- Page 2 CIGGO Tattoo Plus includes: 1* CIGGO Tattoo Plus Box Mod 1* User Manual Specification Size: 88mm*26.5mm*42.8mm Output Mode: TEMP-Ni/ TEMP-Ti/ TEMP-SS/POWER/BYPASS Output Wattage: 1W～75W Support resistance: Above 0.05Ω Temperature range: 100℃~315℃ (200~600℉) Each +/- increase or decrease 5℃/10℉ Hidden Full Length LED Display, Durable Stainless Steel, Single 18650 battery (sold separately), Max Discharge Current over 20 A, 510 Thread.
- Page 3 Pieces & Parts A) Fire Button B) Adjust Up Button C) Adjust Down button D) USB Port (underneath) E) Hidden Screen F) Front Side...
- Page 4 Slide off the battery cover, and put 1pc 18650 cell into the battery holder(recommends: high-rate and better branded 18650 cells, Max discharge current over 20A) Press the firing button 5 times within 2S to turn on the devise on/off, Power on screen display “CIGGO”, and then enter Resistance Screen.
- Page 5 Display Screens: A) Turning on Screen B) Power Mode C) Nichrome TC Mode D) Titanium TC Mode E) Stainless Steel TC Mode F) BYPASS Mode B3.8V B3.6V...
- Page 6 3. Vaping Hold the firing button and inhale from the atomizer mouthpiece, release the firing button and exhale The “ ” battery symbol will change to “ ”lightning symbol 4. Adjust power: Press adjustment buttons. Longer press=Faster adjustment (After you have made your selection/adjustments, the display will show your power output for 1s and then your resistance for 3s) How to Switch Fahrenheit and Celsius Press “+”...
- Page 7 315℃, press “+” shortly to switch to Fahrenheit. (Fahrenheit increases/ decreases 10F each time). Repeat this operation, Celsius and Fahrenheit will switch. 5. How to adjust wattage under Ni/Ti/SS MODE: Press fire button and “+” simultaneously or press fire button and”-” simultaneously, then you can adjust wattage. 6.
- Page 8 8. Standby Mode: If no more operation within 30S,the device will shut off the screen. Press fire button, display screen will light up again. 9. Over Discharge Remind Protection： If vaping voltage is lower than 3.3V, the battery symbol will flash 5 times to remind you the device needs charging, and it turns off automatically.
- Page 9 11. Over heat Protection: If device inner temperature is over 70℃ under VW mode, the screen will display “HOT”, you need to wait till the temperature goes down to below 68℃. 12. Shut OFF Screen Function： Pressing “+” and “-” simultaneously can shut off and turn on the screen. 13.
- Page 10 How to edit your led screen: 1. 1) Make sure your box mod don't have battery cell inside. (if you already have battery cell inside , please take it out), keep the box mod empty or at least the battery slider is open.
- Page 11 2. Short press both "+" and "-" edit next letter. 3. Press fire button and "+" at the same time (image H), editing next word , screen shows Co, C1(image I), C2, ...C9, then the word first letter is flashing , it means you are editing. Repeat the operation，...
- Page 12 4. To finish the settings, long press on fire button and "-" （image J）until the screen shows "END"(image K) , settings are done. image J image K Warm promopt: 1.If you failed with screen editing, please recheck if you've followed correct operating steps , as buttons not press at the same time , or cover back the battery slider too early, both will cause unsuccessful opeartion.
- Page 13 Possible side effect: Using this device can cause dehydration and lead to mouth and throat irritation, if it’s occurs, please change your power and/or airflow setting and/or the your e-liquid. The crossed-out dustbin symbol indicates that batteries, rechargeable batteries, button cells, battery packs, etc.
- Page 14 Our Limited warranties are void if a product is returned with removed, damaged or tampered labels or any alterations, including removal or alteration of any internal or external components. This Warranty extends to the original purchaser only and is non-transferable. Purchaser is required to show proof of purchase for any clams. Contact: service@ciggo.com for warranty inquiries.
- Page 16 TattooPlus 75...
