User Guide
TMS 17XX SE/CE Euro Line Multiswitch Series
Series
TMS 17XX SE A-EU
TMS 17XX SE P-EU
TMS 17XX CE A-EU
TMS 17XX CE P-EU
Language
EN
Single, w/PSU and EU Mains plug, 8-32 out, active TER
Single, w/PSU and EU Mains plug, 8-32 out, passive TER
Cascade, for external PSU, 8-32 out, active TER
Cascade, for external PSU, 8-32 out, passive TER
Version:
9.2016.A
Advertisement
Related Manuals for Triax TMS 17XX SE A-EU Series
Summary of Contents for Triax TMS 17XX SE A-EU Series
- Page 1 User Guide TMS 17XX SE/CE Euro Line Multiswitch Series Series TMS 17XX SE A-EU Single, w/PSU and EU Mains plug, 8-32 out, active TER TMS 17XX SE P-EU Single, w/PSU and EU Mains plug, 8-32 out, passive TER TMS 17XX CE A-EU Cascade, for external PSU, 8-32 out, active TER TMS 17XX CE P-EU Cascade, for external PSU, 8-32 out, passive TER...
-
Page 2: Installation
Triax Euro Line TMS 17XX SE/CE Multiswitch The Triax Euro Line Multiswitch Range is a very high quality range of Multiswitches for single or cascade SAT-IF (satellite) distribution networks with a need for RF loop-through. Available in both active and passive variants for RF loop-through the range offers a perfect selection to use for both terrestrial aerial reception signals (A-active), as well as a full CATV signal including DOCSIS support (P-passive). - Page 3 Make sure that no supply voltage is available on the connection cables during installation. (Temporarily turn off satellite receivers and/or their LNB supply). Mount suitable F-connectors on the coax cable going to the satellite receivers and connect them individually to a multi switch subscriber output (8 to 32 outputs dependent on type).
- Page 4 DTT antenna Satellite STB Grounding connection Optional TER TRIAX TMS 1708 SE stand-alone multiswitch amplifier Connect to 230 VAC Mains via EU-plug 4 x Universal QUATTRO LNBs SAT A, B, C and D Fig. 1: A typical stand-alone installation for 8 satellite receivers and TV.
-
Page 5: Technical Specifications
13/18 VDC, 0/22kHz, DiSEqC 1.0 *) For external PSU w/EU-Mains plug: Fixed/ Fixed/ Fixed/ Power Supply Type 318150, TMS 1520-55, 2,0A, or Included Included Included 318152, TMS 1530-55, 3,0A Please visit www.triax.com for details on individual weight, dimensions and part numbers... - Page 6 Copyright © 2016 TRIAX. All rights reserved. The TRIAX Logo and TRIAX, TRIAX Multimedia are registered trademarks or trademarks of the TRIAX Company or its affiliates. All specifications in this guide are subject to change without further notice.
