- Page 1 OPERATING AND TECHNICAL INSTRUCTIONS KEEP THIS MANUAL WITH DENTAL DELIVERY SYSTEM AT ALL TIMES Manuals for OEM equipment are included in the shipping boxes. Installation, Service, and Maintenance by authorized Heka Dental dealers only. KA-0110-EN-IFU UnicLine S-REV 3.2 – date:20171611 – Soft.: 21.0...
-
Page 2: Table Of Contents
Cautions ......................8 Use of instruments .................... 9 Regulatory Classification .................. 9 Symbols ......................10 UnicLine S Labelled Diagram ................12 1.11 Optional Equipment and Instruments ............. 13 1.12 Diagram of the Display ................... 13 Operating introductions .................. 14 Starting UnicLine S ..................14 Foot control ..................... - Page 3 Removing the suction hose filter ............... 37 Adjustment of the telescopic arm .............. 37 General information about the telescopic arm’s display ......37 Metasys automatic Separator ................. 38 Daily preventive maintenance ..............38 Replacement of the collection tank ............38 Metasys Amalgam Separator ................
- Page 4 Parameters....................56 Sterile Pump, Flow rate 0-100 % (Option)..........56 Setup Code....................56 Aspirator program..................57 Instruments....................57 Spittoon Levels..................58 Glass flow....................58 Setup Chair....................59 Setup Foot ctrl..................59 Setup Timing.
- Page 5 The lighting has also been a major focus area in the development of the UnicLine S. For example, it allows the dentist and assistant to see the settings for the active instrument from the corners of their eyes at any time, which helps them maintain focus on the patient’s oral cavity rather than shifting their attention back and forth.
-
Page 6: Introduction
The new UnicLine S is designed to ensure patient comfort and safety in any of the chair positions. The handles, instrument support, and upholstery are easy to remove and clean. - Page 7 WARNING: For use by qualified and trained personnel only. WARNING: Do not install where there is a risk of explosion. The UnicLine S Dental System is not intended for operation in oxygen rich environments or in the presence of flammable anaesthetics or gases.
-
Page 8: Cautions
CAUTION: This device is only to be sold by or on the order of a dentist. CAUTION: Position the equipment with sufficient area from walls or obstructions to easily operate and disconnect the device (refer to the UnicLine S Mounting Instructions, Section 5 for device dimensions and space requirements) CAUTION: Always examine unit components for damage before commencing treatment. -
Page 9: Use Of Instruments
Documentation of the safety certification of the accessories must be in compliance with current IEC 60601-1 international standards and the current ISO 7494. A complete listing of standards that the UnicLine S Dental Delivery System complies with can be found in Section 12.3 of this manual. -
Page 10: Symbols
Symbols Type B Alternating current General warning See the attached documents and/or catalogues Protective earth Follow Instructions for Use Dangerous Voltage Footcontrol Separate collection of electrical and electronic equipment in Accordance with Directive 2002/96/EEC (WEEE). Temperature Limitation... - Page 11 Keep dry This side up Do not use Hand Hooks Fragile No Rotation Stacking limitation Limitation on Relative Humidity Limitation on Pressure Fuse Do Not Open...
-
Page 12: Unicline S Labelled Diagram
UnicLine S Labelled Diagram... -
Page 13: Optional Equipment And Instruments
1.11 Optional Equipment and Instruments Optional equipment and instruments for use with the Heka Dental UnicLine S can be purchased separately. If you purchased any of the optional equipment and instruments for use with your... -
Page 14: Operating Introductions
Always sterilize handpieces and instruments after operation. Please see the section on Cleaning and Disinfection for a detailed description of cleaning methods for the UnicLine S device. See enclosed OEM instructions for cleaning, disinfection, sterilization, and maintenance of any OEM equipment and instruments. -
Page 15: Foot Control
If in any doubt, please refer to this page. Standard foot control UnicLine S is delivered standard with the round, patented foot control which is used to control the selected instrument. Operation of the Foot Control:... -
Page 16: Standard Variable Foot Control
Standard variable foot control Optional the UnicLine S can be delivered with a standard variable foot control. Operation of the Foot Control: Operation: Location: Action: Top of Foot Activate OP lamp Press Control Change spray on activated Quick Press (<1... -
Page 17: Universal Variable Foot Control
The UnicLine S can be delivered with a universal variable foot control which is used to control the selected instrument. If your UnicLine S is supplied with a universal variable foot control, there will not be 3 pre-selected speeds. However, it can be programmed linearly or logarithmically - please see the technical section for further details. -
Page 18: Wireless Standard Foot Control
Wireless Standard foot control UnicLine S can be delivered with a Wireless Standard foot control, which is used to control the selected instrument. Top: Can be used for activation of OP-lamp (Additional equipment) Middle ring: A short press on the middle ring (less than1 second) changes the spray on the activated instrument. -
Page 19: Pairing Of The Foot Control
Pairing of the foot control Read this instruction before pairing the foot control. 1. Connect the foot control to the console using the cable. The Dental Delivery System must be turned ON. 2. Press and hold the TOP and the middle ring down simultaneously until you hear three beeps 3. -
Page 20: Wireless Standard Variable Foot Control
If your UnicLine S is equipped with a variable foot control, the Dental Delivery System does not have 3 pre-programmed speeds. The foot control can be delivered with a brace to make it easier to move the foot control. -
Page 21: Programming And Pairing Of The Foot Control
Programming and pairing of the foot control Read this instruction before programming the foot control. 1. Connect the foot control to the console using the cable. The Dental Delivery System must be turned ON. 2. Press and hold the TOP and the middle ring down simultaneously until you hear three beeps. -
Page 22: Wireless Variable Universal Foot Control
If your UnicLine S is equipped with a variable foot control, the Dental Delivery System does not have 3 pre-programmed speeds. Activation of pedal arm spring: At the bottom of the foot control, you can activate/de-activate the pedal arm spring by holding the arm at max. -
Page 23: Programming And Pairing Of The Foot Control
Programming and pairing of the foot control Read this instruction before programming the foot control. 1. Connect the foot control to the console using the cable. The Dental Delivery System must be turned ON. 2. Press and hold both ears down simultaneously until you hear three beeps (about 5 sec.). -
Page 24: Instrument Table Display
11 : 17 Time is shown Automatic spittoon function. (touch function) Assistant call. (touch function) Chair control. (only in connection with the UnicLine S patient’s chair) Display when an instrument is activated The timer changes to show speed, intensity or time. 23500 Icon is illuminated (blue) if there is spray air on the activated instrument. -
Page 25: Console Top Keyboard
Console top keyboard Normal display – no instruments activated Chair control (only in conjunction with UnicLine S patient chair). Manual cup fill. The cup is filled as long as the symbol is activated. Manual bowl flush. The bowl is flushed as long as the symbol is activated. -
Page 26: Instruments
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The following descriptions apply to the UnicLine S standard foot control. For instructions on the UnicLine S variable foot control please see the instructions specific to this. -
Page 27: Micro Motor With Fiber Optics
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The following descriptions apply to the UnicLine S standard foot control. For instructions on the UnicLine S variable foot control please see the instructions specific to this. - Page 28 Modification of the spray function In order to change the spray combination on the motor, the instrument must be lifted from the instrument table. The display show the spray combination which can be changed by pressing the middle ring of the foot control briefly. Indicates spray air ON blue Indicates spray water ON green If the air/water spray is selected, there will be an automatic chip blow for 2 seconds...
-
Page 29: Ultrasonic Scaler
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The following descriptions apply to the UnicLine S standard foot control. For instructions on the UnicLine S variable foot control please see the instructions specific to this. -
Page 30: Light Polymerization Instrument
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The following descriptions apply to the UnicLine S standard foot control. For instructions on the UnicLine S variable foot control please see the instructions specific to this. - Page 31 Disinfection of the instrument The optical fibre light guide and the optical protection device can be autoclaved a limited number of times. Warning: NONE of the above light polymerization lamps must be wiped with a strong alcohol solution, as this would dry out the plastic and cause it to crack.
-
Page 32: 3, 6 & 7 - Function Syringes
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The UnicLine S Dental Delivery System can be delivered with different types of 3- function syringes. This section describes the Unic syringe only. For further information about other types of syringes, please refer to the OEM instructions enclosed with the Dental Delivery System. -
Page 33: Intraoral Camera
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The following descriptions apply to the UnicLine S standard foot control. For instructions on the UnicLine S variable foot control please see the instructions specific to this. -
Page 34: Sterile Water System
Sterile water system If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. The sterile water system supplies sterile salt water when the motor or the scaler is activated. Use of the sterile salt water disconnects the normal spray function. -
Page 35: Spittoon
Spittoon If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. How to operate the spittoon By activating automatic fountain, the glass will be filled in the programmed time followed by the bowl flush. -
Page 36: Adjustment Of Water Pressure To Cup And Bowl
Adjustment of water pressure to Cup and Bowl. The water pressure can be adjusted on the adjustments screws (+) for more pressure (-) for less pressure. Bowl Dismantling the glass bowl The glass bowl can be removed for cleaning. Remove mushroom from drain. -
Page 37: Suction Tubing On The Telescopic Arm
Suction tubing on the telescopic arm Selective suction In case of selective suction only the chosen suction hose will work. The suction system is a medium volume suction system from 90 to 250 l/min. Precautionary measures shall be taken during installation to ensure restriction of flow. -
Page 38: Metasys Automatic Separator
Metasys automatic Separator If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. To ensure the correct function and to avoid malfunction of the Metasys automatic separator the following must be carried out: Daily preventive maintenance Rinse the suction hoses and the spittoon after every treatment. -
Page 39: Metasys Amalgam Separator
Metasys Amalgam Separator If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. To ensure the correct function and to avoid malfunction of the Metasys amalgam separator the following must be carried out: Daily Care Rinse the suction hoses and the spittoon after every treatment. -
Page 40: Cleaning & Disinfection
Suction Tube Holder Instrument Tray Instrument Handles External surfaces of the UnicLine S device should be cleaned and then disinfected. See Pictures on page 40 for disassembly of Instrument Handles from the Instrument Table for cleaning and disinfection. -
Page 41: 10.2 Cleaning & Disinfection For The Dental Chair Upholstery
10.2 Cleaning & Disinfection for the dental chair upholstery FIRST, CLEAN Wipe using a soft cloth moistened with mild detergent or disinfecting solution at the beginning and end of each workday. For stains, alcohol based cleaners such as Fantastik® and Formula 409® can be used. To sanitize, use a solution of 1:5 bleach to water. -
Page 42: 10.4 Automatic Suction-Cleaning System
10.4 Automatic Suction-Cleaning System If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. Display You can switch to Suction cleaning by entering the sub-menu (blue button on the telescopic arm). Here you can choose between rinsing with water (F1 key) or with chemicals (F4 key). -
Page 43: 10.5 Instrument Flush
If the equipment does not work as described below, contact an authorized Heka Dental dealer immediately. In order to ensure a fresh water supply, the UnicLine S can be delivered with a facility which flushes the instruments automatically with water. -
Page 44: Maintenance
Maintenance Removing the instrument support The instrument support can easily be removed for cleaning by pulling the rest out from the instrument table. For Cleaning and disinfection se Chapter10 Maintenance of the equipment should be an integral part of the routines of the clinic. Current daily maintenance should be continued. -
Page 45: 11.1 Annual Maintenance
11.1 Annual maintenance Annual inspection by an authorized UnicLine S technician should be performed to ensure optimal function and to maintain the extended 3-year guarantee. The warranty is only valid if the Dental Delivery System is serviced annually with recommended service kit and the installation/service cards and service-kit serial-numbers are submitted to Heka Dental A/S. -
Page 46: Annual Maintenance (Checklist)
11.2 Annual maintenance (checklist) Unit Tested Adustered/Programmed Replaced Product nr. Rep. Base power board Consol controller board Display til glas inst. bord db-0030-11 Instrument controller board Chair controller board (option) Unic footcontrol board (option) Telescope display board Grounding of Unit Water adjustment/regulation kit * 907 Water Filter Insert... - Page 47 Unit Tested Adustered/Programmed Replaced Product nr. Rep. Glas top table Display. Ajust time by telescopehead Key function + light Fodkontrol Functionality Light-Setting Lamp Function Exposure Time Water Valve Gasket (watervalve) * ft-2140-15 O-ring 12,5 x 1,1 FKM ( watervalve ) * ft-0033-15 O-ring 2,35 x 1 (adjust needle Water) * ft-2153-15...
-
Page 48: 12.0 - 16.0 Technical Sections, - Only For Authorised Technicians
12.0 - 16.0 Technical Sections, - only for authorised technicians 12.0 Technical data Power voltage 230V ~/115V ~ Frequency 50Hz/60Hz Power consumption 5 A/10 A Protective degree Type B Classification Class I Fuses Base controller board F1 (230V-secondary fuse) : T4.0A L250VAC 5x20mm F2 (230V-secondary fuse) : T4.0A L250VAC 5x20mm F3 (230V-secondary fuse) -
Page 49: Installation Requirements
5A/1150 W / 10A/2300 W. All of these outlets have a T5.0A/T10.0A fuse. Warning! In order to prevent electric shock, the UnicLine S must only be connected to a mains supply with protective earth. -
Page 50: Classification Of Equipment
12.2 Classification of Equipment Please refer to the OEM manufacturer instructions for more information. Dental Delivery System : Class IIA all type B patient parts comply with IEC/EN60601-1. Method of operation : Continuous operation with intermittent load. Protection against water : IPX 0. -
Page 51: Regulatory Standards Compliance
12.3 Regulatory Standards Compliance Standard: Title: EN 60601-1:2006 Medical electrical equipment EN 60601-1/ corr.1 Generel safety w. corrections EN 60601-1/A1 Industrial, scientific and medical equipment – Radio EN 55011 frequency disturbance characteristic. EN 1041:2009 Information supplied by the manufacturer of medical +A1:2013 devices EN 1640... -
Page 52: Wireless Foot Control, Technical Specifications
12.4 Wireless foot control, technical specifications Specification Radio frequency: 433MHz Encryption: 16 bit Batteries: 3 pieces AAA NiMH rechargeable batteries (700-1100mAh) Operating time: Up to 5 days with fully charged new batteries Radio Part The wireless foot control consists of the foot control it selves with a radio section and a receiver PCB db-0064-11, which is located on P 103 on Power Base PCB. - Page 53 Caution: Be sure to inset the batteries as marked in the battery compartment. Caution: The batteries are a part of an Medical Equipment and approved for the foot control. No other batteries are allowed. Heka Dental A/S can supply for spare batteries.
-
Page 54: Hydraulic Diagram
12.5 Hydraulic diagram... -
Page 55: Menu Structure
13.0 Menu Structure Press the menu symbol repeatedly to change between the menus. Main Menu. SV (Spittoon Valve.) Vacuum in the fountain. (Option) Rinse Position. The chair runs in the rinse position, the cup fills and the bowl is rinsed. (These functions depend on the settings in the Setup menus) Cup fill Short press the cup fills and the bowl is rinsed. -
Page 56: Water Supply. (Option)
Water Supply. (Option) Public. Public water supply, supplies the instrument panel. (Shown by P in the Main menu). Bottle. Bottled water, supplies the instrument panel. (Shown by B in the Main menu). Time/Clock. Adjust the clock in the display. Hour 0-2 Hour 0-9 Min. -
Page 57: Aspirator Program
Aspirator program. Programming the sensor in the telescope head. Full. Sampling (programming) with all aspirator and active instruments in the container. Empty Sampling (programming) with all aspirator and active instruments removed from the container. Instruments. Defines instruments at various Positions. Prev. -
Page 58: Spittoon Levels
Valve3 max: Decrease the maximum valve3 voltage Increase the maximum valve3 voltage Scaler. Control: Var. used for variable scalers Const used for not variable scalers Spittoon Levels. Setting the programmed Flow time on the Main menu. Cup fill (Rinse Position) The key is activated for the desired flow time. -
Page 59: Setup Chair
Start deg. Stop Must be set to 0 0 in UnicLine S Setup Chair. Press repeatedly to change between the options Auto/None. Auto: The chair runs automatically in the rinse position upon activation of Rinse Position. In the Rinse Position you have these... -
Page 60: Setup Timing
Min / Max. Sets the pedal movement. Restart the system (switch on/off) for the change to take effect. Setup Timing. Chip blow. / Steri-pump Second setting for Chip blow. (+) Increased number of seconds. (÷) Reduced number of seconds. Must be confirmed by pressing for the change to take effect. -
Page 61: Setup Features
Setup Features. Individual setup features can be set in this menu. Press repeatedly to change between the options. Switch On/Off by pressing Name ON/OFF Clock. On (default): Clock displayed in the instrument table Off: Clock not displayed in the instrument table Bowl auto (not used) Bowl flush. -
Page 62: Time/Date
Off: the Dental Delivery System stays locked until unlocked or until it is turned off/on All choices in this menu must be confirmed by pressing for the change to take effect. Time/Date Setup the pressent date Date Month Year Service/date Setup the date for next service indication. -
Page 63: Versions
Colour 223 soft Console top Bowl 222 soft Console top Bowl 221 soft Console top Bowl 184 soft (red)* Console top Bowl 478 soft (orange)* Console top Bowl 327 soft (yellow)* Console top Bowl 180 soft (green)* Console top Bowl Turquois* Console top Bowl... -
Page 64: Menu Overview
13.1 Menu overview... -
Page 65: Brief Description Of Error Diagnostics
14.0 Brief Description of error diagnostics This is a brief description of ways in which to locate errors if there are communications problems between the PCBs in the Dental Delivery System. If data communication between the PCB’s in the Dental Delivery System is blocked, the “version menu”... - Page 66 In case the unit detects an error, it will beep twice and display an error code on the telescope display. The top line is the error number and name. In this example “E11 Footc.NoData” means that data communication to the foot control has been lost.
-
Page 67: Special Conditions For The Connection Chair To Uniclines
14.2 Special conditions for the connection Chair to UnicLineS Conditions that affect the chair and unit: When an instrument is activated (lifted), the chair locks into position and the position cannot be changed before all of the instruments have been returned into their rest position. -
Page 68: Summary Of Communications
15.0 Summary of Communications This section describes overall functionality of the electronic PCBs in the UnicLine S. The aim is to provide a summary that will enable the authorized technician to identify and localise any operating problems quickly. The large number of indicators (light diodes and glow discharge lamps) provides the authorized technician with a quick visual status of the system. -
Page 69: General Information
General information Most of the connections on the PCBs can be broken down into standard connection types: 1. Fixed outputs 2. Relay outputs 3. On/Off outputs (fixed + Public Utilities and transistor for chassis) 4. PWM outputs (fixed + Public Utilities and pulse width modulated transistor for chassis) 5. -
Page 70: Console Controller
Console Controller The console controller handles the following: 1. 24VDC stabilised power supply 2. Central storage for instrument settings etc. 3. Clock function 4. Control of spittoon 5. Control of suction valves 6. Interface to telescope 7. Connection of up to 2 active instruments 8. -
Page 71: Instrument Controller
Instrument Controller The instrument controller handles the following functions: 1. Connection of ganged valves and instrument switches 2. Connection of the instrument table display 3. Motor control 4. Instrument control 5. Pump control 6. Control of optical instrument detectors The instrument controller also contains a wide range of indicators which show the status of the Dental Delivery System and indicate whether the Dental Delivery System is working correctly. -
Page 72: Components & Performance Specification
16.0 Components & Performance Specification Dental Delivery System: Components: Five PCBs (Base power, Instrument Controller board, Console board and Telescope board) Torodial Transformers Air/Water Valves & Tubing Amalgam Separator Water Container Instrument Arm & Table Instrument Tray and Table Handles Display Screen and Keypad Materials: Aluminum (Instrument Arm, Console, Table,... -
Page 73: Components & Performance Specification, Cont
Components & Performance Specification, cont. Dental Chair: Components: Junction PCB Seat Motors (Back, Main, Seat) Safety Stop (Chair Lowering) Safety Stop (Backrest) Capacitors Chair Base Headrest Backrest Footrest with Stirrup Armrest Materials: Aluminum DKL or UltraLeather™ Upholstery Dimensions: Chair Length 71.7”... -
Page 74: Probability Of Occurrence & Duration Of Contact For Parts
16.1 Probability of Occurrence & duration of contact for parts. Part Time Comment. Instrument table T < 1 s Table 23, Is touched by the operator for moving the table in position, max 74°C Turbine 10 s =< t < 1 min Table 23, Handpice handled during treatment by the operator, max 51°C... -
Page 75: Warranty Terms & Conditions
All warranty repairs must be performed by an authorized Heka Dental technician The following years’ service cards must be sent to Heka Dental within 15 days from the day the annual service check is performed The following general terms apply to the warranty: ... - Page 76 In order to provide our customers with a fast and efficient service after the end of the warranty period, Heka Dental offers a number of exchangeable parts at a fixed repair price outside the warranty. These only apply to equipment being serviced (standard service and annual service) by an authorised Heka Dental dealer.
-
Page 77: Servicecard
17.1 Servicecard. Attention Warranty is only valid if the Dental Delivery System is serviced annually with recommended service kit and the installation/service cards and service-kit serial- numbers are submitted to Heka Dental A/S. -
Page 78: Emc Informations
Guidance and manufacturer’s declaration – electromagnetic emissions The UnicLine S Dental Delivery System is intended for use in the electromagnetic environment specified below. The customer or the user of the UnicLine S Dental Delivery System should assure that it is used in such an environment. - Page 79 Guidance and manufacturer’s declaration – electromagnetic emissions The UnicLine S Dental Delivery System is intended for use in the electromagnetic environment specified below. The customer or the user of the UnicLine S Dental Delivery System should assure that it is used in such an environment.
- Page 80 The UnicLine S Dental Delivery System is intended for use in the electromagnetic environment specified below. The customer or the user of the UnicLine S Dental Delivery System should assure that it is used in such an environment. Immunity IEC 60601...
- Page 81 Portable and mobile RF communications equipment and UnicLine S dental unit The UnicLine S Dental Delivery System is intended for use in an electromagnetic environment in wich radiated RF disturbances are controlled. The customer or the user of UnicLine S Dental...
-
Page 82: Disposal Of The Dental Delivery System
In order to reduce the environmental impact of the product throughout its lifetime, the UnicLine S is designed to be as safe as possible to manufacture, use and dispose Components suitable for recycling should always be sent to a recycling centre once all hazardous materials have been removed. - Page 83 Notes:...
- Page 84 Heka Dental A/S Baldershøj 38 * DK-2635 Ishøj * Denmark Phone. +45 4332 0990 * Fax +45 4332 0980 www.heka-dental.dk...
