MLock Instruction Manual
Adapt-IQ Digital Signage Tablets 7", 10.1" & 15.6"
Model:
MCT-70QDS, MCT-70QDS-POE, MCT-10QDS, MCT-10QDS-POE, MCT-10HPQ,
MCT-10HPQ-POE, MCT-156QDS, MCT-156QDS-POE, MCT-156HPQ, MCT-156HPQ-POE
Please keep this manual for future reference.
WHAT IS MLOCK?..........................................................................1
MLOCK INSTRUCTIONS..............................................................1
SETTINGS...............................................................................2
PLAYBACK SETTINGS..........................................................................3
DEFAULT APP.................................................................................5
RETURN BUTTON LOCK............................................................6
POWER SCHEDULE....................................................................7
MOTION SENSOR - NOT CURRENTLY IMPLEMENTED.................7
SCROLLING TEXT..........................................................................8
LOG FUNCTION...................................................................................8
MLOCK CONFIGURATION SETUP........................................10
APPENDIX A...........................................................................12
*Desktop background will vary depending on the Android version installed.
Table of Contents
Page
Advertisement
Table of Contents
Related Manuals for Mimo Monitors Adapt-IQ MCT-70QDS
Summary of Contents for Mimo Monitors Adapt-IQ MCT-70QDS
-
Page 1: Table Of Contents
MLock Instruction Manual Adapt-IQ Digital Signage Tablets 7”, 10.1” & 15.6” Model: MCT-70QDS, MCT-70QDS-POE, MCT-10QDS, MCT-10QDS-POE, MCT-10HPQ, MCT-10HPQ-POE, MCT-156QDS, MCT-156QDS-POE, MCT-156HPQ, MCT-156HPQ-POE *Desktop background will vary depending on the Android version installed. Please keep this manual for future reference. Table of Contents Page WHAT IS MLOCK?……………..…………………..……………....…1 MLOCK INSTRUCTIONS……………..…………………..………………1... -
Page 2: What Is Mlock
MLock’s two Play Modes, Video Player or Web Viewer, to display video content or lock the browser to a URL that you provide. Mimo Monitors also offers an MLock SDK that can be used to bundle Mimo services into your application. -
Page 3: Settings
3. The display will prompt you for a password, (default:0000) and the display will show the MLock Settings page. 4. To exit the MLock application, select the Home Icon in the top right-hand corner and the MLock application will exit to the Android home screen. Settings: Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com... -
Page 4: Playback Settings
Web Viewer: This mode will start the specified web page (Web URL). There will be no URL bar, or ability to exit the application without a password. Video Folder- Specifies the storage directory for the video file to be played (For example: /mnt/external_sd/video/) Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com... - Page 5 Repeat One: Plays a specific video, designated in the Video Folder, on repeat. Default video playback configuration. Web URL- Specifies the URL page to load upon startup. This does require the full URL with http:// or https:// Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com...
-
Page 6: Default App
YOU CAN DISABLE ANY WAY TO NAVIGATE. Hiding the Status Bar or disabling physical buttons may be desirable however without a properly written application, the only way to exit may be using safe mode or even a factory reset. Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com... -
Page 7: Return Button Lock
(located on the back of the tablet) is enabled and used to escape the locked screen, you will be prompted for a password. Additionally, you will be prompted for a password when exiting the MLock Console via the Home icon. The default password is 0000. Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com... -
Page 8: Power Schedule
Schedule Power Off field and will be turned back on at the time that is entered in the Schedule Power On field. This feature does NOT physically power the device on or off. Motion Sensor: – Not Currently Implemented Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com... -
Page 9: Scrolling Text
Scrolling Text: When configured, the scrolling marquee will appear on the bottom of the display. Note: You need to check Android Settings ->Developer options -> Disable HW overlays. This capability can be turned off in that location. Log Function: Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) -
Page 10: Content Update (Cms-Content Management Server)
The application will copy the files from the USB drive to the location specified within the Playback Settings à Video Folder directory. When the thumb drive is installed you will see this message indicating that you’ve correctly configured MLock and your thumb drive. Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466) -
Page 11: Mlock Configuration Setup
Appendix A: Provides additional information on how to view Configuration files in a web-based browser. Instructions: 1. Enter the MLock Console interface. Note that "Config Load" and "Config Save" are available. 2. Once you are satisfied with your MLock configuration, click Config Save. Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com... - Page 12 Note: The first option is the SD card path, the second one is the USB File Storage path. If an SD or USB storage device does not exist, clicking Config Save will result in an error message stating: "SD and USB does not exist". Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com...
- Page 13 3. Config Load allows you to select mlock_config.xml files from either a USB drive or an SD card. 4. When the mlock_config.xml file does not exist on the USB drive or the SD card, clicking on "Config Load" will prompt the error message "SD and USB have no configuration file". Mimo Monitors info@mimomonitors.com Mimo Monitors Sales: 1-855-YES-MIMO (937-6466) info@mimomonitors.com...
- Page 14 An mlock_config.xml file located on an SD card. Enter the SD card from the Explorer. You can use Firefox to view the content of the configuration if permissions allow. Settings->Apps->Firefox->Permissions->Individually click All Permissions to “ON”. Mimo Monitors 743 Alexander Rd. Suite 15 Princeton, NJ 08540 Mimo Monitors info@mimomonitors.com...
- Page 15 The configuration contents are shown as follows: Mimo Monitors 743 Alexander Rd. Suite 15 Princeton, NJ 08540 Mimo Monitors info@mimomonitors.com 743 Alexander Rd. Suite 15 Sales: 1-855-YES-MIMO (937-6466) Princeton, NJ 08540 info@mimomonitors.com Sales: 1-855-YES-MIMO (937-6466)
