birddog STRP12050A-WIFIRT Instructions

WiFi Converter
Important: Read All Instructions Prior to Installation
Function introduction
Green LED indicator:
Power normal
41 mm
Red LED indicator:
Under control
Blue LED indicator:
WiFi connected
12V DC power input
Ethernet
WiFi Reset switch: press and
hold down for 10S then release,
the blue WiFi indicator will go
off and go on again, WiFi setting
will be factory reset.
Reset
Switch Note: When the hub
is configured to home router,
use the button to reset WiFi
setting to enable to control
directly through the hub
network again.
Product Data
09.288WN.04158
Output
Operation Frequency
Power Supply
Operating temperature
Relative humidity
Dimensions
• The convertor works with RF receiver series to be controlled by IOS or Android system via WIFI.
• Waterproof grade: IP20
Safety & Warnings
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Wiring diagram
Method 1:Connect your cell phone with your home net router(WiFi-RF)
Method 2:Connect your cell phone with the converter(WiFi -RF)
RF signal
2.4G
12VDC
0-40°C
8% to 80%
110x85x24.2mm
Router
RF LED Receiver
Learning Key
RF LED Receiver
Learning Key
12V DC power
input
RF LED Receiver
Learning Key
12V DC power
input
