SEC-8089 User Manual
Rev 0.1
EpiValley
APRIL 15, 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SEC-8089 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EpiValley SEC-8089

Summary of Contents for EpiValley SEC-8089

  • Page 1 SEC-8089 User Manual Rev 0.1 EpiValley APRIL 15, 2009...
  • Page 2 Revision History Rev 0.1 2009 04 15 First issue...

  • Page 3: Table Of Contents

    Contents 1. Installation & Setup..........................4 2. Getting Started ...........................6 3. Web..............................7 4. Voice ..............................9 1. Call placing/receiving buttons .......................9 2. Call placing/receiving display .....................10 5. SMS ..............................11 1. Send............................11 3. Sent.............................14 4. Draft ............................15 5. Spam............................16 6. Voice ............................17 6.

  • Page 4: Installation & Setup

    1. Installation & Setup 1. SAM Installation 1.1 Insert the Installation CD to the CD-ROM Drive. If the installation process does not start automatically, run Setup.exe file in the CD-ROM Drive. Select a language and click “OK”. (Do not plug the USB modem in the USB port before you finish installing SAM.) 1.2 To continue installation, click “Next”.
  • Page 5 1.4 In order to use the modem for the first time, you need to install the device driver. If the device driver is installed, click “OK” and wait until installation process is completed. 1.6 If SAM is installed successfully, click “Finish”. After installation of SAM, plug the modem in the USB port.

  • Page 6: Getting Started

    2. Getting Started Plug the modem in the USB port, and select “sam.exe”. Then the following initial window appears. If the modem is not properly plugged in, the following message appears. If UIM is not installed normally in the modem, the following message is displayed. If the system finds the modem, SAM is started as in the following figure.

  • Page 7: Web

    3. Web To access Internet, click “web”. Click “Add” to create a connection profile or Click “Edit” to edit existing profile. Set the profile for connection.
  • Page 8 Select a profile from the list, and click “Connect”. If Internet is accessed, “Hybrid Modem Connected” is displayed in the Status bar (bottom of the program window). Rx or Tx status appears, and the Internet connection icon appears in the top right of the program window.

  • Page 9: Voice

    4. Voice 1. Call placing/receiving buttons ___________________________________________ 1.1 Enter the phone number with the number pad or the keyboard, and click “Send”. Click “End” to finish the call. 1.2 To receive a call, click “Send”, and to end a call, click “End”. 1.3 You can control the volume using the control button during a call.

  • Page 10: Call Placing/Receiving Display

    2. Call placing/receiving display_____________________________________________ 2.1 The caller ID of the incoming call is displayed. 2.2 The current call status is displayed. “Incoming call” is displayed if a call is incoming. After connected, the call time is displayed.

  • Page 11: Sms

    5. SMS 1. Send _________________________________________________________________ 1.1 To send a message, click “SMS”, and select “Send”. 1.2 Write a message, enter the numbers of the receivers one by one, and click “Add”. To delete a number from the list, select the number and click “Del”.
  • Page 12 1.3 Select “Normal”, “Urgent” or “Emergency” for the priority of the message, and click “Send”. 1.4 To send a message to numbers of users, the window shows the current number of receivers. 1.5 To send a message at the designated date and time, click “Reserved”. Select Year, Month, Day, Hour and Minute, and click “OK”.
  • Page 13 2. Inbox 2.1 If a message is incoming, an auto popup message appears, or the tray icon blinks, or the alert is sounded depending on your selection in “Incoming SMS Alert”. The received message is automatically saved in Inbox. To set the “Incoming SMS Alert” option, press the “SMS” tab in the “Settings” menu, and set “Incoming SMS Alert”...

  • Page 14: Sent

    3. Sent __________________________________________________________________ 3.1 In the “Sent” menu, the sent messages are sorted by Number, Name, Date and Content. You can identify the location of the messages (PC, UIM or Modem) with the icons. ▶ You can use the following functions with the buttons provided under the list or by right-clicking the mouse button on an entry in the list.

  • Page 15: Draft

    4. Draft__________________________________________________________________ 4.1 In the “Draft” menu, the failed messages or unsent messages are listed. ▶ You can use the following functions with the buttons provided under the list or by right-clicking the mouse button on an entry in the list. - Delete : The selected messages are deleted from the list.

  • Page 16: Spam

    5. Spam _______________________________________________________________ 5.1 In the “Spam” menu, the filtered messages containing specific numbers or words are listed. The messages are sorted by Date, Number, and Content. 5.2 You can select the numbers or words you wish to filter as spam message in the “SMS” tab of the “Settings”...

  • Page 17: Voice

    6. Voice _______________________________________________________________ 6.1 The voice mail messages from BTS are displayed in the “Voice” menu. You can sort the messages by Number, Data and Content. ▶ You can use the following functions by right-clicking the mouse or with the buttons at the bottom of the list.

  • Page 18: Address

    6. Address 1. List __________________________________________________________________ 1.1 To save a phone number in the Address book, click “Add” under the phone numbers list. Select the location between “PC”, “Modem” and “UIM”, enter Name, Mobile, Group, Home, Office, FAX, Address, E-mail and Comment, and then, click “OK”. ▶...

  • Page 19: Search

    2. Search _______________________________________________________________ 2.1 To search an entry in the list, select a field (Name, All no, Mobile, Group, Address, Home, Office, FAX, Email, or Comments) in the top left of the list, enter a name or number, and then, click “Search”. Then, the entries containing the name or number are listed.

  • Page 20: Log

    7.Log 1. Call Log ______________________________________________________________ 1.1 You can see All Calls, Dialed Numbers, Received Calls and Missed Calls. The number of entries stored in the list is displayed in the right of the window. 1.2 “All Calls” shows Dialed Numbers, Received Calls and Missed Calls which can be identified by the icons. The entries can be sorted by Date, Time and Number.

  • Page 21: Internet Log

    2. Internet Log __________________________________________________________ 2.1 If you click “Internet Log” in the Call Log List, you can check the internet logs. “Total” shows the total time used, and Kbytes of the sent data and received data. 2.2 The Internet Log list displays information on Internet usages such as dates, time, Tx and Rx. 2.3 On the top of the Internet Log list are the total log count available and the current log count.

  • Page 22: Settings

    8.Settings 1. General Settings _______________________________________________________ 4.1 If you select “Auto termination when windows go to power saving mode” in “Windows Settings”. the program is automatically exited when the PC is switched to the power saving mode. If you select “Auto execution when windows start”, the program is automatically started when the Windows is booted.

  • Page 23: Sms Settings

    2.1 You can select the incoming call alert method. If you select “Blinking Tray Icon”, the tray icon flickers. The notice pops up if you select “Auto Pop-up”, or an alert tone sounds if you select “Sound prompt”. Or, you can select all the options. 2.2 If “1 Min Alert”...

  • Page 24: Uim Settings

    6. UIM Settings __________________________________________________________ 6.1 In “Current PIN Code”, enter the current UIM PIN Lock Code. 6.2 If “Pin Lock Option” is “On”, you need to enter the UIM PIN Code. If it is “Off”, you don’t need to enter the PIN Code to access UIM and reset the data.

  • Page 25: Information

    7.5 If “Incoming Call Lock” is “On”, you need to enter the lock code every time you receive a call. 7.6 If “SMS Lock” is “On”, you need to enter the lock code every time you access the “SMS” menu. 7.7 With “New Lock Code”, you can change the lock code.

  • Page 26: Internet

    9. Internet If you click “Internet”, the Internet browser is started, moving to a specific URL. 10. Email The Email client or the web mail selected by the service provider is started.

  • Page 27: Others

    11. Others 1. File __________________________________________________________________ 1.1 With the “CSV Import” menu, you can import an address book to SAM. Click “CSV Import”, select a csv file in the search window, and click “Open”. If the “Field Mapping” window pops up, select the matching items, and click “OK”.

  • Page 28: Internet Access Status Icon On The Top Right Of The Program Emulator

    3.1 You can view description on a function with “Quick Guide”. 3.2 If you select “About”, the SAM version and the Home address of Epivalley are displayed. 4. Internet access status icon on the top right of the program emulator ___________ 4.1 The Internet Access Icon is activated if the system is accessed to Internet.

  • Page 29: Part Of The Usb Modem

    12. Part of the USB Modem USB Connector R-UIM Socket T-Flash Socket Indicate LED Earjack Connector...

  • Page 30: Specification

    13. Specification Functions Functions Functions Functions Specifications Specifications Specifications Specifications Remark Remark Remark Remark Main Operation Chip Main Operation Chip Main Operation Chip Main Operation Chip QSC-6085 CDMA2000 EV-DO revision A (Downlink 3.1Mbps / Uplink 1.8Mbps) CDMA Standard CDMA Standard CDMA Standard CDMA Standard CDMA2000 EV-DO revision 0 (backward compatibility)
  • Page 31 PST Tools PST Tools PST Tools Storage temperature range :-30C to +65C Humidity :5% to 95%(non-condensing) EpiValley programmed PST/HEX downloader/NAM editor/PRL editor Win XP, Vista 32bit and 64 bit (PC dialer) OS support OS support OS support OS support MAC O/S Compatible (Data driver only)
  • Page 32 Near-Body Operation To maintain compliance with FCC RF exposure requirements, maintain a 5mm, separation distance between the user's body and the EVDO 1X USB Modem, including the antenna, whether extended or retracted. The highest SAR value for this EVDO 1X USB MODEM is 1.120 W/kg (CDMA Cellular Band) / 0.966 W/kg (EVDO-Rev.0 Cellular Band) / 1.090 W/kg (EVDO-Rev.A Cellular Band) / 0.217 W/kg (CDMA PCS Band) / 0.261 W/kg (EVDO-Rev.0) / 0.242 W/kg (EVDO-Rev.A).
