SPL-32R/SPL-32T
UHF Wireless Tour Guide System
User Manual
SPL-32T
SOOLAI ELECTRONICS CO.,LTD
SPL-32R
Thank you for choosing SOOLAI!
Please take a few moments to read these instructions carefully, as we want you to
enjoy your new SOOLAI products quickly and to the fullest.
Special features
●S
uper portable design -Super mini, light weight, metal shell
●
UHF professional frequency, PLL synthesized design, 32 channels available
●
"Digital Pilotone & Noise Lock" dual-squelch Circuitry
●
High performance double-IF circuit design
●9
6*64 dot matrix White LCD display
●
LCD display Channel, frequency, volume, battery, RF level, AF level, transmitter
gain, RF power, and lock. Mode
●
Transmitter dynamic display of AF level, AF overload warning, 31-step
microphone gain adjustment design
●
Quick-mute function
●
Receiver digital 16-step volume control
●
Receiver digital 21-step SQ adjusting
●
Panel lock with password
●
Built-in polymer battery working for 10 hours
●
unique clip-worn design
●
system support of inputting background music while talking
●
Operating range 300 ft (line-of-sight)
Main Applications：
Industry Touring
Widely used in touring, visiting museums, exhibitions
Guest reception
Used in reception of visitants in product presentation, advanced exhibition of large
companies
Teaching
Used in meeting and teaching of school and so on
Simultaneous interpretation
International conference simultaneous interpretation
Stage monitoring
Monitoring of performance: especially for acting singer to monitor accompaniment
- 2 -
Advertisement
Table of Contents
Related Manuals for SOOLAI SPL-32R
Summary of Contents for SOOLAI SPL-32R
- Page 1 Thank you for choosing SOOLAI! Please take a few moments to read these instructions carefully, as we want you to enjoy your new SOOLAI products quickly and to the fullest. SPL-32R/SPL-32T Special features UHF Wireless Tour Guide System ●S uper portable design -Super mini, light weight, metal shell ●...
-
Page 2: Table Of Contents
CONTENT SPL-32R receiver … … … … … .… … … … … … … … … … … … … … … ..04 SPL-32R receiver … … … … … … … … … ...… … … … … … … … … … … 05 Operating controls …... -
Page 3: Operating Controls
Operating controls Adjusting channel/frequency 1. Via keeping ON/OFF button pressed for 3 seconds, you can switch the receiver on. 1. Keeping SET button pressed for 3 seconds, you can enter the operating menu. 2. Via “ ” or “ ” button, you can select “... -
Page 4: Setting Locking/Unlocking
Setting locking / unlocking SPL-32T transmitter “ ” 1. Keeping button pressed for 3 seconds, you can enter the operating menu. ※ If there is no operating menu but “ CODE?---”displays, it means the former user has set locking code, as shown in the figure . You have to enter the correct code via “... -
Page 5: Operating Controls
Operating controls perfect performance. If there is OL icon, you have to adjust AF GAIN lower. Please refer to Adjusting AF gain. “ ” 1. Via keeping button pressed for 3 seconds, you can switch the transmitter on, as shown in the figure 16. 2. -
Page 6: Adjusting Transmitting Power
reduced by 10dBs.) is wrong, “ INVALID” will appear. Please try other codes. If the code is lost, ● The user can adjust the AF GAIN according to AF dynamic volume display. If please try the following total 8 codes one by one, until you can enter. “... - Page 7 SC-02double unit charger （figure 35） （42） LED for charging compartment(left) （figure 34） （43） Charging cmpartment(left) （44） Charging cmpartment(right) （45） LED for charging compartment(right) （46） Power input jack, mini USB 5Pin. （47） Power adapter, 5V/1A Operation controls： 1. Connect the power adapter to AC power and connect the other side to Power input jack on the charger, as shown in the figure 35.
-
Page 8: Scb-20 Twenty Unit Charging And Storing Case
SCB-20 twenty unit charging and storing case Main application samples In trialogue setting, you are proposed to use the units with enforcing antenna to enlarge transmitting range. In the following samples, TX means transmitter. RX means receiver. (A), (B), (C)… … means different channels/frequencies: channel A, channel B, channel C…... -
Page 9: Troubleshooting
Ｂ．Simultaneous Interpretation different frequency ranges, such as range A and range B.(You have to contact SOOLAI to preset the channel frequency for you!!!)(Please refer to Frequency diagram on page 21.) Troubleshooting No voice in receiver output 1. Make sure the transmitter and receiver are both powered. -
Page 10: Specifications
-10℃ to +55℃ if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no RECEIVER (SPL-32R): guarantee that interference will not occur in a particular installation. Sensitivity 2uV (60dB S/N) -
Page 11: Warranty
WARRANTY SOOLAI values your business and always attempts to provide you the very best of service. No limited warranty is provided by SOOLAI unless your SOOLAI Product was purchased from an authorized distributor or authorized reseller. Distributors may sell Products to resellers who then sell Products to end users.
