USER MANUAL Subject to change without prior notice TUM1094 REV. G 28.01.2019 IMPORTANT Please read this manual carefully before installing the product. R. Stahl Tranberg AS info@stahl-tranberg.com stahl-tranberg.com Main office: Strandsvingen 6 N-4032 Stavanger Norway +47 51 57 89 00...
Page 2
Be aware of any personnel close to the searchlight when testing or operating. GENERAL WARRANTY CERTIFICATE Tranberg AS gives normally a general warranty on Tranberg products valid for 12 months from delivery date. General the products will Confirm to the purchase order,...
GROUP 600A105424 SEARCHLIGHT MOTION CONTROL: The Tranberg Commander Searchlight uses a serial communication net- work to control and monitor the searchlights. This makes it possible to The Commander Searchlights are equipped with positional sensors for both freeely choose and combine the number of searchlights and panels. All motors/axes.
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL OPERATION 2.1 START-UP PROCEDURE If, for some reason, this is not possible, please do a manual re-scan as described in chapter 5.2 after all units are powered up. Power-up: Apply power in the following sequence: A searchlight will do a position reference search when powered up and Apply the 230 VAC power to the searchlights first.
Page 6
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL OPERATION “FAST” AND “SLOW” (2612/2613/2614): “LIGHT” (2612/2613/2614) Adjust motor speed. 9 Steps, 5 Indications Turn light on or off. A green indicator light will light steady if the lamp is on. Flashes rapidly when the group function is activated. “HOME / GROUP”...
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL MAINTENANCE INSTALLATION 3.1 CLEANING 4.1 MECHANICAL INSTALLATION PANEL: SEARCHLIGHTS PHYSICAL PLACEMENT: The control panel may be cleaned with a mild detergent on any parts. Consider the end stop of the horizontal movement, the end stop is SEARCHLIGHT: placed at the connection box, i.e.
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL INSTALLATION SPECIAL PROCEDURES 5.1 IDENTIFYING THE MASTER PANEL NOTE1: Keep communication cables away from all power lines. For the following special procedures, the master panel need to be NOTE2: identified. Treat / regard Shield/Reference as a signal. It shall under no circum- stance be connected to Ground or other Protective Earth potentials.
Page 9
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL SPECIAL PROCEDURES 5.4 RESET OF SEARCHLIGHTS 8. Push power button once to turn on the panel. Check if the searchlight can be controlled on the new address. The procedure can be repeated if necessary. 1.
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL FAULT FINDING 6.1 GENERAL 6.5 PROBLEMS AT INSTALLATION 1. Check which searchlights and from which panels the problem 1. Check correct wiring (A is always connected to A, likewise for B exists on. Can the fault be isolated to a particular searchlight or and Ref.
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL 7 CONNECTIONS, SETTINGS AND INDICATORS 7.1 PANELS CONNECTIONS Versions with phoenix screw terminals: There are 3 different panel models: Connect ‘A/B’ to one pair and ‘Sh1/2’ to one pair. Alternatively: ‘A/B’ 1. TEF 2612 Single (this panel can only control 1 searchlight, search- to one pair, screen to Sh1 or Sh2.
Page 12
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL 7 CONNECTIONS, SETTINGS AND INDICATORS INDICATORS Priority Power btn LED Fault LED Description Fast flash Fast Power on or off. Network error: No messages received. Fast flash Slow Power on or off. Network error: The module receives messages on the bus, but none to its own address.
Page 13
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL CONNECTIONS, SETTINGS AND INDICATORS INDICATORS: Rx (Yellow): shows the activity on the bus, and will flicker at normal bus activity Pwr (Green): light steady when the internal 24VDC is OK. CPU (Green): Priority CPU LED Description Steady on Is on for 5 sec.
Focal point distance: 69 mm (2 3/4”) 69 mm (2 3/4”) 127 mm ( 5”) 127 mm ( 5”) 69 mm (2 3/4”) Tranberg Lamp Part No.: 9400 037 9400 072 9400 072 9400 073 9400 100 Motion (motor unit): Vertical range (positive = up): 50°...
Page 15
COMMANDER SEARCHLIGHT - INSTALLATION AND USER MANUAL TECHNICAL DATA PANEL: Model: 2612, 2613, 2614 Length: 163 mm Width. 96 mm Height: 62 mm Height w/joystick: 105 mm Weight: 360 g Mounting: Flush Input voltage: 12 – 28 VDC Input current (at 24V): max 120mA Ingress protection (DIN40050): IP20...
