- Page 1 Interactive Services - Outdoor Camera IS-OC-1000 User Guide...
-
Page 3: Table Of Contents
Table of Contents CHAPTER 1 INTRODUCTION ..................... 1 Package Contents ......................1 Features ..........................1 LEDs ........................... 2 CHAPTER 2 INITIAL INSTALLATION ................4 Requirements........................4 Procedure ........................... 4 CHAPTER 3 SPECIFICATIONS ................... 6 Hardware features......................6 Software features....................... 7 Regulatory.......................... -
Page 5: Chapter 1 Introduction
Chapter 1 Introduction This Chapter provides an overview of the Outdoor Network Camera's fea- tures and capabilities. Congratulations on the purchase of your new Outdoor Network Camera. The Outdoor Network Camera is a Water/Dust Proof device, which is used for home monitoring and security. Package Contents The following items should be included: •... -
Page 6: Leds
Wireless Adapter User Guide LEDs Front-mounted LEDs The Outdoor Network Camera has 4 LEDs. • Power On (Green)- Power On • Off - Power Off • Flashing - The device is rebooting. • Active Off - No user is viewing the camera. •... - Page 7 Introduction Rear Panel LAN Port Use standard LAN cables (RJ45 connectors) to connect your PCs to these ports. RESET Click this button to setup WPS Auto mode and pin mode, or reset all setting to factory default. After Reset switch is pressed, system will take following actions: •...
-
Page 8: Chapter 2 Initial Installation
Chapter 2 Initial Installation This Chapter covers the software installation of the Outdoor Network Camera. Requirements • Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors. Procedure 1. Choose an Installation Site Select a suitable place to install the Outdoor Network Camera. 2. - Page 9 Initial Installation • The Network LED should be ON (provided the PC is also ON.)
-
Page 10: Chapter 3 Specifications
Chapter 3 Specifications This Chapter provides specifications for the Outdoor Network Camera. Hardware features Feature Description SC1100, ARM9 based, 32bit-192Mhz base clock Hardware MPEG-4 SP/MJPEG Encoders Flash ROM 4 Mbytes SDRAM 32 Mbytes SDRAM DM9102H, Ethernet 10/100BaseT, Auto-MDIX, WiFi IEEE 802.11b/g standard Max 50m line of sight, with no interference External Antenna with 4.2dBi,... -
Page 11: Software Features
Appendix B - About Wireless LANs Built-in Microphone 6mm, – 40 dB + 3db, >55dB Image Sensor Image Sensor Omni Vision OV7740 1/5” CMOS Sensor, Effective Pixels 640x480 (6µm x6µm pixels) Lens F2.0 @ f1.8 Fixed Focus lens (board lens, 3P), 50cm infinity, 60 view angle Viewing Angle Viewing Angle... - Page 12 Wireless Adapter User Guide Internet Explorer 6 and above Browser Support ActiveX 8.0 and above ActiveX Support Audio Audio Compression G.726 (16/32 Kbps), G.711 (64 Kbps) 8 KHz Sampling Rate Events On board video pixel motion detection Internal Motion Detection PIR trigger Trigger HTTP trigger...
-
Page 13: Regulatory
Appendix B - About Wireless LANs Regulatory Regulatory Water-Proof IP65 EMI / EMC FCC, CA, RoHS, WEEE Safety UL2044... - Page 14 Wireless Adapter User Guide This device has been designed to operate with the antennas listed below, and having a maximum gain of [4.2] dB. Antennas not included in this list or having a gain greater than [4.2] dB are strictly prohibited for use with this device. The required antenna impedance is [50] ohms.
