BETCO PeroxiDraw Installation Instructions Manual

™
The PeroxiDraw Dispensing System is a locking dispensing system that allows the user to dispense Green Earth
to six different dilutions and applications safely and effectively. Pretipped to use at the right dilution. Simply hang on the wall and start
using the dispenser.
1.

PARTS CHECKLIST:

ITEM
A.
B.
C.
D.
E.
F.
G.
H.
I.
J.
2. INSTALLATION: (Refer to Figure 1)
Note: All installations must conform with local plumbing codes and use approved backflow preventers. Pressure indicating
tee is to be installed with existing faucets according to local plumbing codes in the state of Wisconsin and any other
state that requires the use of a pressure indicating tee.
A. MOUNTING AND WATER SUPPLY:
Locate mounting holes on a permanent surface. Drill all of the holes into the drywall using a 1/4" diameter bit for use with
the included #10 screw and anchor set. (If mounting the PeroxiDraw
included anchors, drill 1/8" diameter holes.) Insert the anchors into drilled holes and hammer them into the wall until they
are flush with face of wall. Assemble all of the #10 screws with a Phillips screwdriver into the anchors so the screw heads
are sticking out of the wall approximately 1/2". Mount the PeroxiDraw
keyhole slots in the base and tighten the screws.
The water inlet is equipped with a female garden hose fitting (with strainer washer) for attaching a water supply hose. The
water inlet may be removed to permit direct connection to a 3/8" NPT pipe. The unit is designed so water can be supplied to
either side by interchanging the pipe plug with the pipe and female hose fitting. Note: Apply pipe dope, hand tighten, and
then turn 1-1/2 times with a wrench. DO NOT OVER TIGHTEN.
WARNING: Do not use Teflon
I-883
05/05

INSTALLATION INSTRUCTIONS

™
PeroxiDraw Assembly
1/4" ID Vinyl Supply Tubing & Foot Valve Assembly
Ceramic Weight
1/2" ID X 6' Long Vinyl Outlet Tubing (For 4 GPM Station Only)
Outlet Tubing Hanger (For 4 GPM Station Only)
Drip Tray (For 1 GPM Station Only)
#10 Screw & Anchor Kit Set (Total 10 Screws & 10 Anchors)
Metering Tip Kit
Cabinet Lock Keys
Hinge
®
tape to seal internal plastic threads as the extra thickness of the tape
may cause the plastic to crack. Use a non-welding liquid sealant instead.
™
PeroxiDraw Dispenser
DESCRIPTION
™
dispenser to wood and you do not plan to use the
™
dispenser by inserting the screw heads through the
®
Peroxide Cleaner for up
QTY.
1
1
1
1
1
1
1
1
1
8
Pg. 1 of 6
