Summary of Contents for Savi ST-618
-
Page 1: Contents
Installation Guide Savi ST-618 Asset Tag... - Page 2 EchoPoint, Savi, Savi SensorTag, Savi SmartChain, Savi SmartStart, Savi Technology, Savi’s Nested Visibility, SaviTag, SmartChain, the EchoPoint Logo, and the Savi Logo are trademarks or registered trademarks of Savi Technology, Inc. in the United States and other countries. Information in this manual is subject to change without notice and does not represent a commitment from the vendor.
-
Page 3: Table Of Contents
Contacting Savi Support ........13... -
Page 5: St-618 Asset Tag Description
ST-618 Asset Tag Description The Savi ST-618 asset tag is a rugged active RFID tag ideally suited for locating, tracking, and managing medium to high value assets in both defense and commercial applications. The ST-618 carries enough memory to record asset configuration and maintenance records, and is ideal for these functions. -
Page 6: Features
Savi ST-618 Asset Tag Installation Guide Features • ISO 18000-7 compliant active RFID asset tag • 2 Kbytes of memory for recording asset configuration and maintenance data • 400-foot (122m) range for wake-up, collections, and RF write/read operations • Replaceable battery with typical life of five years •... - Page 7 Activating the Tag shown on the tag housing. The tag will not work if you install the battery in the wrong direction (reversed). Turn cap to close Correct battery orientation Whenever a battery is inserted into a tag, the tag will emit 5 beeps. Then, the tag will emit 2 short beeps to indicate adequate battery voltage or 3 short beeps if a fresh battery is required.
-
Page 8: Placing The Tag For Best Performance
Placing the Tag for Best Performance Savi Technology recommends that you mount the tag on a flat surface, with the tag aligned vertically. For best performance, place the tag as high as possible, safe from impact (for example, between the ribs of an ISO-type shipping container), and away from obstructions on the asset. - Page 9 Note: Make sure you clean the surface of the container or other asset before attaching the tag. The tag will have 400-foot (122m) read/write range to Savi SR-650 Fixed Readers. For the most consistent communications with the tag, the Fixed Readers must be mounted: •...
-
Page 10: Mounting The Tag
20 feet (6m) or higher caution: Tags mounted close to the ground may have less range. Follow the instructions in the Savi Fixed Reader documentation to locate and position the Savi Fixed Reader for best performance. Mounting the Tag You can choose among several mounting methods for the tag, including using pressure sensitive tape (PST) or a plastic mounting sleeve. - Page 11 Mounting the Tag Pressure sensitive tape The magnetic mount clamps directly onto the metal surface. The magnets hold the tag securely, but allow the tag and the magnetic bracket to be removed quickly. Once a mounting sleeve is fastened to an asset, you can leave it on the asset even after the tag is removed so it is available for future use with other compatible tags.
-
Page 12: Replacing The Battery
Savi ST-618 Asset Tag Installation Guide Security hole Replacing the Battery The tag is equipped with non-volatile memory, which means stored data is not lost when you replace the battery. Remove the battery cap. Remove the discharged battery from its compartment For more information, see “Activating the Tag”... -
Page 13: Contacting Savi Support
• Call 1-888-994-SAVI (North America only) or 1-650-316-4760 between 5 a.m. and 5 p.m. Pacific time. When you contact Savi Support Services by telephone or email, have the following information available: • Contact information (company name, your name, email, and phone number) •... -
Page 14: Specifications
Savi ST-618 Asset Tag Installation Guide Specifications Model Numbers ST-618-030: Asset Tag ST-618-032: Asset Tag ST-618-032-NSN: Asset Tag with label Physical Dimensions: 6.2 in. (15.8 cm) x 2.1 in. (5.4 cm) x 1.1 Characteristics in. (2.8 cm) Weight: 3.8 ounces (108g) - Page 15 Database memory: Onboard non-volatile user-accessible memory: 2 KB Accessories Mounting: • Pressure sensitive tape • Savi Mounting Kit SRA-1260-Green (sold sepa- rately) • Savi Magnetic Mounting Kit STA-1261-Green (sold separately) Approvals Radio Type Approval: FCC Part 15, EN 300 220 (433...
- Page 16 Savi ST-618 Asset Tag Installation Guide...
