- Page 1 GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual...
- Page 2 "CAUTION: Exposure to Radio Frequency Radiation. Antenna shall be mounted in such a manner to minimize the potential for human contact during normal operation. The antenna should not be contacted during operation to avoid the possiblility of exceeding the FCC radio frequency exposure limit.
-
Page 3: Document History
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) DOCUMENT HISTORY REVISION DATE COMMENTS 2008.01.08 official version (H/W Rev.A1) 2009.04.30 Modified as per H/W Rev.B3 2009.07.20 Modified as per H/W Rev.C1 & FCC... -
Page 4: Table Of Contents
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) Table of Contents DOCUMENT HISTORY..................3 1. Introduction ....................5 2. Systems Configuration ................7 3. Wireless Sensing Unit.................. 9 3.1 Functional Description ................. 9 3.2 How to set the DIP Switch #1 ............. 11 3.3 How to set the DIP Switch #2 ............. -
Page 5: Introduction
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 1. Introduction ® The GreenOK-II Wireless Thermo-Hygro Monitor measures and transmits the temperature and humidity via 2.4GHz Zigbee wireless technology. The Wireless Sensing Units(WSU) can be installed anywhere within a 300 meters radius from the Base Monitoring Unit(BMU). - Page 6 GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) <Figure 1> Photos: Wireless Sensing Unit / Base Monitoring Unit...
-
Page 7: Systems Configuration
User’s Manual (Rev 2.1) 2. Systems Configuration GreenOK-II is composed of Wireless Sensing Unit(WSU) for temperature and humidity monitoring and Base Monitoring Unit(BMU) for displaying the data from wireless sensing unit and Wireless Repeater Unit(WRU) which retransmit the data from WSU. - Page 8 GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) Wireless Sensing Unit Base Monitoring Unit Sensor ID Sensor ID Wireless Repeater Unit Sensor ID <Figure 2> Systems Configuration...
-
Page 9: Wireless Sensing Unit
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 3. Wireless Sensing Unit 3.1 Functional Description SENSOR_ID Shows the current SENSOR ID of the unit. GROUP ID Shows the current GROUP ID of the unit. TEMP/VOLT1 Shows the current temperature, voltage 1 as per operating mode. - Page 10 GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) <Figure 3> Functional Description of Wireless Sensing Unit <Figure 4> DIP Switches and Connectors of Wireless Sensing Unit...
-
Page 11: How To Set The Dip Switch #1
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 3.2 How to set the DIP Switch #1 DEVICE TYPE The DEVICE TYPE can be configured as one of GMS-120ZB, GMS-130ZB and GMS-140ZB as per the sensor connected. The default TYPE is GMS-120ZB. -
Page 12: How To Set The Dip Switch #2
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 3.3 How to set the DIP Switch #2 SENSOR ID The SENSOR ID can be configured as one of 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 and 16. -
Page 13: How To Connect The Sensors
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 3.4 How to connect the Sensors <Figure 7> Connectors of Wireless Sensing Unit... -
Page 14: Base Monitoring Unit
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 4. Base Monitoring Unit 4.1 Functional Description Initialization: Power up the BMU and initialization operation follows. The firmware version displays. The 16 STATUS LED light red and green just one time. - Page 15 GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) TEMP_HIGH / TEMP_LOW Alarm Setting Button To increase or decrease the TEMP_HIGH or TEMP_LOW alarm value, press these buttons until you get the desired values. The default TEMP_HIGH alarm value is 40 .
- Page 16 GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) <Figure 8> Functional Description of Base Monitoring Unit <Figure 9> DIP Switches and Connectors of Base Monitoring Unit...
-
Page 17: How To Set The Dip Switch #1
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 4.2 How to set the DIP Switch #1 DEVICE TYPE The DEVICE TYPE can be configured as one of GMS-220ZB, Repeater and Test Mode as per operation mode. The default TYPE is GMS-220ZB. -
Page 18: How To Set The Dip Switch #2
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 4.3 How to set the DIP Switch #2 GROUP ID The GROUP ID can be configured as one of 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 and 16. -
Page 19: How To Connect The Relay And Ac Adapter
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 4.4 How to connect the Relay and AC Adapter <Figure 12> Connectors of Base Monitoring Unit... -
Page 20: How To Set Temperature Alarm Value
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 4.5 How to set Temperature Alarm Value Press the SET button for 3 seconds until the TEMP_HI and TEMP_LO LED flash simultaneously which showing current temperature alarm values of SENSOR ID 1. -
Page 21: Replacing The Batteries
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 5. Replacing the Batteries This product uses 2 C-size alkaline batteries. If the LED of sensing unit doesn’t blinking for several minutes, follow these steps to replace the batteries; Unscrew the 4 screw of the unit. -
Page 22: Specifications
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 6. Specifications 6.1 GMS-120ZB Item Description Temperature: -40 Measurement range Humidity: 1% ~ 99% RH (Display) Volt: 0.0V ~ 1.500V Temperature: 0.1 Resolution Humidity: 0.1% Volt: 0.001V Temperature: ±0.5 Accuracy Humidity: ±3% RH Volt: 0.005V... -
Page 23: Gms-140Zb
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 6.3 GMS-140ZB Item Description Measurement range Volt: 0.0V ~ 1.500V Resolution Volt: 0.001V Accuracy Volt: 0.005V IEEE802.15.4 Zigbee 2.4GHz ISM Band Radio Specification Channel 11(2405MHz) RF Power: 16dBm DC 3V, 2 C-size Batteries... -
Page 24: Gms-220Zb
GreenOK-II : Wireless Thermo-Hygro Monitor User’s Manual (Rev 2.1) 6.4 GMS-220ZB Item Description 16 units Max. Group ID 16 groups Temperature: -40 ~ 120 Display Range Humidity: 1% ~ 99% RH Volt: 0.0V ~ 1.500V Temperature: 0.1 Display Resolution Humidity: 0.1% Volt: 0.001V...
