Summary of Contents for SPL-Laboratory Mini Bass Meter 2016
- Page 1 2016 Mini Bass Meter User Manual Sound pressure meter with voltmeter function SPL-Laboratory 14.05.2016...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ..........................2 Functions and technical features of the device ................3 Description ........................... 3 Ergonomics ..........................3 Technical features ........................4 Working with the device........................5 Important safety information: ...................... 5 Identifying the functional parts of the device: ................6 Button assignment ........................ -
Page 3: Functions And Technical Features Of The Device
Functions and technical features of the device Description Spl-Lab Mini Bass Meter is a new device for measuring sound pressure and voltage. This device is, probably, the most compact SPL meter of those available on the market today. The uniqueness of this device is in its capability of simultaneously measuring sound pressure and voltage. -
Page 4: Technical Features
Technical features Measured value of direct 1-20 volts* current voltage Measurement accuracy 0.1 dB, 0.1 volt, 1 Hz Data refresh speed 1 second Algorithm Measuring the SPL peak value Mini-USB slot or input for Power connecting to a cigarette lighter socket. -
Page 5: Working With The Device
Working with the device Important safety information: ！ The manufacturer does not bear responsibility for damage, caused directly or indirectly, as a result of improper device use. ！ Before using the device, examine its case for cracks and splits. Any depressurization of the device will result in possible damage. -
Page 6: Identifying The Functional Parts Of The Device
Identifying the functional parts of the device: Number Description of the element Display Functional button #1 Mini-USB slot for auxiliary power supply and updating the firmware Functional button #2 Primary Power socket for connecting the adaptor and measuring voltage Functional button #3 Suction cups for attaching the device to the windshield Sound pressure meter Button assignment... -
Page 7: Hold Mode
Hold mode Press Functional button #2: currently selected hold mode will be displayed. Using buttons #1 & #3, select the required mode according to the table below. For completing this procedure, press Functional button #2. Type of mode Description Peak hold is switched off The maximum pressure and voltage that corresponds to this pressure are being held The maximum pressure and maximum voltage are being held...
