The discharge pipe (D2) from the tundish should:
A) Have a vertical section of pipe at least 300mm long,
below the tundish before any elbows or bends in the
pipework.
B) Be installed with a continuous fall of at least 1 in 200
thereafter.
The discharge pipe (D2) from the tundish should be of metal
or other material that have been demonstrated to be capable
of withstanding temperatures of the water discharged.
The discharge pipe (D2) should be at least one pipe size
larger than the nominal outlet size of the safety device
unless its total equivalent hydraulic resistance exceeds that
of a straight pipe 9m long i.e. discharge pipes between 9m
and 18m equivalent resistance length should be at least two
sizes larger than the nominal outlet size of the safety device,
between 18 and 27m at least 3 sizes larger, and so on. Bends
must be taken into account in calculating the low resistance.
Refer to diagram 1, Table 1 and the worked example. An
alternative approach for sizing discharge pipes would be to
follow BS670 ce of services supplying water for domestic
use within buildings and their curtilages.
The discharge pipe (D2) should terminate in a safe place
where there is no risk to persons in the vicinity of the
discharge. Examples of acceptable discharge arrangements
are:
a. To a trapped gully with the end of the pipe below
the ixed grating and above the water
seal.
b. Downward discharges at a low level; i.e. up to 100mm
above external surfaces such as car parks, hard standings,
grassed areas etc. are acceptable providing that where
children play or otherwise come into contact with
discharges, a wire cage or similar guard is positioned to
prevent contact whilst maintaining visibility.
c. Discharges at a high level; e.g. in to metal hopper
and metal down pipe with the end of the discharge pipe
clearly visible or onto a roof capable of withstanding high
temperature discharges of water and 3m from any plastic
guttering systems that would collect such discharges.
d. Device to warn when discharge takes place.
UNVENTED HOT WATER CYLINDERS
WORKED EXAMPLE
The example below is for G1/2 temperature relief valve with
a discharge pipe (D2) having 4 No. elbows and length of 7m
from the tundish to the point of discharge.
From Table 1:
Maximum resistance allowed for a straight length of 22mm
copper discharge pipe (D2) from a G1/2 temperature relief
valve is: 9.0m. Subtract the resistance for 4 No. 22mm
elbows at 0.8m each = 3.2m. Therefore the maximum
permitted length equates to: 5.8m. 5.8m is less than the
actual length of 7m therefore calculate the next largest size.
Maximum resistance allowed for a straight length of 28mm
pipe (D2) from a G1/2 temperature relief valve equates to:
14m. As the actual length is 7m, a 28mm (D2) copper pipe
will be satisfactory.
TABLE 1
Sizing of copper discharge pipe 'D2' for a temperature
relief valve with a G1/2 outlet size (as supplied).
Maximum length of
Size of
straight pipe
discharge
(no bends or
pipework
elbows)
22mm Up to 9m
28mm Up to 18m
35mm Up to 27m
EHC NEPTUNE 08
Deduct the igure below
from the maximum length
for each bend or elbow in the
discharge pipe
0.8m
1m
1.4m
