- Page 1 Folding Ladies Shopper Bike Assembly Manual 26CF01 Ecosmo Ltd...
-
Page 2: Know Your Bike
Know your bike 1. Wheel 2. Rear Derailleur 3. Chain 4. Crank Set and Chain Guard 5. Pedal 6. Seat Post Clamp 7. Saddle and Post 8. Frame Folding Lock 9. Front Bag ( For demo only) 10. Front Brake 11. - Page 3 • Ecosmo Ltd is not responsible for accidents resulting from failure to comply with all bicycling safety laws, careless driving or improper maintenance of your bicycle.
-
Page 4: Quick Start
Quick start Thanks for purchasing a ladies shopper bike by Ecosmo Bike. Here are some tips to get your new bike set up before riding. It is always advisable to have your bicycle properly assembled by a bicycle professional. This setup and ongoing maintenance will ensure a proper and safe setup and long life for your new bike. - Page 5 Setting up handlebar When setting up the handlebar, insert the stem to the head tube, make sure the front wheel and handlebar are in right positions before you secure the handlebar. Also you can adjust the handlebar to a suitable position by loosing the nut in the third picture.
- Page 6 This bike comes with a kick stand, loose the left side nut on the axle of rear wheel, attach it to the axle of the rear wheel, then put back the nut, tighten it. Connecting the front brake cable First release the front brake cable, then insert the end of cable into the hole of front brake lever, adjust the cable, lock the nuts, finally use Allen Key to set the brake pads to right position.
- Page 7 The angle of the handbrake levers is generally a straight line from your shoulders through your hands to the brakes. Tighten the position of the handbrake levers in this position by tightening the hex nut with a 5mm hex key or allen wrench. Installing the rear rack Your bike comes with a rear rack which should be attached to the seat stay and chain stay and secured by the small bolts.
-
Page 8: Connecting The Pedals
Angle the saddle so that it is parallel to the ground or at a preferred angle for comfort when seated on the bicycle. Tighten the bolts on opposite sides of the seat post connector with a 14mm or adjustable wrench. Alternate sides after each rotation to tighten evenly: tighten one side a full rotation, then the opposite side a full rotation, and vice-versa until each bolt is completely tight and there is no movement in the saddle angle. - Page 9 Thread both pedals into the crank arms as far as you can by hand. Then fully tighten them with a slender adjustable wrench or pedal wrench. Unfolding/folding quick start guide With a little practice, you should be able to fold or unfold your bike quickly and easily.
-
Page 10: Tire Pressure
Finally, remove all the protective materials for delivery and enjoy your new bike. thanks! Thank you for purchasing a Ecosmo Bike! Before using your new bike, please follow the setup steps. Proper operation of your bicycle is important for your safety and enjoyment. To avoid injury and maximize your riding performance and enjoyment, read this manual completely.
