- Page 1 IONizer 4200 Series Hardware Installation Guide Apprion Incorporated March 2009 Apprion Proprietary and Confidential...
- Page 2 Revision History Date Document Revision Author(s) January 09 Version 1 David Cote February 09 Version 2 Updated antenna information David Cote March 09 Updated antenna co-location information David Cote Apprion Proprietary and Confidential...
-
Page 3: Table Of Contents
Conventions ................................... v How to Use this Guide ..............................xv CHAPTER 1 IONIZER DEVICE OVERVIEW ...................... 1 Introduction ................................... 1 IONizer 4200 Series Models ............................1 Safety Information ................................. 1 Compliance ..................................3 CHAPTER 2 INSTALLATION PREPARATION ....................5 Overview ..................................5 Preparation .................................. - Page 4 Table of Contents Directional Antennas .............................. 28 APPENDIX B IONIZER SPECIFICATIONS ......................29 Specifications ................................29 Page iv Apprion Proprietary & Confidential...
-
Page 5: Audience
Apprion Employees (Full time and Contract) This document is a product of the Apprion Engineering team and may be used to help other Apprion employees gain a better understanding of the IONizer installation process. Apprion Services Group This document is intended for use by the Apprion Services Group to aid in the installation of IONizer devices. -
Page 7: How To Use This Guide
How to Use This Guide How to Use this Guide This guide provides detailed instructions on how to install and wire an IONizer device. You should read ALL chapters for important information before attempting the installation. Apprion Proprietary & Confidential... -
Page 9: Chapter 1 Ionizer Device Overview
IONizer Device Overview Introduction This guide provides information on how to install Apprion™ IONizer devices. The IONizer provides an integrated set of modular hardware and software services that facilitate creation, control and monitoring of secure device networks for the modern plant. The IONizer is a wireless transceiver that serves as the center point of an independent wireless network, or as the connection point between wireless and wired networks. - Page 10 IONizer must be installed with a minimum separation distance of 25.26 cm from all persons, except the 16 dBi Sector Antenna (Apprion P/N 89-1186-000) and the 19 dBi Directional Antenna (Apprion P/N 89-1187-000) which must be installed with a minimum separation distance of 48.97 cm from all persons...
-
Page 11: Compliance
This equipment complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device must not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation. Page 3 Apprion Proprietary and Confidential... -
Page 13: Chapter 2 Installation Preparation
4200 Series IONizer 4200 or 4220 Mounting Hardware ( 2 U-bolts with associated hardware, 4 wall anchor bolts) Wire nuts (for 24 VDC installation) Manual Product Registration and Warranty Cards Page 5 Apprion Proprietary and Confidential... - Page 14 Chapter 2 – Installation Preparation Note: IONizer 4200 Series devices have two internally connected WAN and LAN cables routed out of the unit’s conduit opening. In addition, two 24VDC cables are also routed through the same opening. Cables are to be routed through conduit during installation.
-
Page 15: Chapter 3 Installation Guidelines
25.26 cm from all persons, except the 16 dBi Sector Antenna (Apprion P/N 89-1186-000) and the 19 dBi Directional Antenna (Apprion P/N 89-1187-000) which must be installed with a minimum separation distance of 48.97 cm from all persons. -
Page 17: Chapter 4 Mounting Methods
The IONizer can be mounted on vertical poles up to 2 inches in diameter using the U-bolt hardware provided with the device. The device must be mounted in the correct orientation with device connectors on the bottom facing the ground. Page 9 Apprion Proprietary and Confidential... -
Page 18: Mounting Diagram
Phillips head screwdriver Procedure 1. Ensure that the surface is clean and free of loose debris. 2. Use the device as a template using the mounting slots to mark screw locations on the mounting surface. Page 10 Apprion Proprietary & Confidential... - Page 19 4. Mount the device to the surface using the anchor screws and flat washers per manufacturer’s instructions. The flat head washers should be between the unit mounting flange and the anchor screw head. 5. You can also mount the IONizer on rails as shown: Page 11 Apprion Proprietary and Confidential...
-
Page 20: Sealing Antenna Connections
It remains stable over a wide temperature range and degrades very slowly in sunlight. The tape can be removed by cutting it away with a sharp knife. Page 12 Apprion Proprietary & Confidential... -
Page 21: Chapter 5 Grounding And Cabling The Ionizer
This chapter provides grounding and cabling information for IONizers in the 4200 Series. Grounding All IONizers must be properly grounded before making power and signal connections. Apprion recommends a UL Listed #10 AWG wire that is suitable for this purpose, and a ring tongue terminal, Panduit P/N P10-8R or equivalent. - Page 22 Chapter 5 – Cabling the IONizer The bottom of the IONizer may look slightly different depending on the specific model. However, the grounding stud on these models is always basically in the same location. Page 14 Apprion Proprietary & Confidential...
-
Page 23: Ionizer 4200
Two additional wires protrude from the same opening to provide a 24 VDC power option. See “Using 24VDC with an iKIT” in this chapter if you are using the 24 VDC option to power the Ionizer. Page 15 Apprion Proprietary and Confidential... -
Page 24: Using 48V Poe From An Ikit
Using 48V PoE from an iKIT The IONizer can also be connected to an Apprion iKIT which also supplies power and Ethernet. The iKIT provides a convenient way to cable an IONizer especially in areas where power and network cabling is a long distance from the IONizer. - Page 25 Chapter 5 – Cabling the IONizer Note: This iKIT is designed for hazardous locations and has a stainless-steel enclosure. This iKIT must use conduit for ALL connections (not shown in this diagram). Refer to the specific iKIT Installation Guide Page 17 Apprion Proprietary and Confidential...
-
Page 26: Using 24 Vdc From An Ikit
Chapter 5 – Cabling the IONizer for more information. There are also a number of different iKITs available for different applications. Talk to your Apprion Sales Representative. Using 24 VDC from an iKIT The IONizer can be powered by 24 VDC. The 24 VDC wires are hard wired inside the IONizer and protrude from the same conduit opening as the WAN and LAN cables. -
Page 27: Appendix A Approved Antennas
Antennas used with the IONizer must be installed with a minimum separation distance of 25.26 cm from all persons, except the 16 dBi Sector Antenna (Apprion P/N 89-1186-000) and the 19 dBi Directional Antenna (Apprion P/N 89-1187-000) which must be installed with a minimum separation distance of 48.97 cm from all persons. -
Page 28: Approved Antennas
The tape can be removed by cutting it away with a sharp knife. Approved Antennas The following sections provide information on Apprion approved antennas for use with IONizer and provides specifications on each. Omni-Directional Antennas Dual Band Omni (Standard –... - Page 29 Appendix A– Approved Antennas Vertical H-Plane Horizontal E-Plane Page Apprion Proprietary and Confidential...
- Page 30 Gain: 7 dBi at 5150 – 5875 MHz/4.5 dBi at 2400 – 2500 MHz Horizontal/Vertical BW: 30° at 2.4GHz, 15° at 5 GHz Weight: 0.8 lbs. (0.4kg) Dimensions: 27” x 0.6” (685mm x 15mm) Page 22 Apprion Proprietary & Confidential...
- Page 31 Rated Wind Velocity: 125 mph (56 m/sec) Operating Temperature: -40° C min. to +70°C max. Connector: Type N Male Frequency: 2400 – 2485 MHz Gain: 9dBi Vertical BW: 14° Weight: 0.8 lbs. (0.4kg) Dimensions: 27” x 0.6” (690mm x 15mm) Page Apprion Proprietary and Confidential...
- Page 32 Frequency: 4900 – 5875 MHz Gain: 10 dBi 3 dB Beamwidth – Elevation: 8° 3 dB Beamwidth –Azimuth : Omnidirectional Weight: 0.4 lbs. (0.18 kg) Dimensions: 19.6” x 1.0” (497 x 25.4mm) H Plane Page 24 Apprion Proprietary & Confidential...
- Page 33 Appendix A– Approved Antennas E Plane Page Apprion Proprietary and Confidential...
-
Page 34: Polarized Antennas
Gain: 16 dBi Horizontal BW: 120° Vertical BW: 9° Mechanical Downtilt: 30° Weight: 6.65 lbs. (3kg) Dimensions: 33.5 x 6.5 x 2.5” (851 x 165 x 64 mm) Pole Diameter: 1” (25mm) to 2” (50mm) Page 26 Apprion Proprietary & Confidential... - Page 35 Gain: 16 dBi Horizontal BW: 120° Vertical BW: 6° Mechanical Downtilt: 15° Weight: 2 lbs. (1.3 kg) Dimensions: 24.6 x 2.7 x 1.7” (625 x 69 x 43 mm) Pole Diameter: 1.5” (38mm) to 3.5” (89mm) Page Apprion Proprietary and Confidential...
-
Page 36: Directional Antennas
Cross Polarization: 35 dB Front to Back: 30 dB Bracket Tilt: 45° Weight: 17.6 oz. (0.5 kg) Dimensions: 7.5 x 7.5 x 0.8” (190 x 190 x 20 mm) Pole Diameter: 1” (25mm) to 2.5” (64mm) Page 28 Apprion Proprietary & Confidential... -
Page 37: Appendix B Ionizer Specifications
On-chip IEEE 1588 Hardware Assist IEEE 802.11 a/b/g mini-PCI Modules (Typical) Expansion (12C/SSP/2xHSS/2x921K UARTs/USB2) Mechanical Size: IONizer 4200 Series: 11.00 inches (279.4mm) x 11.00 inches (279.4mm) x 4.00 inches (101.6mm) Weight: IONizer 4200 Series: 6 lbs. (2.7 kg) 8 lbs. (3.6 kg shipping weight) - Page 38 European Union EC Declaration of Conformity for all European directives for this product can be Directive Info: found on the Apprion website at www.apprion.com. A hard copy may be obtained by contacting your local sales representative. Page 30 Apprion Proprietary & Confidential...
