Summary of Contents for enware EMF305M
- Page 1 TOUCH-ACTIVATED URINAL FLUSHING SYSTEM - SLIM BUTTON (DUCT ACCESS) Installation & Maintenance Instructions EMF305M I00015 - AUG12 Call 1300 369 273 www.enware.com Enware Australia Pty Limited 9 Endeavour Rd Caringbah NSW 2229 Australia Ph: 02 8536 4000 Fax: 02 8556 4055...
- Page 2 Touch-Activated Urinal Flushing System - Slim Button (Rear Access) EMF305M Enware’s urinal flushing systems provide a neat and reliable flushing solution using piezoelectric technology particularly suited for public access applications. Electronic Flush Valve for urinals, activated by a piezo button that is powered by mains power.
-
Page 3: Installation Instructions
Hydraulic services Consultant and/or Engineer (or other Hydrostatic testing, cleaning & disinfection of water services. personnel appropriately qualified in hydraulic services design) must NOTE: Enware’s WC flushing units have Watermark License to be engaged. ATS5200.020 (For Flushing Valves for Water Closets and Urinals - For use with Mains Supply), ATS5200.030 (Solenoid Valves) and... - Page 4 11. Plug in transformer. Turn on to test the operation of the valve. If the valve clicks and resets, it is working. (FIGURE 1.8) FIGURE 1.5 FIGURE 1.7 FIGURE 1.6 (View from behind wall) FIGURE 1.8 Call 1300 369 273 EMF305M www.enware.com.au...
- Page 5 - Fit air gap to solenoid (use thread tape or similar to seal) Air Gap Air Gap - Fit sparge 25mm pipe to air gap. SINGLE STALL 600 MAX Solenoid TROUGH Air Gap Sparge Nut O-Ring Sparge Pipe www.enware.com.au EMF305M Call 1300 369 273...
-
Page 6: Exploded View
EMDS801 24V Transformer - 1.8M Lead 2m Power to piezo extension cable EMFS300 Switch Piezo 22MM S/S Urinal EMS804 Solenoid 3/8” 24V AC ENMS123 1/2” Strainer EMFS304 Shut off valve EMFS10 1/2” Air Gap Call 1300 369 273 EMF305M www.enware.com.au... -
Page 7: Service And Maintenance
Disconnect flush valve at union and separate from spreader pipe Remove the filter & wash it under running water. It may be necessary to replace the filter (spare parts can be ordered from Enware) www.enware.com.au EMF305M Call 1300 369 273...
