- Page 1 Order Number : GETEC-C1-09-041 FCC Class B Certification Test Report Number : GETEC-E3-09-023 Page APPENDIX H : USER’S MANUAL EUT Type: 32” LCD TV/Monitor FCC ID.: TGELT32U4...
- Page 2 OWNER’S MANUAL OWNER’S MANUAL MT-SYKIT32K1AB Please read this manual carefully before operating your set. Retain it for future reference.
-
Page 3: Warning / Caution
WARNING / CAUTION The lightning flash with arrowhead WARNING/CAUTION symbol, within an equilateral triangle, RISK OF ELECTRIC SHOCK is intended to alert the user to the DO NOT OPEN presence of uninsulated “dangerous voltage” within the product’s enclosure TO REDUCE THE RISK OF ELECTRIC that may be of sufficient magnitude to SHOCK DO NOT REMOVE COVER (OR constitute a risk of electric shock to... - Page 4 (e.g., for watching low-power TV stations, class A or translator stations still broadcasting in analog, watching pre-recorded movies, or playing video game). For more information, please call SOYO, Inc. at 1-866-280-1998, or see www.DTV.gov For converter box information, see www.dtv2009.gov or call the NTIA at 1-888-DTV-2009...
-
Page 5: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. -
Page 6: Important Safety Instructions
Important Safety Instructions 16.To completely disconnect this apparatus from the AC Mains, disconnect the mains plug from the AC receptacle. 17.The mains plug of the power supply cord shall remain readily operable. 18.This apparatus shall be connected to a Mains socket outlet with a protective earthing connection. Prolonged use of headphones at a high volume may cause health damage on your ears. -
Page 7: Table Of Contents
Contents WARNING / CAUTION Important Safety Instructions Contents Accessories Supplied Accessories Installing Batteries Controls And Connectors 10-13 Front Panel Rear Panel Remote Control 12-13 Installation 14-16 Parts for stand assembly Stand Installation Wall mount Installation Desktop Pedestal Installation Connections 17-26 Antenna Connection VCR Connection 18-19... -
Page 8: Contents
Contents CTI(Color Transient Intensity) Flesh Tone Adaptive Luma Control Sound Controls 42-45 Auto Sound Controls Manual Sound Controls Digital Output Auto Volume Control Stereo/SAP Broadcast Setup Time Setting 46-50 Time Zone Setting Auto Time Setting Manual Time Setting Auto On/Off Time Setting Sleep Timer Captions 51-53... -
Page 9: Accessories
Ensure that the following accessories are included with your product. If an accessory is missing, please contact our support department at (866) 280-1998 or contact us through our website located at www.soyo.com/content/Product_Support/147 User must use shielded signal interface cables with ferrite cores to maintain standard compliance for the product. -
Page 10: Controls And Connectors
Controls And Connectors Front Panel SOURCE MENU SOURCE MENU 1. VOL + / VOL - Adjusts menu setting. Adjusts sound level. 2. CH / CH Select a channel. 3. SOURCE Selects the TV, AV, S-Video, YPbPr, VGA or HDMI mode. 4. -
Page 11: Rear Panel
Controls And Connectors Rear Panel COMPONENT IN HDMI/DVI RGB IN AC IN AUDIO IN ANTENNA/ DIGITAL AUDIO S-VIDEO (PC) AV IN (RGB/DVI) CABLE IN OUT(COAXIAL) AUDIO VIDEO VIDEO AUDIO 1. AC IN 6. AV IN This TV operates on an AC power. Connect RCA cable to an appropriate external A/V device such as VCR, DVD or Camcorder. -
Page 12: Remote Control
Controls And Connectors Remote Control - All the functions can be controlled with the remote control handset. - Some functions can also be adjusted with the buttons on the front panel of the set. - Before using remote control handset, please install the batteries. 1. -
Page 13: Controls And Connectors
Controls And Connectors 10. MENU Display on screen menus. 11. MUTE POWER SOURCE Switches the sound on or off. Recalls your preferred picture setting. Recalls your preferred sound setting. 14. SLEEP EXIT Sets the sleep timer. 15. ZOOM Selects your desired picture format. 16. -
Page 14: Installation
Installation Parts for stand assembly Stand Body Stand Base 4 - A type bolts 4 - B type bolts... -
Page 15: Stand Installation
Installation Stand Installation Stand body Stand base 1. Carefully place the product screen side 2. Using the screws provided assemble the down on a cushioned surface that will stand body with the stand base as shown. product and screen from damage. 3. -
Page 16: Wall Mount Installation
Installation Wall mount Installation 4 inches 4 inches 4 inches 4 inches 4 inches The set can be installed on a wall as shown above. For proper ventilation, allow a clearance of 4 inches on all four sides from the wall. Detailed instructions are available from your dealer, refer to the optional Wall Mounting Bracket Installation and Setup Guide. -
Page 17: Connections
Connections Antenna Connection Multi-family Dwellings/ Apartments (Connect to wall antenna socket) AUDIO IN ANTENNA/ DIGITAL AUDIO AV IN (RGB/DVI) CABLE IN OUT(COAXIAL) VIDEO AUDIO Wall Antenna Socket RF Coaxial Wire (75 ohm) Turn clockwise to tighten. Outdoor Antenna Be careful not to bend the bronze wire when connecting to an antenna port. -
Page 18: Vcr Connection
Connections VCR Connection - To avoid picture noise (interface), leaves an adequate distance between the TV and the VCR. When connecting with an antenna 1. Connect the Antenna out socket of the VCR to the Antenna input socket on the TV. 2. - Page 19 Connections When connecting with a S-Video cable 1. Connect the S-VIDEO output of the VCR to the S-VIDEO input on the set. The picture quality is ANT IN improved; compared to normal composite (RCA VIDEO (L) AUDIO (R) cable) input. ANT OUT S-VIDEO OUTPUT...
-
Page 20: Dvd Connection
Connections DVD Connection When connecting with a S-Video cable 1. Connect the S-VIDEO output of the DVD to the S-VIDEO input on the set. ANT IN VIDEO (L) AUDIO (R) 2. Connect the audio outputs of the DVD to the ANT OUT S-VIDEO OUTPUT... - Page 21 Connections When connecting with a HDMI cable 1. Connect the HDMI output of the DVD to the HDMI/DVI IN jack on the set. HDMI-DVD OUTPUT 2. Select HDMI input source with using the SOURCE button on the remote control. 3. Refer to the DVD player's manual for operating instructions.
-
Page 22: Hdstb Connection
Connections HDSTB Connection - This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive Digital signals from a digital set-top box or other digital external device, refer to the figure as shown below. When connecting with a D-Sub 15 pin cable Digital Set-top Box 1. - Page 23 Connections When connecting with a Component cable Digital Set-top Box 1. Connect the video outputs (Y, PB, PR) of the digital set-top box to the COMPONENT (L) AUDIO (R) VIDEO(Y, Pb, Pr) jacks on the set. 2. Connect the audio outputs of the digital set-top box to the COMPONENT AUDIO L, R jacks on the set.
-
Page 24: External A/V Source
Connections External A/V Source 1. Connect the AUDIO/VIDEO jacks between TV and external equipment. Match the jack colors (Video = yellow, Audio Left = white, and Audio VIDEO L-AUDIO-R Right = red) Camcorder Video game set 2. Select the AV input source with using the SOURCE button on the remote control. -
Page 25: Pc Connection
Connections PC Connection When connecting with a D-Sub 15 pin cable 1. Connect the RGB output of the PC to the RGB IN(PC) jack on the set. AUDIO OUT PC OUTPUT 2. Connect the PC audio outputs to the AUDIO IN (RGB/DVI) jack on the set. -
Page 26: Resolution
Connections Resolution Horizontal Vertical Resolution Frequency (kHz) Frequency (Hz) 31.47 59.94 640 x 480 35.16 56.25 800 x 600 37.88 60.32 1024 x 768 48.36 60.00 a. The synchronization input form is separate. b. If the resolution is not supported, ‘Not Support!’ message will be displayed. -
Page 27: Basic Operation
Basic Operation Turning On or Off Standby Setup: The AC power cord must be connected to have the TV in standby mode and ready to be turned on. Press the ON/OFF button on the front panel of the TV to go into standby mode. 1. -
Page 28: Input Selection
Basic Operation Input Selection 1. Press the SOURCE button to change the input mode. Input Source 2. Press the Down or Up button to select your desired mode. S-Video YPbPr 3. Press the OK button to change your selected mode. HDMI Language Selection 1. -
Page 29: On Screen Menus
On Screen Menus Your TV’s OSD(On Screen Display) may differ slightly from what is shown in this manual. 1. Press the MENU button and then use Down or Up button to select each menu. 2. Press the OK button and then Down, Up, Left and Right buttons to navigate to the available menus. Picture Mode F F G G Balance... -
Page 30: Setting Up Tv Channel
Setting up TV Channel Auto Scan Automatically finds all channels available through the Antenna or Cable and stores them in memory on the channel list. 1. Press the MENU button and then press the Down Tuner Mode Cable Video F F G G or Up button to select the TV. -
Page 31: Add/Delete Channel
Setting up TV Channel Add/Delete Channel You can manually store or remove channels in whatever order you desire. 1. Press the MENU button and then press the Down Tuner Mode Cable Video F F G G or Up button to select the TV. Channel Scan Audio Channel Skip... -
Page 32: Epg(Electronic Program Guide)
Setting up TV Channel EPG(Electronic Program Guide) Displays Broadcasting guide of received channel. 1. Press the EPG button to display the Electronic Program Guide. 2. Press the Left or Right button to change channel and display the broadcasting guide at the bottom of the screen. -
Page 33: Picture Controls
Picture Controls Auto Picture Controls Picture Mode adjusts the set for the best picture appearance. Select the preset value in the Picture Mode menu. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. -
Page 34: Manual Picture Controls
Picture Controls Manual Picture Controls You can adjust picture Brightness, Contrast, Saturation, HUE and Sharpness to the levels you prefer. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. Brightness Audio Contrast... -
Page 35: Color Temperature
Picture Controls Color Temperature You can adjust to color temperature you prefer. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. Brightness Audio Contrast Saturation 2. -
Page 36: Advanced Video
Advanced Video Dynamic Noise Reduce Use this feature to reduce picture artifacts caused by the digitizing of image motion content that may be present in the picture. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. -
Page 37: Black Level Extender
Advanced Video Black Level Extender Use this feature to increase the picture reproduction performance in the dark areas of the picture. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. Brightness Audio Contrast... -
Page 38: White Peak Limiter
Advanced Video White Peak Limiter Use this feature to limit excessive amounts of white in bright areas of the picture, this is caused by a lower sync level from a channel being received from the antenna or cable. 1. Press the MENU button and then press the Down Picture Mode User Video... -
Page 39: Cti(Color Transient Intensity)
Advanced Video CTI(Color Transient Intensity) This feature can be used to reduce the time taken to transition from one color to another. The effect will be seen as sharpening the border between colors. 1. Press the MENU button and then press the Down Picture Mode User Video... -
Page 40: Flesh Tone
Advanced Video Flesh Tone In some cases, activation of this feature can result in a more pleasing production of sky and flesh color. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. -
Page 41: Captions
Captions Closed Caption-Analog The Analog Caption function operates when watching regular analog channels. Analog caption displays information at any position on the screen and is usually the program’s dialog. 1. Press the MENU button and then press the Down OSD Language English Video F F G G... -
Page 42: Parental Control
Parental Control Rating Enable/Disable Enables or disables the blocking scheme you set up previously. 1. After inputting the password, press the Down or Program Block Video Up button to choose Program Block. Change Password Audio Clean All 2. Press the OK button and then press the Down or Setup Up button to select Rating Enable. -
Page 43: Tv Ratings For Usa
Parental Control TV Ratings for USA Prevents children from watching certain TV programs, according to the rating limits set. The children rating will not apply to TV programs until you select the ratings you want to be blocked. 1. After inputting the password, press the Down or Program Block Video Up button to choose Program Block. - Page 44 Parental Control TV (FCC) Age Categories TV-MA TV-G Mature audiences only. General audience. This program may contain mature themes, This contains little or no violence, no strong profane language, graphic violence and language, and little or no sexual dialog or situ- explicit sexual content.
-
Page 45: Movie Ratings
Parental Control Movie Ratings Blocks movies according to the movie ratings limits specified so children cannot view certain movies. Applies to movies broadcasted on TV and allows you to select which ratings you want blocked. 1. After inputting the password, press the Down or Program Block Video Up button to choose Program Block. -
Page 46: Tv Rating English For Canada
Parental Control TV Rating English for Canada Selecting canadian english language rating system. 1. After inputting the password, press the Down or Program Block Video Up button to choose Program Block. Change Password Audio Clean All 2. Press the OK button and then press the Down or Setup Up button to select Canadian English Ratings. -
Page 47: Tv Rating French For Canada
Parental Control TV Rating French for Canada Selecting canadian french language rating system. 1. After inputting the password, press the Down or Program Block Video Up button to choose Program Block. Change Password Audio Clean All 2. Press the OK button and then press the Down or Setup Up button to select Canadian French Ratings. -
Page 48: Downloadable Rating
Parental Control Downloadable Rating Your TV’s OSD (On Screen Display) may differ slightly from what is shown in this manual. 1. After inputting the password, press the Down or Program Block Video Up button to choose Program Block. Change Password Audio Clean All 2. -
Page 49: Clean All
Parental Control Clean All Use to quickly clean the Program Block menu options. 1. After inputting the password, press the Down or Program Block Video Up button to choose Clean All. Change Password Audio Clean All 2. Press the OK button and then press the Left or Setup Right button to select OK. -
Page 50: Setting The Pc Mode
Setting the PC Mode Auto Picture Controls Picture Mode adjusts the set for the best picture appearance. Select the preset value in the Picture Mode menu. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. -
Page 51: Manual Picture Controls
Setting the PC Mode Manual Picture Controls You can adjust picture Brightness, Contrast and HUE to the levels you prefer. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. Brightness Audio Contrast... -
Page 52: Color Temperature
Setting the PC Mode Color Temperature Adjusts the display to your desired color temperature. 1. Press the MENU button and then press the Down Picture Mode User Video F F G G or Up button to select the Video. Brightness Audio Contrast Setup... -
Page 53: Auto Adjustment
Setting the PC Mode Auto Adjustment This function is for the automatic adjustment of the screen position, clock, phase and scale in pc mode. The displayed image will disappear for a few seconds while the auto configuration is in progress. Although the image is still not correct, your set is functioning properly but needs further adjustment. -
Page 54: Manual Adjustment
Setting the PC Mode Manual Adjustment If the picture isn’t clear after auto adjustment and especially if characters are still trembling, adjust the picture phase manually. To correct the screen size, adjust Clock. 1. Press the MENU button and then press the Down Picture Mode Custom Video... -
Page 55: Special Functions
Special Functions Picture Format You can watch the screen in various picture formats; 4:3, ZOOM, Auto, Full. If a fixed image is displayed on the screen for a long time, that fixed image may become imprinted on the screen and remain visible. Repeatedly press the ZOOM button to select your desired picture format. -
Page 56: Specification
Specification Model MT-SYKIT32K1AB Horizontal 796.0 mm Dimension Height 583.0 mm Thickness 233.0 mm 14.0 kg Weight Contrast Ratio 1,000:1 typical Brightness 500 cd/m typical Panel Resolution 1366 (H) x 768 (V) Display Color 16.7M colors Audio Output 2.5W + 2.5W... -
Page 57: Troubleshooting
Troubleshooting Problem Check Point No picture on screen. Check whether the set is turned on. Power cord inserted into wall outlet? Test if there is power coming from the wall outlet by plugging in another product into the wall outlet where the set’s power cord was plugged in. - Page 58 Product other than for normal intended use, or other misuse, abuse or negligence to the Product; (3) by the use of parts not man- ufactured or sold by SOYO; (4) by modification of the Product; (5) as a result of service by anyone other than SOYO or a SOYO authorized service provider;...
-
Page 59: Registration Card
IMPORTANT! Please fill out and return within the next 10 days. PRODUCT This is your SOYO Product Registration Card. Proper registration can serve as proof of purchase in the event your original REGISTRATION receipt becomes misplaced or lost. Returning this card will not affect warranty coverage, but may expedite the processing of warranty claims. - Page 60 Required. Post Office will not deliver without proper MARKETING DEPARTMENT postage. 1290 EAST ELM STREET ONTARIO, CALIFORNIA 91761 USA Visit our website at http://www.soyo.com PRODUCT REGISTRATION DEPARTMENT 1290 EAST ELM STREET ONTARIO, CA 91761-4584...
- Page 62 1290 East Elm Street Ontario, CA 91761 United States www.soyo.com A Publicly Traded Company : SOYO Copyright © 2009 SOYO, Inc. All other trademarks and logos are property of their respective owners. All specifications are subject to change without notice.
