12V Lithium 4" CompaCt
Set up and operating inStruCtionS
note: Use with Lithium Battery Pack (SKU 67120) and Lithium Battery Pack Charger
(SKU 67104), both sold separately.
distributed exclusively by harbor Freight tools
Visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
SaVe thiS manuaL.
©
Copyright
2009 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
CirCuLar Saw
3491 Mission Oaks Blvd., Camarillo, CA 93011
®
. All rights reserved. No portion of this manual or any artwork
67431
®
.
Advertisement
Table of Contents
Related Manuals for CHICAGO 67431
Summary of Contents for CHICAGO 67431
-
Page 1: Circular Saw
12V Lithium 4” CompaCt CirCuLar Saw 67431 Set up and operating inStruCtionS note: Use with Lithium Battery Pack (SKU 67120) and Lithium Battery Pack Charger (SKU 67104), both sold separately. ® distributed exclusively by harbor Freight tools 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our website at: http://www.harborfreight.com... -
Page 2: Important Safety Information
Caution, used Inspect Battery Pack before with the safety every use; do not use or charge if alert symbol, indicates a damaged. hazardous situation which, if SKU 67431 For technical questions, please call 1-800-444-3353. Page 2... -
Page 3: General Power Tool Safety Warnings
SKU 67431 For technical questions, please call 1-800-444-3353. Page 3... - Page 4 Liquid ejected from the battery may cause irritation or burns. SKU 67431 For technical questions, please call 1-800-444-3353. Page 4...
-
Page 5: Circular Saw Safety Warnings
(diamond versus SKU 67431 For technical questions, please call 1-800-444-3353. Page 5... - Page 6 Check lower guard for proper or uneven lumber. closing before each use. do not SKU 67431 For technical questions, please call 1-800-444-3353. Page 6...
- Page 7 People with pacemakers should both hands to resist starting torque. consult their physician(s) before Do not leave the tool unattended use. Electromagnetic fields in close when the battery pack is connected. proximity to heart pacemaker could SKU 67431 For technical questions, please call 1-800-444-3353. Page 7...
-
Page 8: Vibration Safety
To reduce vibration, maintain the tool as explained in this manual. If any abnormal vibration occurs, stop use immediately. SKU 67431 For technical questions, please call 1-800-444-3353. Page 8... -
Page 9: Extension Cords
SaVe theSe inStruCtionS. extension Cords note: Extension cords must not be used with this item’s charger. SKU 67431 For technical questions, please call 1-800-444-3353. Page 9... -
Page 10: Specifications
Blades must be rated to at least the maximum speed marked on the tool. SKU 67431 For technical questions, please call 1-800-444-3353. Page 10... -
Page 11: Bevel Adjustment
Wet lumber, green (unseasoned) lumber, and pressure treated lumber all have an increased potential for kickback and should only be cut with a blade designed for cutting that lumber. Wear a NIOSH-approved respirator and have appropriate SKU 67431 For technical questions, please call 1-800-444-3353. Page 11... -
Page 12: Charging Instructions
1/4” or less. Lock depth Knob after adjustment. make sure that all guards are in place and in proper working order. tighten all knobs/bolts, including Blade Bolt, securely. SKU 67431 For technical questions, please call 1-800-444-3353. Page 12... -
Page 13: Maintenance And Servicing
Blocked motor housing vents. Wear ANSI-approved safety goggles and NIOSH-approved dust mask/respirator while blowing dust out of motor using compressed air. Follow all safety precautions whenever diagnosing or servicing the tool. disconnect power supply before service. SKU 67431 For technical questions, please call 1-800-444-3353. Page 13... -
Page 14: Please Read The Following Carefully
Angle support Safety button Rivet Safety button spring Flat washer Tapping screw Angle nut Tapping screw Special bolt Anode connecting line Depth scale Link film support Hex wrench Locking lever Special nut SKU 67431 For technical questions, please call 1-800-444-3353. Page 14... -
Page 15: Assembly Diagram
If product has no serial number, record month and year of purchase instead. note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 67431 For technical questions, please call 1-800-444-3353. Page 15... -
Page 16: Limited 90-Day Warranty
This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 67431 For technical questions, please call 1-800-444-3353. Page 16...
