- Page 3 The following symbols are used to identify important safety information on the product and in this manual: WARNING! Read the safety precautions in this section before installing, powering, operating or servicing this product. After receiving the fixture, please unpack and check if there is any damage due to transportation.
- Page 4 Protection against explosion Shields, lenses and ultraviolet screens must be replaced if they have become visible damaged to such an extent that their effectiveness is impaired. Replace the lamp immediately if it becomes visually deformed, damaged or in any way defected. Protection against injury due to falls Do not lift or carry the fixture alone.
- Page 20 Attached 1 : FINE 354 DG( round body) led wash explosive chart Front cover Lens plate LED board LED Cooling part Middle cover driver board of the fixed board CPU board LED driver board Power supply Power adapter board Power fix board LED display board rear base bracket...
- Page 21 Attached 2 : FINE 354 DG( round body) led wash light luminous chart light output and beam angle range 1 Beam angle 20° Luminance(lux) 7754 1938 mixed white(lux) 1692 red(lux) 2704 green(lux) blue(lux) 3098 white(lux) distance(m) diameter(m) 0.69 1.39 2.08 2.77 3.46 3.46...
- Page 22 light output and beam angle range 2 Beam angle 44° Luminance(lux) 8033 2008 mixed white(lux) 1758 red(lux) 2761 green(lux) blue(lux) 3154 white(lux) distance(m) diameter(m) 1.49 2.99 4.48 5.97 7.46 7.46 mixed white(m) 1.49 2.99 4.48 5.97 7.46 7.46 red(m) 1.49 2.99 4.48 5.97...
