TRAMPOLINE WITH
HANDLEBAR
MODEL NO.:
A024
IMPORTANT! Read
all instructions
carefully before
using this product.
Save this manual for
future reference.
EXERCISE
EQUIPMENT
QUESTIONS:
Contact customer
service at
service@zoovaa.com

USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A024 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Efitment A024

Summary of Contents for Efitment A024

  • Page 1: User Manual

    TRAMPOLINE WITH HANDLEBAR MODEL NO.: A024 IMPORTANT! Read all instructions carefully before using this product. Save this manual for future reference. EXERCISE EQUIPMENT QUESTIONS: Contact customer service at service@zoovaa.com USER MANUAL...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS At Efitment your safety is our top priority and to make sure both you and the unit remain in perfect working order, we encourage you to read all the instructions before assembling and using your new Efitment machine.
  • Page 3 EXPLODED DRAWING...

  • Page 4: Parts List

    PARTS LIST Description Qty. Description Qty. Steel Tube Knob Steel Tube Screw M8*16 Steel Tube Curved Washer ø8 Lower Handlebar Post Screw M8*40 Upper Handlebar Post Rope Handlebar Drag Hook Allen Wrench S=5 Jumping Mat Thread Protector Cap...

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS STEP 1: Lay the Steel Tubes (No.1&2&3）on the floor and assemble in sequence as shown in the picture. STEP 2: Put the Jumping Mat (No.8) on the floor. Turn round steel tube over and place on the Jumping Mat (No.8). Use Drag Hook (No.14) to hook the 32 Ropes (No.13) as shown in drawing.
  • Page 6 STEP 3: Remove 8 Thread Protector Caps (No.16). Screw in the 8 Legs (No.7) clockwise to tighten. Turn the trampoline over. All 8 legs should be locked in place and touching the floor.
  • Page 7 STEP 4: Insert the Lower Handlebar Post (No.4) into the hole of steel tube and secure using the Curved Washer (No.11) and the Screw (No.10). Tighten with Allen Wrench (No.15). Attach Upper Handlebar Post (No.5) to the Lower Handlebar Post (No.4) using Knob (No.9).
  • Page 8 STEP 5: Attach the Handlebar (No.6) to Upper Handlebar Post (No.5) using 1 Curved Washer (No.11) and 1 Screw (No.12). Tighten with Allen Wrench (No.15). The assembly is completed! Before each use, check to make sure all the ropes are secure. If any are loose, use Drag Hook (No.14) to attach the ropes.
