- Page 1 Version 1.11 March 22, 2018 User manual DALIGate DIN DGD-1-DE2DALI, DGD-1-DE4DALI...
-
Page 2: Table Of Contents
Table of contents Visual appearance Specifications Safe operation General information Installation Web interface •ArtNet settings •DALI control •Network settings Operation Technical maintenance Connection scheme... -
Page 3: Visual Appearance
Visual appearance 3 4 5 Pic.1 DALIGate DIN device appearance DMX 512 input Trigger inputs Power input DMX512 terminator LED indicators Ethernet port DALI outputs Fuse Ground terminal Specifications Supported protocols: ArtNet, sACN, DMX512, RDM, DALI Data refresh rate: 44 Hz DMX ports: 1 isolated DMX connectors:... -
Page 4: Safe Operation
Safe operation WARNING! The device uses hazardous voltage AC 230 V In installation, operation, preventive maintenance and repairs of the device, the requirements of the safety rules must be followed. To ensure safe and reliable operation of the devices, please ob- serve the following requirements: •... -
Page 5: Installation
Installation Before mounting and power up, it is necessary to verify protec- tive earthing and cable connections. 1. Ensure the device has no damage due to transportation. 2. Mount device on DIN rail. 3. Connect Ethernet cable. 4. Connect DMX line input (if necessary) and DALI lines outputs. 5. -
Page 6: Artnet Settings
ArtNet settings To access the settings page enter the IP address of the device to the browser. ArtNet settings page will be displayed. Pic.2 ArtNet settings Device name – edit device name; • Device description – editable device description; • Input data protocol –... -
Page 7: Dali Control
DALI control To edit the settings of one of DALI interfaces, click on the link “DALI1 CONTROL” or “DALI2 CONTROL”. Pic.3 DALI control settings Current DALI Network- shows the devices found on DALI line. • Short Address Individual address of DALI device (0-63) Device Type Code of type, returning by device Group... -
Page 8: Network Settings
Network settings To edit the network settings of the device, click on the link “Network Settings”. Pic.4 Network settings Static IP address – main network address of the device; • Subnet mask – the mask of the IP subnet; • Default Gateway –... -
Page 9: Operation
Operation DALIGate devices start their normal operation in a few seconds after they have been powered up. Device always operates based on last saved settings. Viewing DALIGate settings does not affect normal operation until any of the settings have been saved. When changes are saved, the device applies the new settings immediately, without having to power it down. -
Page 10: Connection Scheme
Connection Scheme Ballasts/Drivers with Dimming Control (interface DALI) DALI DALI DALI DALI DALI DALI controllable controllable equipment 1 equipment 2 ArtNet/sACN/Other... - Page 11 Please send all your warranty-related questions to support@sundrax.com All Sundrax products are covered by a 36 months warranty.
- Page 12 Sundrax Electronics, 6008, First Central 200 2 Lakeside Drive, Park Royal, London NW10 7FQ United Kingdom + 44 (0) 208 991 33 19 office@sundrax.com www.sundrax.com...
