Page 1: Front Page
INSTALLATION AND OPERATION MANUAL DIGITAL CLASS-D SINGLE CHANNEL AMPLIFIER SP-DA1000 SP- DA1500 1 / 9... -
Page 2: Important Safety Information
Important Safety Information Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 3: Safety Warning
Safety Warning WARNING! TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. -
Page 4: Table Of Contents
Contents ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐1 Front Page ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Important Safety Information ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Safety Warning Contents-------------------------------------------------------------------------------------------------------------------------------------4 Introduction --------------------------------------------------------------------------------------------------------------------------------5 Front Panel ---------------------------------------------------------------------------------------------------------------------------------6 Rear Panel ----------------------------------------------------------------------------------------------------------------------------------7 Specification -------------------------------------------------------------------------------------------------------------------------------8 Service and Warranty----------------------------------------------------------------------------------------------------------------------9 4 / 9... -
Page 5: Introduction
Introduction Features: Switching power technology digital power amplifier Class-D PA power amplifier of minimum power consumption Less rack space and less heat generation Single channel power amplifier into 19” rack mount unit Rated power output at 1000W, 1500W ... -
Page 6: Front Panel
Front Panel 1. VOLUMN CONTROL 2. LED Indicator Port&Clip Protection indicator will light on in orange once the amplifier comes into protection status. The protection maybe resulted from speaker line short circuit, speaker line open circuit, amplifier overload and inner working temperature over 55℃, this indicator give visually guidance ask for repair and It will light off once these failures been repaired. -
Page 7: Rear Panel
Rear Panel AC POWER CORD AC power cord for input from 110V to 230V, the power cord itself is auto-switching. LINK The line output to next power amplifier to have the same signal input. Signal input The Signal input is used to adjustment the input sensitivity from various inputs so as to have the best response. There are two separate gain control for each channel. -
Page 8: Specification
Specifications Model SP-DA1000 SP-DA1500 Description Single Channel Class-D Power Amplifier Rated Power Output 1000W 1500W Speaker Output 4-16Ω & 100V Frequency Response 40Hz-16KHz (+1/-2dB) Input 1V, 0dBu, Charon connector Input Impedance 10KΩ <0.1% (1KHz/-3dBv, 100W) S/N Ratio >80dB Crosstalk >60dB, 1KHz, Max output... -
Page 9: Service And Warranty
Terms and conditions of warranty for a given product may be determined first by locating the appropriate country which the product was purchased in, then by locating the product type. Guangzhou Surpass Audio Co., Limited No.347 Tiannan Street, Tanshan Village, Hualong, Panyu, Guangzhou, China 511434 Web: www.surpass-audio.com...
