A. Gain CV amount. Amount of gain (amplitude) modulation from the CV input (4), or direct gain control
when no cable is patched in the CV input. When this knob is turned fully clockwise, a CV of +5V yields a
gain of 1 (0dB), and a CV above +5V might cause distortion. Veils does not provide any offset control - a
module like Shades or Blinds can be used to pre-process the gain CV to offset it.
B. Response curve. Continuously variable between exponential and linear. Because the exponential
function grows rapidly, very high gains (above 10) can be achieved with an exponential response curve.
Beware of clipping!

1. DC-coupled signal input.

Accepts audio or CV signals.

2. Signal output.

When no patch cable is plugged into an output, the signal from this channel is routed to
the next channel. For example, when no patch cable is patched into output 1, output 2 will contain the sum
of channel 2 and channel 1. If nothing is patched into outputs 1, 2 and 3, output 4 will contain the sum of
all four channels.

3. Indicator LED.

Brightness represents signal level, and color represents signal polarity (green =
positive).

4. Gain CV input.

Normalized to a constant +8V.
This product is covered by Mutable Instruments' warranty, for one year following the date of manufacture.
This warranty covers any defect in the manufacturing of this product. This warranty does not cover any
damage or malfunction caused by incorrect use - such as, but not limited to, power cables connected
backwards, excessive voltage levels, or exposure to extreme temperature or moisture levels.
The warranty covers replacement or repair, as decided by Mutable Instruments. Please contact our
customer service (support@mutable-instruments.net) for a return authorization before sending the
module. The cost of sending a module back for servicing is paid for by the customer.
Mutable Instruments encourages modding and hacking, but we will not service modified units or provide
any assistance in the realization of mods.
