Avantree BTTC-200X User Manual

1. Product Description
Avantree BTTC-200X is a 2-in-1 Bluetooth stereo audio transceiver, which can
easily switch between receive and transmit modes. With standard 3.5mm audio
jack, it's plug & play, no software installation required. And it is very simple to use
and allows your audio devices to send or receive stereo audio via Bluetooth
wireless.
2. Product Overview
3. Charging
BTTC-200X comes with a built in rechargeable battery that provides a very long
standby time and working time. We recommend charging the battery fully before
using it for the first time.
1) Insert one Micro USB charging cable end to Saturn Micro USB socket, and
put the other end into a standard USB power outlet, such as laptop or
desktop.
2) It takes 3 hours to charge full and reaches its full capacity for the first time.
Each subsequent charge cycle take around 2 hours.
3) LED will indicate red when charging, and goes off when charging is
complete.
4) If you have not used the device for a few months, LED might not turn red
when first charging. It might take 15-35 minutes before the LED turns red.
5) We suggest to fully charge the device at least every two months
Notice:
(1) LED Indicator
(2) Multi-Function Button (MFB)
(Power on / Off / Pairing)
(3) Micro USB charging socket
(4) 3.5 mm audio jack
(5) TX/RX switch button
What's in the box:
Avantree BTTC-200X
3.5mm to 3.5mm audio cable
USB charging cable
User Manual
Warranty card
When battery power is low, the indicator light will flash red. Please recharge
the battery.
3
4. Transmitter, Turn On / Off
Please push the click button to TX mode from TX / RX positon, before power on.
TX or RX mode can not be changed after powering on Saturn.
Turn On: press and hold the MFB button for about 5 seconds until the blue LED
is on for 1 second
Notice: For the first time use or first time turn on after clear connection list, transmitter
Saturn will automatically enter into pairing mode, the LED light flashes blue quickly.
Turn Off: press and hold the MFB button for about 3 seconds until the red LED is
on for 1 second, and then go off.
