HOBO® Plug Load Logger (UX120-018) Manual
HOBO Plug Load Logger
UX120-018
Included Item:
• AC power cord
Required Items:
• HOBOware 3.7 or later
• USB cable (included with
software)
17838-A MAN-UX120-018
The HOBO Plug Load logger is designed to monitor energy consumption of AC-powered plug in
loads. This compact device can be used as a power meter with its built-in LCD for real-time
energy monitoring or as a data logger that can record up to 1.4 million measurements for
analysis. With the ability to view or log true RMS voltage (V), true RMS current (A), active
power (W), active energy (Wh), apparent power (VA), and power factor (PF), the HOBO Plug
Load logger provides you with an accurate log of your energy consumption of plug loads. Using
HOBOware®, you can also easily configure the logger to calculate minimum, maximum, and
average statistics during logging at a fixed sampling rate of 16.67 mS.

Specifications

RMS Voltage Accuracy
RMS Current Accuracy
Active Power Accuracy
Active Energy Accuracy
Power Factor Accuracy
Drift
Resolution
Operating Environment
Operating Modes
Logging Rate
Statistics Sampling Rate
Memory Modes
Start Modes
Stop Modes
Restart Mode
Time Accuracy
Power Source
Battery Life
Memory
Download Type
Full Memory Download Time
LCD
Size
Weight
Ratings
Calibration
0.5% up to 14 Amp continuous; up to 1.0% over 14 Amp when equipment
being monitored is at 100% duty cycle
0.5% up to 14 Amp continuous; up to 1.0% over 14 Amp when equipment
being monitored is at 100% duty cycle
0.5% up to 14 Amp continuous; up to 1.0% over 14 Amp when equipment
being monitored is at 100% duty cycle
0.5% up to 14 Amp continuous; up to 1.0% over 14 Amp when equipment
being monitored is at 100% duty cycle
±0.02
Up to 0.5% typical within 1 year
1 Watt Load at 120 V AC 15 Amp
Logging: 5° to 40°C (41° to 104°F); 0 to 95% RH (non-condensing), up to
2,000 m (6,562 ft) altitude
Meter or logging when launched with HOBOware
1 second to 18 hours, 12 minutes, 15 seconds
60 Hz or 16.67 mS single-cycle
Wrap when full or stop when full
Immediate, push button, date & time, or next interval
When memory full, push button, or date & time
Push button
±1 minute per month at 25°C (77°F), see Plot A
Line-powered with 0.92 m (3 ft) AC power cord or two AAA 1.5 V alkaline
batteries, user replaceable
2 years with line power; 6 months battery only (no line power) with
logging rate of 1 minute or greater operating at 25°C (77°F)
4 MB (1.4 million measurements, maximum)
USB 2.0 interface
Approximately 1.5 minutes
LCD is visible from 0° to 50°C (32° to 122°F); the LCD may react slowly or
go blank in temperatures outside this range
13.97 x 7.62 x 4.75 cm (5.5 x 3 x 1.87 in.)
230.8 g (8.14 oz)
IP50; UL Listed; UL Listed to Canadian safety standards
This device has been calibrated using equipment that has been tested in
accordance with ANSI C12.20 0.5%.
