Onset T-VER-E50B2 Installation Manual

onset
®
T-VER-E50B2
FCC PART 15 INFORMATION
Note: This equipment has been tested by the manufacturer and found to comply with the
limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when this
equipment is operated in a residential environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference in
which case the user will be required to correct the interference at his own expense.
Modifications to this product without the express authorization of Veris Industries
nullify this statement.
For use in a Pollution Degree 2 or better environment only. A Pollution Degree 2
environment must control conductive pollution and the possibility of condensation or
high humidity. Consider the enclosure, the correct use of ventilation, thermal properties
of the equipment, and the relationship with the environment. Installation category: CAT
II or CAT III
Provide a disconnect device to disconnect the meter from the supply source. Place this
device in close proximity to the equipment and within easy reach of the operator, and
mark it as the disconnecting device. The disconnecting device shall meet the relevant
requirements of IEC 60947-1 and IEC 60947-3 and shall be suitable for the application. In
the US and Canada, disconnecting fuse holders can be used. Provide overcurrent
protection and disconnecting device for supply conductors with approved current
limiting devices suitable for protecting the wiring. If the equipment is used in a manner
not specified by the manufacturer, the protection provided by the device may be
impaired.
This symbol indicates an
electrical shock hazard exists.
14724-D PAGE 1
Veris and the Veris "V" logo are trademarks or registered trademarks of Veris Industries, L.L.C. in the USA and/or other countries.
1.800.561.8187
POWER MONITORING
Documentation must be consulted where
this symbol is used on this product.
© 2011–2013 Veris Industries and Onset Computer Corporation
Onset, HOBO, HOBOware, and HOBOlink are trademarks or registered trademarks of Onset Computer Corporation.
www.
T-VER-E50B2
Compact Power and Energy Meter
Installer's Specifications
Measurement Accuracy:
Real Power and Energy
Reactive Power and Energy
Current 0.4% (+0.015% per °C deviation from 25°C) from 5% to 100% of range;
0.8% (+0.015% per °C deviation from 25°C) from 1% to 5% of range
Voltage 0.4% (+0.015% per °C deviation from 25°C) from 90V (L-N) to 600VAC (LL)
Sample Rate
Data Update Rate
Type of Measurements
Input Voltage Characteristics:
Measured AC Voltage
Metering Over Range
Impedance
Frequency Range
Input Current Characteristics:
CT Scaling
Measurement Input Range
Impedance
Control Power:
AC
DC*
Ride Through Time
Output:
Maximum Pulse Output
Amp Hour
Real/Reactive Energy
Pulse Contacts
Mechanical Characteristics:
Weight
IP Degree of Protection (IEC 60529)
Display Characteristics
Terminal Block Screw Torque
Terminal Block Wire Size
Rail
Environmental Conditions:
Operating Temperature
Storage Temperature
Humidity Range
Altitude of Operation
Metering Category:
North America CAT III; for distribution systems up to 347 V L-N/600VAC L-L
CE
Dielectric Withstand
Conducted and Radiated Emissions
Conducted and Radiated Immunity
Safety:
North America (cULus)
Europe (CE)
* External DC current limiting is required, see fuse recommendations.
information@itm.com
.com
INSTALLATION GUIDE
IEC 62053-22 Class 0.5S, ANSI C12.20 0.5%
IEC 62053-23 Class 2, 2%
2520 samples per second
True RMS up to the 21st harmonic 60 Hz,
One to three phase AC system
Minimum 90VL-N (156VL-L) for stated accuracy
UL Maximums: 600V
CE Maximums: 300V
2.5 MΩ (L-N)/5 MΩ (L-L)
Primary: Adjustable from 5 A to 32,000 A
0 to 0.333VAC or 0 to 1.0VAC (+20% over-range)
10.6kΩ (1/3 V mode) or 32.1kΩ (1 V mode)
5VA max.; Minimum 90VAC,
UL Maximums: 600V
CE Maximums: 300V
3W max.; UL and CE: 125 to 300VDC
100 msec at 120VAC
N.C., static output (30VAC/DC, 100mA max. @ 25°C,
derate 0.56mA per °C above 25°C)
N.O., static output (30VAC/DC, 100mA max. @ 25°C,
derate 0.56mA per °C above 25°C)
0.62 lb (0.28 kg)
IP40 front display; IP20 Meter
Back-lit blue LCD
0.37 ft·lb (0.5 N·m) nominal/0.44 ft-lb (0.6 N·m) max.
26 to 14 AWG (0.13 to 2.08 mm2)
T35 (35mm) DIN Rail per EN50022
<95% RH (non-condensing)
CAT III; for distribution systems up to 300 V L-N
Per UL 508, EN61010
FCC part 15 Class B, EN55011/EN61000 Class B
(residential and light industrial)
EN61000 Class A (heavy industrial)
UL508 (open type device)/CSA 22.2 No. 14-05
EN61010-1:2001
1 sec
(347V )
L-L L-N
(520V )
L-N L-L
+20%
45 to 65 Hz
(347V ),
L-L L-N
(520V )
L-N L-L
50 Hz
-30° to 70°C
-40° to 85°C
3 km max.
