Juna JRDAB-02 Quick Manual

Dab/dab+ radio for rns 510

Hide thumbs Also See for JRDAB-02:

JRDAB-02

DAB+/DAB Radio for CAR

1.Introduction

JRDAB-02 device is a DAB/DAB+ radio receiver. It is designed

to receive digital radio stations in vehicle equipped with digital

sound system. JRDAB-02 supports the "following service"

function.

WARNING!

To start listening of digital radio stations from DAB/DAB+ radio receiver,

press the MEDIA button on control panel and select MDI from display

by touch screen.

JuNa

PPHU

ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND

QUICK MANUAL

RNS 510

JRDAB -02 device is controlled from RNS control panel buttons

and touch screen.

Fig.1

Manufacturer

Model:

JRDAB-02_C_V3.0_CAN

Fig.1

www.juna.pl

Table of Contents

Do you have a question about the JRDAB-02 and is the answer not in the manual?

Page 1 JRDAB-02_C_V3.0_CAN DAB+/DAB Radio for CAR QUICK MANUAL RNS 510 1.Introduction JRDAB-02 device is a DAB/DAB+ radio receiver. It is designed to receive digital radio stations in vehicle equipped with digital sound system. JRDAB-02 supports the "following service" function. 2.Start Up...
Page 2 Fig.3 Fig.2 Fig.3 4.Searching process There are three possibilities for scan process: 1. First press “WYBOR” button, then press SCAN button. Fig.4 and Fig.5 Fig.4 Fig.5 JuNa PPHU Manufacturer www.juna.pl ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND...
Page 3 3. It is the fastest way to start SCAN process. Only press knob located on right side of control panel. Fig.7 Fig.7 Warning! When received station has poor quality Signal, sound can disappear for short moments or completely. JuNa PPHU Manufacturer www.juna.pl ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND...
