Summary of Contents for DAVIS 6331
- Page 1 USER MANUAL Sensor Transmitter Product numbers 6331 & 6332 Davis Instruments, 3465 Diablo Avenue, Hayward, CA 94545-2778 U.S.A. • 510-732-9229 • www.davisinstruments.com...
-
Page 2: Fcc Part 15 Class B Registration Warning
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved in writing by Davis Instruments may void the user's authority to operate this equipment. - Page 3 E N S O R R A N S M I T T E R S A C -P OL A R OWE R E D AN D OWE RE D The Sensor Transmitter enables you to create a customized wireless sensor station that can communicate directly with your Vantage Pro2 console, Vantage Connect, or WeatherLink Live.
- Page 4 Prepare the Sensor Transmitter The illustration below shows the sensor interface inside the Sensor Transmitter. 3-Volt Battery Lithium Battery Pull Tab Test LED DIP Switches SENSOR SENSOR INTERFACE INTERFACE MODULE MODULE TEMP TEMP RAIN RAIN WIND WIND Cable Clamp Cable Clamp Mount Square Black Grommets AC- Power...
-
Page 5: Set The Transmitter Id
Set the Transmitter ID Each wireless transmitter (such as a Vantage Pro2 sensor suite or a Sensor Transmitter) must be set to a different one of eight transmitter IDs. Set the transmitter ID using the DIP switches inside the sensor interface. DIP switches #1, 2 and 3 allow you to control the ID —... - Page 6 (73 m), maximum wind speed may be less than 100 mph (161 kph). Note: Not all cables are compatible with your system. To be sure they will work, order Davis extension cables from your dealer or directly from Davis Instruments.
- Page 7 Test Transmission from Proposed Location It is very important to test reception from the proposed location before permanently mounting the sensor and Sensor Transmitter. Place the Sensor Transmitter at the intended mounting site, or have someone hold it there, so you can walk around with the console/receiver for a few minutes. Rotating the antenna may help to improve reception.
- Page 8 Mount the Sensor Transmitter You can mount the Sensor Transmitter on a pole or on a vertical surface such as a post or wall. Note: If using the solar-powered model, remember to position the shelter so the solar panel has maximum exposure to the sun Mounting on a Pole 1.
-
Page 9: Installing Sensors
Installing Sensors Using the Sensor Transmitter with a Vantage Pro2 Console You can use a Sensor Transmitter with a Vantage Pro2 console to install the anemometer at a distance from the rest of the sensor suite, or to add a temperature station or a temperature/humidity station. -
Page 10: A Note On Securing Cables
Install the Sensor(s) Install the sensors as described in User Guide that came with the sensor. Note: User Guides are available on our website in the Support Section, or on each product’s description page. Anemometer: You can use the anemometer that came with your Vantage Pro2 sensor suite or use Anemometer (#6410). -
Page 11: Troubleshooting
4. There is a problem with the receiver. See “Contacting Davis Instruments” on page 10. Note: Remember to turn the Test DIP switch OFF when you’re finished testing wireless transmission. -
Page 12: Contacting Davis Instruments
Contacting Davis Instruments For questions about installing or operating your Sensor Transmitter please contact Davis Technical Support. We’ll be glad to help. Online www.davisinstruments.com See the Weather Support section for copies of user manuals, product specifications, application notes, software updates, and more.
