The ConsoleLink Transmitter (Tx) connects to a host Weather Monitor II,
Weather Wizard II & III, or Perception II. The ConsoleLink Tx transmits
weather data from your host station to other DavisTalk™ compatible consoles
and receiving units. This allows you to send weather data to one or more loca-
tions without using any wires.
Providing you have the necessary sensors, the ConsoleLink Tx will send the
following weather data:
Inside Temperature
Inside Humidity
Outside Temperature
Outside Humidity
Rainfall
Wind Speed
Wind Direction
Barometer
The ConsoleLink Tx is user-configurable to communicate on one of 8 different
ID codes. This allows multiple systems to coexist in the same geographical
area. The unit includes a pass-thru connector so that a WeatherLink data logger
can still be used with the host station.
Note: The ConsoleLink Tx operates on a low power frequency that does not require you to obtain an
FCC license.
C
O N S O L E
I
N S T A L L A T I O N
Weather Monitor
II
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
L
I N K
M
A N U A L
Weather Wizard
II and III
Yes
No
Yes
No
Yes
Yes
Yes
No
Perception
Yes
Yes
No
No
No
No
No
Yes
Product # 7617

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ConsoleLink and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DAVIS ConsoleLink

  • Page 1 The unit includes a pass-thru connector so that a WeatherLink data logger can still be used with the host station. Note: The ConsoleLink Tx operates on a low power frequency that does not require you to obtain an FCC license.
  • Page 2 Through trees and foliage: 100 to 400 feet (30 to 120 m) Setting the ID Code The ConsoleLink Tx may be set to use any of eight selectable ID codes (the default is ID Code #1). The transmitter and receiver will only communicate with each other if they are both set to the same ID code.
  • Page 3 Powering Up the ConsoleLink Tx To power up the ConsoleLink Tx, apply power to your host weather station. If the ConsoleLink Tx is working properly, it will make a single or double beep about 30 seconds after the weather station is energized. The single beep indi- cates that the unit is working properly and that no WeatheLink data logger is connected to the unit.
  • Page 4 Shielded cables and I/O cords must be used for this equipment to comply with the relevant FCC regulations. Changes or modifications not expressly approved in writing by Davis Instruments may void the user's authority to operate this equipment. Product Number: 7617...
