Bizerba CS 300 Operating Instructions Manual

Checkout scale
Hide thumbs
Table of Contents

Advertisement

Quick Links

CS 300
Checkout Scale
Operating instructions
as of program version 4.42
6.110.98.5.01.40 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Bizerba CS 300

Summary of Contents for Bizerba CS 300

  • Page 1 CS 300 Checkout Scale Operating instructions as of program version 4.42 6.110.98.5.01.40 en...
  • Page 2 All rights reserved Tous droits réservés Reservados todos los derechos Tutti i diritti riservati © 07 / 2015 Bizerba GmbH & Co. KG, 72336 Balingen P.O. Box 10 01 64 72301 Balingen, Germany Telephone (+49 7433) 12-0, Fax (+49 7433) 12-2696 Email: marketing@bizerba.com...
  • Page 3 Chapter index About these instructions About the device Safety instructions Installation Device and operating controls Operation Programming Troubleshooting Maintenance Technical data Subject index Appendix 6.110.98.5.01.40 en...
  • Page 4 6.110.98.5.01.40 en...

  • Page 5: Table Of Contents

    4.2.3 Installation between Bizerba devices and devices from other man- ufacturers ........... . 4 - Start-up .
  • Page 6 Set-up scale CS 300 TM ........4 - Connecting the scale CS 300 TM ......4 - 4.5.2...
  • Page 7 Calling up logbook entries with P displays..... . 7 - 10 Calling up logbook entries on CS 300 SD ..... . 7 - 11 Calling up logbook entries with WS display .
  • Page 8 Subject index ............11 - Appendix Declaration of conformity CS 300 0 - 4...

  • Page 9: About These Instructions

    These operating instructions explain how to operate and set the device. Bizerba products undergo continuous further development and are subject to different country-specific regulations. Examples of pictures and graphics included in these instruc- tions may vary from the version you have received.

  • Page 10: Symbols Used

    About these instructions Operating instructions CS 300 Symbols used Various symbols are used in these instructions. Icon Meaning Text with arrow prompts you to carry out an action. <Key> Text within < > refers to a key. <Key> + <key>...

  • Page 11: Warnings

    Operating instructions CS 300 About these instructions Example: Pr101..00 Example Description Display Pr 1 Menu (program) "Pr1" Program number "01" Menu setting "00" Warnings Warnings are divided into danger levels by the signal word above the warning symbol. Structure of warnings and meaning of signal words are described in these instructions as follows.
  • Page 12 About these instructions Operating instructions CS 300 CAUTION Source of danger with slight risk with potentially threatening dan- ger for personnel! The consequences can be: injuries, damage to property. – Measures to avoid the danger are specified. CAUTION Source of danger, improper use! Damage to property can result.

  • Page 13: About The Device

    For different installation situations at single POS workstation the CS is available in various models. CS 300 TE built-in tabletop model CS 300 TE tabletop model Fig. 1: CS 300 TM / TE CS 300 ER built-in with roller conveyor Fig. 2: CS 300 ER CS 300 MA 84 integrated in Datalogic 8300 / 8400 scanners Fig.

  • Page 14: Accessories

    CS 300 MA 94 integrated in scanner. Fig. 5: CS 300 MA 94 Accessories Bizerba offers a wide range of accessories for this device. For further information, please contact your Bizerba specialist. Intended use The CS cash register scale in conjunction with a cash register (POS) system has been de- signed for checkout operations.
  • Page 15 Operating instructions CS 300 About the device Fig. 6: Example of an identification plate Explanations of the individual labels with example values: CS 300 Type designation BIZERBA Manufacturer 11047xxxxx Identification plate no. CE 05 CE identification with the last two digits of the year in which the CE certification was applied.

  • Page 16: Verification-Related Notes

    Scales that are connected on site to an additional device must have the conformity valua- tion carried out either by the responsible verification office or by a Bizerba verification engi- neer. Scales as well as the additional device must be tested and verified. If the scale with add.
  • Page 17 (installation and commissioning). A yellow mark of conformity is affixed to the load receptor of the scale, with the inscription "Gesichert von BIZERBA" (for these scales the valu- ation of conformity has been carried out by Bizerba). Verifications must be carried out by the operator of the scale according to the legal re- quirements.

  • Page 18: Standards And Guidelines

    About the device Operating instructions CS 300 Standards and guidelines Measuring technology Directive 2009/23/EC Scale directive "non-automatic scales" DIN EN 45501 Metrological aspects of non-automatic scales. OIML R76-1 OIML- recommendation for non-automatic scales. Organisation internationale de métrologie légale Nonautomatic weighing instruments WELMEC 2.3...

  • Page 19: Operating Conditions

    Changes to the devices require prior written consent of Bizerba. External data dialog between Bizerba equipment and third-party devices, the hardware and software re- quired as well as test and modification work must be clarified with Bizerba in writing. Please contact the responsible Bizerba customer service department if you have any doubts concerning the practical application of these conditions.

  • Page 20: Warranty

    Bizerba device. Warranty Installation, commissioning and initial training must be carried out by trained Bizerba sales office or customer service personnel, or by companies commissioned by Bizerba. Bizerba is not responsible for damages caused by: –...
  • Page 21 Operating instructions CS 300 About the device Bizerba and its dealers are naturally willing to take back these defunct old devices. Please contact your specialist in these cases. If your device contains a rechargeable battery, you are required by the Battery Ordinance to return the used battery to the dealer or the public return points provided for this purpose.
  • Page 22 About the device Operating instructions CS 300 2 - 10 6.110.98.5.01.40 en...

  • Page 23: Safety Instructions

    Operators (purchasers) as well as supervisory and operating staff must carry out program- ming and data protection on Bizerba systems and devices exclusively in accordance with the Bizerba operating and programming instructions. Only use equipment for its intended purpose.

  • Page 24: Plates On The Device

    Safety instructions Operating instructions CS 300 WARNING Opening the device! – Opening the device must be carried out by trained and qualified Bi- zerba personnel only. Repair or service works on scanner! – Repairs or services to the optical scanner unit are only performed by the responsible cash-desk or scanner supplier.

  • Page 25: Installation

    Route the cables in a way that no mobile parts get into contact with the system. Bizerba products undergo continuous further development and are subject to different country-specific regulations. Pictorial and graphic examples in the installation and assembly instructions may differ from the supplied version.

  • Page 26: Installation And Assembly

    Installation Operating instructions CS 300 Installation and assembly The weighing system is firstly installed in the scanner by the POS or scanner supplier and then assembled to the POS counter on site. The cover plate of the scanner serves as the load platter.

  • Page 27: Mains Supply

    4.2.3 Installation between Bizerba devices and devices from other manufacturers Installation must be carried out by a specialist and is usually done by the Bizerba service. Start-up Putting into operation, as well as instruction on the operation, cleaning, maintenance and servicing is carried out by the relevant Bizerba customer services office or the Bizerba trade consultant.

  • Page 28: Checking The Scale For Freedom Of Movement

    Installation Operating instructions CS 300 4.3.2 Checking the scale for freedom of movement Center of load platter Display Preparation Connect the display. Connect the power supply to the scan- ner. Set the display to zero with the push- button Fig. 8: Check Check Place maximum load (6 kg or 15 kg) in the center of the load platter.

  • Page 29: Decommissioning

    Mounting the device Unpacking Open packaging, remove accessories and lift the device carefully out of the packaging. 4.5.1 CS 300 TM The CS 300 TM (tabletop model) is placed on the POS counter. Length: 340 mm Width: 275 mm Construction...

  • Page 30: Set-Up Scale Cs 300 Tm

    Spirit level Connector for power supply Display connector POS connector Strain relief (disc) Fig. 12: Cable connections CS 300 TM Lay and connect cables. Route POS cable properly and connect it to scale. Route display cable properly and connect it to scale.

  • Page 31: Installation Of Scale Cs 300 Te In The Pos Counter

    Place all cables under relief strain Screw the relief strain directly under the scale. The cables are now strain-relieved. 4.5.2 CS 300 TE The CS 300 TE (built-in tabletop model) is intended for installation in POS counter. Scale dimensions Length: 335 mm Width:...
  • Page 32 Installation Operating instructions CS 300 Take note: – Cables must not touch movable parts of the scale. – Prevent accumulation of dirt between the mounting frame and load platter. (Weight falsification) Make sure that the scale has a free play.

  • Page 33: Connecting The Scale Cs 300 Te

    Screw the relief strain directly under the scale. The cables are now strain-relieved. 4.5.3 CS 300 ER-K THe CS 300 ER-K (Built-in rollerconveyorCompact) is designed for installation in POS counter and for attachment of coller conveyor.. 6.110.98.5.01.40 en 4 - 9...

  • Page 34: Installation Of Scale Cs 300 Er-K Into Pos Counter

    Pay attention to the position. The cutout is asymmetric. Fig. 18: Dimensions CS 300 ER-K Installation of scale CS 300 ER-K into POS counter Requirements The mounting area or cutout in the POS counter should be dimensioned so as to provide a distance of min.
  • Page 35 POS counter or max. 2mm higher Reattach the roller conveyor. Check the installation and adjust if nec- essary. The scale can be fastened with fastening screws. Fig. 19: Installing CS 300 ER-K 6.110.98.5.01.40 en 4 - 11...

  • Page 36: Connecting The Scale Cs 300 Er-K

    Installation Operating instructions CS 300 Connecting the scale CS 300 ER-K Scale cable Connector for power supply POS connector Display connector Lay and connect cables Route display cable properly connect it to electronics box. Route POS cable properly and con- Fig.
  • Page 37 The weighing system was preset and verified during manufacture. It is conform with the verification regulation. The weighing system CS 300 MA 84 is firstly mounted to the scanner by the POS or scan- ner supplier and then installed into the POS counter on site.

  • Page 38: Mounting The Weighing System Cs 300 Ma 84

    Installation Operating instructions CS 300 Mounting the weighing system CS 300 MA 84 The scanner must not be connected. – Unplug scanner. – Please observe the scanner operating instructions . CAUTION No correct cable routing when inserting the weighing system into a scanner! Cables get into contact with mobile parts of the weighing system.
  • Page 39 Operating instructions CS 300 Installation Connect cable from weighing system to adapter. Fig. 25: Cable from weighing system Weighing system Adapter Cable from weighing system Connect cablefrom weighing system with adapter Installation of weighing system into scanner CAUTION Wrong screws for weighing system! The weighing system will be damaged.

  • Page 40: Installation Of Scanner With Weighing System Into Pos Counter

    Installation Operating instructions CS 300 Never lift the weighing system at the load arms. Scanner Weighing system 4 Fastening screws Carefully insert weighing system into scanner Screw weighing system to the scan- using 4 fastening screws (torque 6-7 Nm). Fig. 26: Installation of weighing system CS...
  • Page 41 Please make sure that the load platter is on the same height level as the POS counter. Fig. 29: Installation of CS 300 MA 84 in POS counter Adjust load platter Place the load platter on the load platter supports of the weighing system.

  • Page 42: Leveling

    (RJ-45 socket). Route POS counter cable properly and connect it to weighing system (SUB-D socket). Fig. 31: Connectors CS 300 MA 84. 4.5.5 CS 300 MA 94 The scanner is designed for mounting of weighing system. See instructions provided by scanner manufacturer.
  • Page 43 Operating instructions CS 300 Installation Load platter Scanner Threaded holes for weighing system Fig. 32: Scanner and load platter MA 94 Load platter holders Remove all four load platter holders from teh bottom of the load platter . Use a suit- able screwdriver (currently: Torx TX10, sub- ject to change).

  • Page 44: Mounting The Weighing System

    The weighing system was preset and verified during manufacture. It is conform with the verification regulation. The weighing system CS 300 MA 94 is firstly mounted to the scanner by the POS or scan- ner supplier and then installed into the POS counter on site.
  • Page 45 Operating instructions CS 300 Installation Bizerba products are subject to constant further development and various country-specific regulations. In order to guarantee that the weighing system is still conform with these regulations after installation into scanner and complete scanner scale into POS counter, the points descri- bed in these installation and assembly instructions must be absolutely adhered to.

  • Page 46: Installation Of Scanner Into Pos Counter

    Installation Operating instructions CS 300 Fig. 37: Connecting cable leading to scanner MA 94 Properly route connecting cable of the scale electronics in the holders back of scanner Route connecting cable on back of scanner and insert it into the "SCALE HOST PORT"...
  • Page 47 Installation For installing and deinstalling the scanner adhere to the installation in- structions of the scanner manufacturer. Dimensions of scanner with weighing system Fig. 39: Dimensions CS 300 MA 94 Installation Remove load platter Lift scanner using the handles place scanner into cut-out of POS coun- Reattach load platter and check clear- ance.

  • Page 48: Leveling

    Installation Operating instructions CS 300 Distance to POS counter When installing the scanner in the POS counter, make sure that there is a clear- ance of 2-3 mm between load platter and lateral limitations of the POS coun- ter on all sides.

  • Page 49: Connect

    Operating instructions CS 300 Installation Connect Lay and connect cables. Connectors Display connection POS connection USB connection A cable with USB A connector for cash drawer and 5-pin mini USB B connector for scale is required. A software must be installed on the POS system which cre- ates a virtual COM interface.

  • Page 50: Mounting The Weighing System Cs 300 Ma 98

    Load arms Weighing system Fig. 45: Load arms Bizerba products are subject to constant further development and various country-specific regulations. In order to guarantee that the weighing system is still conform with these regulations after installation into scanner and complete scanner scale into POS counter, the points descri- bed in these installation and assembly instructions must be absolutely adhered to.
  • Page 51 Operating instructions CS 300 Installation Pictorial and graphic examples in the installation and assembly instructions may differ from the supplied version. Installation into scanner Carefully insert weighing system into scanner Screw weighing system to the scanner using 4 fastening screws...

  • Page 52: Installation Of Scanner With Weighing System Into Pos Counter

    Do not lift the scanner by the load carriers or by the weighing sys- tem! For installing and deinstalling the scanner adhere to the installation in- structions of the scanner manufacturer. Dimensions of scanner with weighing system CS 300 MA 98 4 - 28 6.110.98.5.01.40 en...
  • Page 53 Operating instructions CS 300 Installation Fig. 49: Dimensions Insert the scanner with the weighing system into the cutout of the POS counter Adjust the foot screws of the scanner so that the load platter is on the same height level as the POS counter.

  • Page 54: Leveling

    Fig. 52: Cable connection MA 98 4.5.7 CS 300 SD (Software Display) The software module CS 300 SD (Software Display) is used to display scale data on a screen connected to the POS system. The program is operated via remote keys.

  • Page 55: Installing The Software Module

    Requirement – The software module must be installed on the POS system. – A Bizerba scale must be connected to the POS system. – Remote keys for software display must be connected to the scale. Instead of a display, remote keys are connected to the scale.

  • Page 56: License For Software Display

    Installation Operating instructions CS 300 Connect the cable to the remote keys License for software display If you have aquired a license for the software display, an SD adhesive stamp comes with the software. The software must be installed on the POS system.

  • Page 57: Setting Overload Stop

    Operating instructions CS 300 Installation Setting overload stop Maximum load 1/30 of the max. load 6 kg 200 g 15 kg 500 g Fig. 56: Overload stop Put the max. load plus 1/30 of the max. load (e.g. 6 kg + 200 g or 15 kg + 500 g) in succession onto positions A-D.

  • Page 58: Overload Stop Ma 84

    4.6.1 Overload stop MA 84 The overload limitation of the weighing system is factory-set by Bizerba. Due to factory-set tolerances in the scanner the overload limitation may no longer meet the requirements. The overload stop must only be set by trained and qualified personnel.

  • Page 59: Overload Stop Ma 98

    Carefully take weighing system out of the scanner. 4.6.3 Overload stop MA 98 The overload limitation of the weighing system is factory-set by Bizerba. Due to factory-set tolerances in the scanner the overload limitation may no longer meet the requirements. 6.110.98.5.01.40 en...
  • Page 60 Overload stop screws Carefully set the overload stops. See page 4 - 33. Fig. 59: Overload stops CS 300 MA 98 Place and align load platter. There must be an uniform gap between the load platter and the lateral limitations of the scanner housing.

  • Page 61: Device And Operating Controls

    Operating instructions CS 300 Device and operating controls Device and operating controls Display Fig. 60: Display The display shows symbols, weight and price in the respective display areas. Type and country dependent symbols indicate different operating states: Net display after taring...

  • Page 62: Display Types

    Device and operating controls Operating instructions CS 300 5.1.1 Display types Different types of displays are offered: Display type Display shows: WS display Weight only P display Weight, tare, basic price, sell- ing price. VGAScreen Weight, tare, unit price, sell- ing price, PLU text.

  • Page 63: Design Versions Of Ws, And P Displays

    Operating instructions CS 300 Device and operating controls Weight Tare Unit price Selling price Symbols, see page 5 - 1 Fig. 62: P display 5.1.2 Design versions of WS, and P displays Depending on the version, the display may be mounted using an angle bracket...

  • Page 64: Cs 300 Sd (Software Display)

    POS display. CS 300 SD (Software Display) The software module generates the scale display on a screen, e.g. of a POS system. The weighing results are transmitted from the connected scale to the POS system and dis- played on the built-in POS screen.

  • Page 65: Checking The Software

    To view the logbook, go to menu Pr 705, see page 7 - 11. Keyboard Overview of function keys Function (depending on operat. mode) Key symbol Bizerba display Switching on/off display Zero setting Programming function Tare function with menu setting Pr 209 / 00 only...
  • Page 66 Device and operating controls Operating instructions CS 300 Key <T> Key <0> Fig. 67: Keys for WS display Key <T> Key <0> Fig. 68: Keys for P display Key <T> Key <0> Fig. 69: Remote keys for software display Key <0>...

  • Page 67: Cs 300 With Posscale (Rik4Checkout)

    The POSscale (OEM scale) software runs on the display (window) and weighing software on the host, e.g. a POS system. The CS 300 can be connected as external load receptor. – Parallel operation of P, WS, and CS300SD displays is not possible.

  • Page 68: Ma 98 And Ma 94 With Scalesentry

    Device and operating controls Operating instructions CS 300 Zero setting of scale 1. Touch weight field for approx. 3-5 seconds. Function disabled in self-service operation. 2. If remote keys are connected or integrated in the scanner, press the key <T>.
  • Page 69 Operating instructions CS 300 Device and operating controls Invisible infrared beams are used to con- trol the long sides of the load platter. Fig. 72: Example: Infrared beam If fruit and vegetable are incorrectly posi- tioned, the infrared beam is interrupted and no weight value is transmitted to the cash register.
  • Page 70 Device and operating controls Operating instructions CS 300 5 - 10 6.110.98.5.01.40 en...

  • Page 71: Operation

    Operating instructions CS 300 Operation Operation Switching device on The scales should not be loaded. Press key <0> once. The display test occurs automatically. It causes the figure 8 and the symbols to appear at all digit places for approx. 5 seconds.

  • Page 72: Tare Functions

    Operation Operating instructions CS 300 If the weight value display is not zero with the scale being unloaded, it can be reset to zero. Press key <0> once. The weight display is set to zero. Tare functions Tare balancing for unknown tare values An unknown tare (empties) is a non product-related tare, which must be weighed and tared.
  • Page 73 Operating instructions CS 300 Operation Fill container deposit with the article. The weight display indicates the net weight of the article "2.000" kg. The tare display indicates the weight of the empty container "0.535" kg. Fig. 78: Net weight 6.4.2...

  • Page 74: Deleting Tare

    Operation Operating instructions CS 300 Press the <T> key. The article weight and the weight of the empty container are added to the new tare weight The weight display indicates zero. Fig. 82: Batch tare For scales with weighing ranges up to 10 kg, you can tare the entire weighing range.

  • Page 75: Programming

    Operating instructions CS 300 Programming Programming Key functions in programming mode Menu Program number Menu setting Key <0> – Select (menu, program number, menu setting) Key <T> – Confirm Fig. 83: Programming mode (menu, program number, menu setting) – 2x <T> = Restart of scale when "Pr1--"...

  • Page 76: Menu Pr2

    Programming Operating instructions CS 300 Exit menu Press <T> twice while "Pr1--" appears on the display. The scale runs a display test. The scales returns to the weighing mode. Fig. 85: Exit menu Menu Pr2-- Checkout dialog Pr 201 Switching between POS / scale display on 1/4 VGA...

  • Page 77: Pr 204 Switching Between Scale / Pos Display On 1/4 Vga Display

    Press <T> key. 7.3.2 Pr 204 Switching between scale / POS display on 1/4 VGA dis- play and CS 300 SD When entering an article to be weighed at the POS, the POS display switches to the scale display. The point of time at which the scale display switches to the POS display depends on the setting made in Pr204: 6.110.98.5.01.40 en...

  • Page 78: Pr 206 Active Zeropoint Monitoring

    Programming Operating instructions CS 300 Setting options 0 = Only after motion on scale, the scale display switches to the POS display. 1 = After approx. 2 seconds the scale dis- play switches to the POS display. Fig. 87: Pr 204 Standard Example: Menu setting "1":...

  • Page 79: Pr 209 Tare Function

    Operating instructions CS 300 Programming 0 = Passive zeropoint monitoring (default) 1 = Active zeropoint monitoring Example: Menu setting "1" Press key <0> three times. Press <T> key. Press <0> key. Press <T> key. Press key <0> five times. Press <T> key.

  • Page 80: Menu Pr 4

    Programming Operating instructions CS 300 Select program number Press <0> eight times. Press <T> key. The first digit starts flashing. Menu setting Press <T> key. The second digit starts flashing. Press key <0>. Press <T> key. Menu Pr 4-- 0-LED on scanner...

  • Page 81: Pr 404 Setting Display Type

    7.4.2 Pr 404 Setting display type Setting options: 0 = Setting according to program number 1 = P/W display (standard Bizerba display with green display) 3 = IBM display 4 = AV display (Arc Vision) 5 = WS display 6 = P/W display (orange Bizerba standard display) Selection of programming mode during display test Press key <0>...

  • Page 82: Pr 701 Switching The Fine Resolution Display On

    Programming Operating instructions CS 300 7.5.1 Pr 701 Switching the fine resolution display on Use the fine resolution display to make settings on the scale (e.g. overload limitation). Press key <0> three times. Press <T> key. Press key <0> six times.

  • Page 83: Pr 705 Logbook Control

    Operating instructions CS 300 Programming Load cell types Load capacity Interval Display Cod 150503 WS18 6/15 kg 2/5 g Cod 120201 WS18; WS22; 12 kg WS36 Cod 151501 WS12; WS 18; 15 lb 0.005 lb WS22 Cod 301111 WS18; WS22;...

  • Page 84: Calling Up Logbook Entries With P Displays

    Press key <0>four times. Press <T> key. Step 1 Displayed step Software ID Version number of legally relevant part Program version CS 300 of legally non-relevant part Press key <0>. Step 2-1 Displayed step Consecutive number of logbook entry 7 - 10...

  • Page 85: Calling Up Logbook Entries On Cs 300 Sd

    Component number Press key <0>. Step 2-2 Displayed step Software ID Version number of legally relevant part Program version CS 300 of legally non-relevant part Press key <0>. Step 2-3 Displayed step Date Time Steps 2-1 to 2-3 are repeated until all logbook entries have been displayed.
  • Page 86 Press key <0> four times. Step 1 Press key <T>. Displayed step Software ID Version number of legally relevant part Program version CS 300 of part which is not legally relevant Fig. 92: Step 1 Step 2-1 Press key <0>. Displayed step...
  • Page 87 Operating instructions CS 300 Programming Step 2-2 Press key <0>. Displayed step Software ID Version number of legally relevant part Program version CS 300 of part which is not legally relevant Fig. 94: Step 2-2 Step 2-3 Press key <0>. Displayed step Date Time Fig.

  • Page 88: Calling Up Logbook Entries With Ws Display

    Programming Operating instructions CS 300 Step 2-3 Press key <0>. Displayed step Date Time Fig. 98: Step 2-3 Steps 2-1 to 2-3 are repeated until all logbook entries have been displayed. If all entries have been displayed, the scale returns to the initial menu display.
  • Page 89 Operating instructions CS 300 Programming Program version of legally non-relevant part Step 2-3 Date of download: 25 Sept. 2009 Time of download: 10:05 a.m. Repeat steps 2-1 to 2-3 until all logbook entries have been displayed. If all entries have been displayed, the scale returns to the initial menu display.

  • Page 90: Overview Of Programming

    Programming Operating instructions CS 300 Overview of programming Setting option Menu page Display example Checkout dialog Standard 06 Pr 201 7 - 2 Switching between Switching after motion on scale Pr 204 7 - 3 POS / scale display on 1/4 VGA display Switch after approx.

  • Page 91: Troubleshooting

    In the case of errors which you cannot eliminate yourself and which are not described in these operating instructions, please call your Bizerba customer service point. Please provide your Bizerba customer service point with the following details: – Device type (see identification plate) –...
  • Page 92 Troubleshooting Operating instructions CS 300 Fig. 99: Display Messages Cause Elimination Cod 112 Movement of the scale during start-up. Do not move the scale! Cod 110 Scale loaded during start-up. Unload scales! Cod 110 Scale below zero during start-up. Apply load platter.

  • Page 93: Maintenance

    Operating instructions CS 300 Maintenance Maintenance Cleaning The cleaning instructions must be observed during installation, operation and mainte- nance. CAUTION Incorrect cleaning agents! Damage of device surfaces. – Do not use spirit, acetone or aggressive cleaning or scouring agents. CAUTION Cleaning! Damage due to water in the device.
  • Page 94 Maintenance Operating instructions CS 300 9 - 2 6.110.98.5.01.40 en...

  • Page 95: Technical Data

    10.1 Dimensions Scale CS 300 TM Length: 340 mm Width: 275 mm Construction height: 101 mm Fig. 100: CS 300 TM Scale CS 300 TE Length: 335 mm Width: 270 mm Construction height: 96 mm Fig. 101: CS 300 TE...
  • Page 96 Technical data Operating instructions CS 300 Length 1: 210 mm Length 2: 125 mm Width 1: 90 mm Width 2: 52 mm Housing height 1: 91.4 mm Housing height 2: 79 mm Overall height 3: 416mm Fig. 103: P display on stand...

  • Page 97: Power Supply

    Strictly adhere to the following requirements when applying electronic retail scales weigh- ing and EDP systems, recording units and similar devices, device combinations and spare parts. For other manufacturers' equipment included in Bizerba's scope of supply, the respective manufacturer's regulations take preference if they deviate from Bizerba's conditions. 6.110.98.5.01.40 en...
  • Page 98 Technical data Operating instructions CS 300 Limit values Device Protec- Temperature °C Celsius (degF Fahren- Relative air humidity % family tion heit) class as Operation Storage Operation Storage per IP min. max. min. max. min. max. min. max. sys- (+60)

  • Page 99: Subject Index

    Mains supply, 10 - 3 CS 300 TM, 4 - 5 Mounting, 4 - 5 Display, 5 - 1 CS 300 ER-K, 4 - 9, 4 - 10 Design, 5 - 3 CS 300 MA 84, 4 - 12 Types, 5 - 2...
  • Page 100 Subject index Operating instructions CS 300 Place of installation, 4 - 2 Plates, 3 - 2 Plug-in transformer unit, 10 - 3 POSscale, 5 - 7 Power supply, 2 - 7 Protection type, 10 - 4 Servicing, 9 - 1...

  • Page 101: Declaration Of Conformity Cs 300

    Operating instructions CS 300 Appendix Appendix Declaration of conformity CS 300 6.110.98.5.01.40 en...
  • Page 102 Appendix Operating instructions CS 300 6.110.98.5.01.40 en...
  • Page 103 The Declaration of Conformity only applies with regard to the EC Scales Guideline in conjunction with a conformity certification from an appointed body. This sentence is omitted when the conformity evaluation has been carried out by Bizerba. The basis for the declaration of conformity is the contract documents (Bizerba purchase order documents).
