Racking Solutions WD002 Assembly Instructions

Chrome 3-Tier Wardrobe
Please inspect box contents to ensure you have received all components.
Note: the black circular plastic tops in between the shelves are used only for
packaging purposes. They are NOT NEEDED. Please discard responsibly
& keep away from small children.
Total weight capacity of is 80 kg on casters. HELP LINE
01977 555007
PACKAGE CONTENTS
AX3
Shelf
Bottom Pole (with threaded
insert pre-installed)
DX24+2
extra Slip sleeve
(2 locking; 2 non-locking)
GX2
Hanging Rod Bracket
ASSEMBLY INSTRUCTIONS
WD002
BX4
Top Pole (with end cap and
pole connector pre-installed)
EX4
Casters
HX1
Hanging Rod
!
!
CX4
FX2
Screw
if in doubt contact the supplier
Information
Please read these instructions
throughly before commencing
assembly.
Inspect all packages for damage and
check that all components have been
supplied
Assembly should be undertaken by
at least two people
During Assembly
Caution
Wear appropriate clothing -protective
gloves and footwear are
recommended
Dispose of packaging materials
responsibly
Make sure the floor is level
Allow adequate working space and be
aware of others working around you
Take care when handling heavy items
particularly when lifting or stretching
Rules for safe use of shelving
Warning
Not suitable for use in damp or wet
environments.
ENSURE THAT THE MAXIMUM LOAD
CARRYING CAPACITIES ARE NOT
EXCEEDED
Shelves must be loaded evenly, and load
heavier items on the bottom shelves
Never climb or stand on the shelves.
TOOLS REQUIRED
Rubber Mallet
