- Page 1 16x1 HDMI Multi-Viewer with Seamless Switcher VER 1.2...
-
Page 2: Table Of Contents
Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electri- cal spikes, surges, electric shook, lighting strikes, etc. -
Page 3: Introduction
1. Introduction This product is a high performance 16 by 1 Multi-Viewer wit seamless switcher. It supports sixteen High definition input source display on one screen. As a switcher, it can also seamlessly switch the sixteen HD input freely. The product can be controlled by various ways, through the front panel button control and RS-232 control etc. -
Page 4: Specifications
4. Specifications Technical Video Bandwidth 2.25Gbps 16 × HDMI (Female type),1x RS232 Input Ports Output Ports 1 × HDMI (Female type), Audio output PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1 480i60Hz,480p60Hz,576i50Hz,576p50Hz,720p50/60Hz, 1080i50/60Hz,1080p 24/30/50/60Hz,800x600@60, Input Resolution 1024x768@60,1280x720@60,1920x1080@60; Output Resolution 1080p,1080i,720p,1024x768,1360x768 ESD Protection ±8kV (Air-gap discharge), ±4kV (Contact discharge) Power Supply 12V/5A DC (US/EU standards, CE/FCC/UL certified) -
Page 5: Operation Controls And Functions
5. Operation Controls and Functions 5.1 Front Panel Number Name Function description Press this button to power the device on/off. The POWER LED will illuminate green when the power is on, red when it is in 'Standby' mode. Press this button to lock all the buttons on the panel, press again to unlock. -
Page 6: Detail Description Of Display Mode
Number Name Function descriptions Connect HDMI sources. LED 1-16 illuminate when HDMI INPUT Area the HDMI signal plug in corresponding input port with HDMI cable. Output for displays, AVR etc. LED illuminate when HDMI OUTPUT Area the display plug in corresponding output port with HDMI cable. -
Page 7: Pc Controller User Guider
MODE3: The 16x1 multi-viewer divides the nine HD input to the same size and display on one screen. And now switch the input button on front panel or IR remote, the HDMI output audio will corresponding to the selected input source. IN10 IN11 MODE3-9×1 Multi-Viewer... - Page 8 ① Select PC connect COM port，Click to connect or disconnect PC and multi-viewer and the corresponding light will display. ② Select the HDMI output resolution. ③ Select the input source. ④ Select the output mode, see the detail description (chapter 6). ⑤...
-
Page 9: Application Example
8. Application Example...
