  • Page 1 5x2 4K60 Presentation Switcher with HDMI and HDBaseT output VER 1.0...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions caref- ully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shook, lighting strikes, etc.

  • Page 3: Introduction

    1. Introduction The 5x1 4K60 Presentation Switcher supports 5 inputs including 3 HDMI ports, 1 VGA(YPbPr/CVBS) and 1 DisplayPort, scaling to HDMI and HDBaseT outputs (Mirrored). It offers flexibility application of audio which includes unbalance audio, MIC In and line out. The audio processor offers auto-mixer and auto-gain control to mix or reduce background audio in order to enhance major audio source.

  • Page 4: Specifications

    4. Specifications Technical HDMI Compliance HDMI 2.0b DP Compliance DisplayPort 1.2a HDCP Compliance HDCP 2.2 and HDCP 1.4 HDMI/DisplayPort: up to 4K2K@50/60Hz(4:4:4) Video Input CVBS: PAL/NTSC3.58/NTSC4.43/SECAM/PAL M/PAL N Resolutions YPBPR: 480i to1080p VGA: 640x480/60 to1920x1200/60 4K2K/30,4K2K/25,1920x1080p60, 1920x1080p50, HDMI/HDBT 1280x720p/60, 1280x720p/50, 1024x768/60,1280x Output Resolutions 800/60, 1360x768/60,1400x1050/60,1680x1050/60, 1920x1200/60...

  • Page 5: Operation Controls And Functions

    Connections Housing Metal Color Black Dimensions 150mm [W] x 220mm [D] x 44mm [H] Weight 1250[g] DC 24V/1A Adaptor Power Supply (US/EU standards, CE/FCC/UL certified) 9W [Main unit] Power Consumption 18W [Main unit + HDBaseT Receiver] Operation 32 - 104°F / 0 - 40°C Temperature Storage temperature -4 - 140°F / -20 - 60°C Relative Humidity...
  • Page 6 ● Press “MENU/OK” button to enter the OSD immediat- ely. Then the user can navigate using the 4-way arrow buttons. A new OSD setting is confirmed by pressing “MENU/OK” button. ● Press "EXIT/AUTO" will exit OSD when OSD is displ- ayed.
  • Page 7 ● IR OUT: Connects with IR emitter cable used for con- trolling the local source device or the switcher. ● CONTACT IN: This input control reserving for direct source input selection. Connect ground pin (mark as on panel) with following pin number for individual source selection.
  • Page 8 5.3 OSD MENU The switcher provides a powerful OSD operation menu. Press MENU button on IR remote to enter in OSD menu, the users can change some settings through the OSD menu. 5.3.1 Main MENU The Main MENU includes Picture mode, Aspect ratio, Screen, EDID switch, Audio setting, network and Software update options.
  • Page 9 Contrast 0-100 (default 50), Brightness 0-100 (default 50), Color 0-60 (default 30), Sharpness 0-20 (default 10), Tint 0-100 (default 50, for CVBS NTSC format only) 5.3.3. Aspect Ratio The user can adjust picture output aspect ratio to 4:3, 16:9 or 16:10. 5.3.4 Screen The screen MENU adjusts for VGA input only.
  • Page 10 5.3.5 EDID The EDID MENU adjusts for HDMI and Display port inputs only. EDID1.4 4K2K30,PCM 2.0 EDID2.0 4K2K60,PCM 2.0 EDID copy from local HDMI port EDID From HDMI EDID From HDBT EDID copy from HDBaseT Receiver HDMI port Auto compare HDMI and HDBT Receiver HDMI EDID AUTO port EDID 9/30...
  • Page 11 5.3.6 Audio Setup The Audio Setting MENU select between Embedded or External analog audio to choose the desired audio output port for HDMI and DP input ports. Select MIC mixer mode: ON, AUTO, OFF. MIC mixer on: The switcher will mix the source audio and MIC audio to the audio output (HDMI, HDBT, Audio output port).
  • Page 12 5.3.8 System Setup The system setup menu includes output resolution, output hdcp, sleep timer, OSD time out, RS-232 Baud Rate. Test Pattern and Factory reset items. 5.3.8.1 Resolution The switcher HDMI output resolutions support multiple modes. Through the system setup menu or press the “RES” button on the IR remote, the resolution menu will be displayed.
  • Page 13 5.3.8.2 HDCP on out Set the HDMI and HDBT port output HDCP status. Pass through means the output HDCP is follow the selected input source HDCP status. HDCP1.4 means the output HDCP will fix to HDCP1.4 status. 12/30...
  • Page 14 5.3.8.3 Sleep timer Set the switcher sleep timer(the time for switcher detect input source no signal to standby mode). The default timer is set to OFF. 5.3.8.4 OSD time out Set the OSD display time. the default time is set to 10 seconds. 13/30...
  • Page 15 5.3.8.5 Baud Rate Set the switcher RS-232 control port baud rate. the default value is set to 115200 bit/s. 5.3.8.6 Test pattern Set the output test pattern type. 14/30...
  • Page 16 5.3.8.7 Reset default Select Reset default -->YES enters to factory reset. The switcher will reset to factory default setting.(eg: HDMI1 input, audio mixer on, Output resolution set to 1920x1080 @60Hz,Baud rate set to 115200 bit/s etc.) 5.3.9 Software update The switcher supports software updates via USB flash disk. The procedure is as follows: 1) Copy the file “MERGE.bin”...
  • Page 17 5.4 Remote Control &IR Operations 5.4.1 Remote Control ① : Press this button to power on to the switcher or set it to standby mode. ② INPUT: Press these buttons for select the input INPUT sources. ③ ADJ: Press this button for operate VGA input auto AUTO adjustment function;...
  • Page 18 2) Control local device from remote To control the switcher or local source device by using the corresponding remote controller. TX 1 UTP Cable DVD Remote Scaler switcher Scaler switcher Remote 3) IR(20KHz---60KHz) cable introduction 5.5 Auto-Switching function The switcher has auto-switching and manual-switching modes. When the user select auto-switching mode, It will follows the following principles: 5.5.1.New input principle Once a new input signal is detected, the switcher will switch to this new signal...
  • Page 19 5.5.3. Signal removing principle Once the current signal is removed, the switcher will detect all input signals with priority on HDMI1->HDMI2->HDMI3->DP->VGA (YPbPr/CVBS). It will transfer the first signal detected to the output. Notice: Auto-switching function works only when there is a new input signal or if an input signal is removed.
  • Page 20 Switch to “48V” 48V Condenser Microphone 48V C ondenser Microphone 2) Balanced Connections: “+” connects to positive, “-” connects to negative and “ ” to ground. Switch to “48V” 48V Condenser Microphone 5.7.2 MIC mode When switched to “MIC” (It has a low frequency characteristics, and wide frequency response in this mode), the microphone input is used for connecting dynamic microphones and electrets condenser microphone.
  • Page 21 2) Balanced connection: “+” connects to positive, “-” connects to negative and “ ”connects to ground. Switch to “MIC” Electret Condenser Microphone Dynamic Microphone 5.7.3 Line mode When switched to “LINE” (It has a low frequency characteristics, and wide frequency response in this mode), the microphone input is used for connecting line audio or wireless microphones.
  • Page 22 2) Balanced connection: “+” connects to positive, “-” connects to negative and “ ”connects to ground. LINE Switch to “LINE” Electret Condenser Microphone Dynamic Microphone 5.8 Operations of RS-232 Control As RS-232 can be transmitted bi-directionally between the switcher and the HDBaseT receiver, it is able to control a third party RS-232 device locally or control the compact switcher bi-directionally.
  • Page 23 2) Control the Switcher or 3rd Party Device from remote Receiver RS-232 device Scaler switcher HDMI Cable RS232 Cable UTP Cable 3) RS-232 Controller Please connect the switcher with input devices and output device needed, then connect it with a computer that is installed with RS-232 control software (attention: the switcher RS-232 port settings must same with the software settings ,eg: baud rate, data bits, parity,stop bits).
  • Page 24 4) RS232 Communication Commands Item Command Description help! Display all communication commands s factory reset! Return to factory reset setting r version! Read current FW version xyz! Upgrade the switcher FW r power! Read the switcher power on/off status s power on! Power on the switcher Power off the switcher s power off!
  • Page 25 Setup picture color 0(range:0-60) s color 0! r sharpness! Read picture sharpness status s sharpness 0! Setup picture sharpness 0(range:0-20) r tint! Read picture tint status s tint! Setup picture tint 0(range:0-100,for CVBS NTSC format only) r aspect ratio! Read current input source output picture aspect ratio s aspect ratio 1! Setup current input source output picture aspect ratio at 16:9 (1: 16:9 , 2: 4:3, 3:16:10 )
  • Page 26 r auto vol! Read source audio volume when set to mixer auto mode r fade in time! Read source audio fade in time when set to mixer auto mode s fade in time 1000! Setup source audio fade in time when set to mixer auto mode. (The fade in time range is 0~5000ms.) r fade out time! Read source audio fade out time when set to mixer auto mode...
  • Page 27 r ip mode! Read IP mode s ip mode 1! Setup IP mode at Static (1:Static,2:DHCP) r ip addr! Read IP address s ip addr 192.168.1.255! Setup IP address at 192.168.1.255 r subnet! Read subnet s subnet 255.255.255.252! Setup subnet at 255.255.255.252 r gateway! Read gateway Setup gateway at 192.168.1.1...
  • Page 28 1) General page 2) Video page 3) Audio page 27/30...
  • Page 29 4) Network page 5) Advanced page 28/30...

  • Page 30: Connection Diagram

    6. Connection Diagram 29/30...
  • Page 31 1.Connect HDMI source devices (e.g. Blue-ray DVD) to HDMI input ports of the switcher with HDMI cable. Connect VGA source device (eg.PC/Note-book) to VGA input port of the switcher with a VGA cable. 2.Connect HDMI display device to the HDMI output port of the switcher with a HDMI cable.
