- Page 1 OPERATION & SERVICE MANUAL Models: 06-5020 Series Reservoir Servicing Unit 08/2009 - Rev. 12 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
- Page 2 REVISION DATE TEXT AFFECTED 08/2009 Revised External Components Illustrations and Parts List...
- Page 3 Models 06-5020 Series Reservoir Servicing Unit TABLE OF CONTENTS PAGE GENERAL DESCRIPTION ............................... 3 SPECIFICATIONS ................................3 FEATURES ..................................3 PREPARATION FOR USE ............................... 3 OPERATION ..................................3 MAINTENANCE ................................4 TIRES ................................. 4 FILTERS ................................4 SERVICE ................................4 GUARANTEES/LIMITATION OF LIABILITY ........................
-
Page 4: Specifications
GENERAL DESCRIPTION The Tronair Reservoir Service Unit is a compact unit primarily designed to provide a source of clean fluid for filling reservoirs. It is not intended for performing any pressure testing tasks. A unique feature is that the unit pumps fluid directly from standard five (5/18.9 lt) gallon containers. - Page 5 Description of the problem If warranty coverage is approved, either replacement parts will be sent or the product will have to be returned to Tronair for repairs. If the product is to be returned, a Return Material Authorization (RMA) number will be issued for reference purposes on any shipping documents.
- Page 6 Models 06-5020 Series Reservoir Servicing Unit HC-2252/HC-2172/HC-2173 Hand Pump Section View When ordering replacement parts/kits, please specify model, serial number and color of your unit. 08/2009 | Rev. 12 Page | 5...
-
Page 7: Parts List
Models 06-5020 Series Reservoir Servicing Unit Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description CXD-020046-004-1 Piston Rod CENT-TA-2098 Spring CXD-020004-006 Flapper CDX-020004-005 Piston 09-AHDF-06-18 x 04 Shoulder Screw... - Page 8 Models 06-5020 Series Reservoir Servicing Unit Internal Components Illustration When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description Phosphate Ester HC-2173 Hand Pump Phosphate Ester HK-3720 Kit, Pump Seal MIL-PRF-5606/MIL-PRF-83282 HC-2172...
- Page 9 Models 06-5020 Series Reservoir Servicing Unit Internal Components Illustration When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description K-1768 Kit, Latch; consists of: H-1646 Strike, Right Angle H-1647 Clamp K-1767 Kit, Lanyard Assembly; consists of:...
-
Page 10: External Components
Models 06-5020 Series Reservoir Servicing Unit External Components When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description K-1550 Kit, Wheel (Single); consists of: G-1203-1115 Jamnut, 3/4-16 Elastic G-1250-1110N Flatwasher, 3/4 Narrow... -
Page 11: Filter Assembly
Models 06-5020 Series Reservoir Servicing Unit Filter Assembly When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Fluid Part Number Description MIL-PRF-5606/MIL-PRF-83282 HC-1481 Assembly, Filter MIL-L-23699/MIL-PRF-87257 HC-1826 Assembly, Filter Phosphate Ester HC-1480 Assembly, Filter... - Page 12 Models 06-5020 Series Reservoir Servicing Unit Towbar Assembly When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description Z-2037 Weldment, Truck Z-2036 Weldment, Tongue K-1249 Kit, Towbar Pin Replacement; consists of: G-1301-03 Pin, 1/8 diameter x 1-1/2"...
- Page 13 Models 06-5020 Series Reservoir Servicing Unit Truck Assembly When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description G-1283 Spindle Washer K-1253 Kit, Hub Bearing and Seal; consists of: G-1301-03 Pin, Cotter...
