KAPSCH Janus HOTPass Mounting Instructions

Kapsch TrafficCom IVHS
Janus HOTPass
®
Mounting Instructions
The HOTPass interior transponder mounts on the vehicle windshield. The preferred mounting location
®
is between the roofline and the rear view mirror post. If there is not enough room in the preferred
mounting location to accommodate the HOTPass
the rear view mirror post. The HOTPass
Requirements
For reliable operation of the transponder, the vehicle must be
n
equipped with only one transponder while passing through a toll
facility. Other transponders present in or on the vehicle must be
switched off or enclosed in an RF shield.
The mounting location must provide direct line-of-sight
n
communication between the transponder and the toll facility
overhead antenna.
Do not mount the HOTPass
n
®
with non-metallic roofs.
u
with windshields covered in RF-blocking material (ex. metal oxide).
u
with a metallic center windshield dividing post.
u
without center-mounted rear view mirrors.
u
Handheld mobile communication devices must not be located within
n
12 in. of the transponder.
Metal objects (except for the rear view mirror and the roof ) must not
n
be located within 6 in. of the transponder.
HOTPass transponders cannot be used where local regulations prohibit
n
®
mounting transponders on the windshield.
Apply Dual Lock ™ fasteners in accordance with 3M
n
70-0709-4029-4.
Interior Transponder
®
transponder is secured using 3M
®
transponder on vehicles:
™ document.
transponder, the transponder can be mounted beside
®
HOTPass® Interior Transponder Mounting
Instructions
1. Select a mounting location on the front windshield. The HOTPass
transponder should be mounted � in., but no more that 2 in. from the
roofline. The preferred mounting location is between the roofline and the
rear view mirror mounting post, with a minimum of � in. between the
transponder and the rear view mirror post.
Dual Lock fasteners.
™ ™
®
