Fortress Technologies ES820 Hardware Manual

Secure wireless bridge
Hide thumbs Also See for ES820:

Advertisement

Table of Contents

See also: User Manual , Hardware Manual
ES820
Secure Wireless Bridge
Hardware Guide
www.fortresstech.com
© 2010 Fortress Technologies

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES820 and is the answer not in the manual?

Questions and answers

Related Manuals for Fortress Technologies ES820

Summary of Contents for Fortress Technologies ES820

  • Page 1 ES820 Secure Wireless Bridge Hardware Guide www.fortresstech.com © 2010 Fortress Technologies...
  • Page 2 Fortress Technologies, 4023 Tampa Road, Suite 2000, Oldsmar, FL 34677, except as specified in the Product Warranty and License Terms.
  • Page 3 ES820 Bridge YOU MAY ALSO FIND HELPFUL THE FOLLOWING BOOKLET, PREPARED BY THE FCC: “HOW TO IDENTIFY AND RESOLVE RADIOTV INTERFERENCE PROBLEMS.” THIS BOOKLET IS AVAILABLE FROM THE U.S. GOVERNMENT PRINTING OFFICE, WASHINGTON, D.C. 20402 CHANGES AND MODIFICATIONS NOT EXPRESSLY APPROVED BY...

  • Page 4: Table Of Contents

    ES820 Bridge Table of Contents Port Locations ......... . . 1 LED Indicators .

  • Page 5: Port Locations

    DC power inlet I/O control connector antenna port Radio 1 Figure 1 ES820 Back-Panel Port Locations LED Indicators The ES820 Bridge’s front panel features six system LEDs. Power On/Off Radio 2 Radio 1 Ethernet port 2 LEDs Ethernet port 1...

  • Page 6: Chassis And I/O Controls

     Power LED will go dark. Reboot (hard boot) the ES820 by powering it off and back on again (described above). The power button is tied to pin 33 or the Bridge’s 37-pin I/O connector, which is a power control line. Both switches must be OFF to power the ES820 off.

  • Page 7: 37-Pin Input/Output Connector

    ES820 Bridge: Hardware 37-Pin Input/Output Connector The connector on the rear panel of the ES820 provides all non- radio input/output for the unit. In order to connect to the ES820, a cable with a matching connector must be made, using the...
  • Page 8 The 37-pin connector provides support for six LEDs, five controls, two Ethernet ports, one USB port, and one RS232 COM port. Table 1. ES820 37-Pin I/O Connector Pin-Outs signal description USB pin 4 Ground USB D+...

  • Page 9: 3-Pin Dc Input Connector

    Table 2 shows the power connector pin-outs. Table 2. ES820 DC Power Connector Pin-Outs signal +9 to 30 VDC Dimensions and Weight dimension inches centimeters height 1.75 4.44 width 6.85 17.4 depth 7.29 18.52 The ES820 weighs 2 lbs 8 oz (1.13 kg).
