- Page 1 Fortress Security System ES210 Secure Wireless Bridge Hardware Guide www.fortresstech.com © 2010 Fortress Technologies...
- Page 2 Fortress Technologies, 4023 Tampa Road, Suite 2000, Oldsmar, FL 34677, except as specified in the Product Warranty and License Terms.
- Page 3 ES210 Hardware Guide YOU MAY ALSO FIND HELPFUL THE FOLLOWING BOOKLET, PREPARED BY THE FCC: “HOW TO IDENTIFY AND RESOLVE RADIO- TV INTERFERENCE PROBLEMS.” THIS BOOKLET IS AVAILABLE FROM THE U.S. GOVERNMENT PRINTING OFFICE, WASHINGTON, D.C. 20402 CHANGES AND MODIFICATIONS NOT EXPRESSLY APPROVED BY...
-
Page 4: Table Of Contents
Mounting the ES210 ........9... - Page 5 ES210 Hardware Guide: Table of Contents Pushbutton Operation ........15 Powering the Bridge On and Off .
-
Page 6: Overview
ES210 Hardware Guide: Overview Chapter 1 Overview This Document This user guide covers preparing and installing the ES210 WARNING: cause physical in- Fortress hardware. It also describes the LED indicators and jury or death and/or se- push button operations and provides specifications. Other... -
Page 7: The Es210
ES210 Hardware Guide: Overview The ES210 The Fortress ES210 Secure Wireless Bridge is a full-featured Fortress controller device, providing strong data encryption and Multi-factor Authentication™, including native RADIUS (Remote Authentication Dial-In User Service) authentication, to users and devices on the network it secures. -
Page 8: Installation
ES210 Hardware Guide: Installation Chapter 2 Installation Preparation Before using or charging an ES210 battery, review the initial installation and charging information in Section 1.1. Before proceeding with installation, review the safety information in Section 2.1.1 below. 2.1.1 Safety Requirements... - Page 9 The wall-mounted (12 V @ 2A) um battery for time- power supply simultaneously powers and charges the keeping purposes. It is ES210 Bridge, at a normal load of 6 W (16 W max. during not intended to be oper- charging). ator- user-replace- The 7.4V lithium ion battery cartridge contains...
-
Page 10: Battery Use And Maintenance
ES210 Hardware Guide: Installation 2.1.2 Battery Use and Maintenance The ES210 Bridge is equipped with a 7.4 volt, 4 amp-hours (29 To en- CAUTION: sure optimal per- watt-hours), lithium ion polymer battery. The battery can power formance, the battery 5–8 hours of Bridge operation, depending on the specific should be fully charged power requirements of your deployment. - Page 11 Do not freeze the battery. Most lithium ion battery electrolytes freeze at approximately -40º F/C. 2.1.2.4 Replacing the Battery If you need to obtain a replacement for the ES210 Bridge battery, contact your Fortress Technologies representative. Power Off Power the Bridge down by depressing the button on the right side of the chassis.
-
Page 12: Port Locations
Replace the battery cover and retighten the cover screws. If the replacement battery has previously been in service (in the current or another ES210), skip the rest of this procedure. If the replacement battery has never been used, connect DC Power the Bridge’s... -
Page 13: Connecting The Es210
Logging On, Licensing, and Configuring the GUI software. 2.2.2 Connections for Deployment WARNING: comply with FCC The section provides instructions for connecting the ES210 for regulations, antennas deployment after you have preconfigured the Bridge software. must be professionally Review the Radio Frequency Safety Requirements (Section installed and the install- 2.1.1) before installing or operating the Bridge radio. -
Page 14: Mounting The Es210
An ES210 Universal Mounting Kit for the ES210 Bridge is optionally available from Fortress Technologies. The same kit permits you to mount the ES210 on a mast, fix it to a flat surface, or attach it magnetically to a smooth metal surface. -
Page 15: Mast Mounting
The ES210 Universal Mounting Kit accommodates masts from 1" to 3.5" in diameter. If you will be mounting the ES210 on a mast, first attach the mast clamps to the mounting bracket. Figure 2.4. Attaching Mast Clamps to the Mounting Bracket... -
Page 16: Non-Magnetic Surface Mounting
With two (of the four included) mounting screws partially screwed into the top corners of the chassis, hang the ES210 by the shafts of these screws on the upper ES210 mounting slots in the bracket. Install the remaining two mounting screws through the ... - Page 17 With two (of the four included) mounting screws partially screwed into the top corners of the chassis, hang the ES210 by the shafts of these screws on the upper ES210 mounting slots in the bracket. Install the remaining two mounting screws through the ...
-
Page 18: Leds And Pushbutton Operation
ES210 Hardware Guide: LEDs and Pushbutton Operation Chapter 3 LEDs and Pushbutton Operation Top-Panel Indicators There are NOTE: indica- The ES210 Bridge’s top panel features four system LEDs tions in a Bridge in Power Battery Radio Crypto Link Activity ,) and a pair of blackout mode (see Sec- LEDs for each of the ES210’s two Ethernet ports. -
Page 19: Port Leds
RF kill activated 3.1.2 Port LEDs The ES210 Bridge’s top-panel Ethernet ports are equipped with link ( ) and activity ( ) LEDs. can exhibit: solid green - A link has been established for the port. -
Page 20: Pushbutton Operation
Powering the Bridge On and Off NOTE: Bridge’s internal When the ES210 Bridge is powered off, the lower button on the temperature reaches left side of the chassis powers it on. The single button on the 176ºF (80ºC) it powers right side of the chassis powers it off. -
Page 21: Pushbutton Rf Kill Operation
ES210 Hardware Guide: LEDs and Pushbutton Operation If Blackout Mode is , the actions below will enable it. If Disabled NOTE: also change the the setting is , the same steps will disable it. Enabled setting in Blackout Mode Press the lower button on the left side of the chassis. -
Page 22: Specifications
ES210 Hardware Guide: Specifications Chapter 4 Specifications Hardware Specifications 4.1.1 Physical Specifications form factor: compact, wearable, mountable 7" H x 3.3" W x 1.7" D dimensions: (17.8 cm × 8.4cm × 4.3 cm, approx.) weight: 2.1 lbs. (.95 kg, approx.) -
Page 23: Battery Specifications
Compliance and Standards FCC Class A, part C; emissions: MIL-STD 461F immunity: MIL-STD 461F vibration: MIL-STD 810F The Fortress ES210 is certified by the Wi-Fi Alliance® for the following standards: IEEE: 802.11a/b/g security: WPA™, WPA2™—Personal and Enterprise EAP-TLS, EAP-TTLS/MSCHAPv2, EAP types:... -
Page 24: Db9-To-3-Pin Console Port Adapter
ES210 Hardware Guide: Specifications DB9-to-3-pin Console Port Adapter A DB9-to-3-pin cylindrical adapter is required in order to Console connect the Bridge’s port to a DB9 terminal connection. Table 4.1 shows the adapter pin-outs. Table 4.1. DB9-to-3-pin Cylindrical Adapter Pin-Outs Description... - Page 25 ES210 Hardware Guide: Index Index see compliance antennas 4, 17 fuse installing ports location specifications hardware restrictions 9–12 mounting kit 3–4 safety requirements 17–18 specifications see also ports 1–7 battery charging installation 8–9 installation safety requirements 9–12 chassis mounting specifications 3–4...
- Page 26 ES210 Hardware Guide: Index resetting factory defaults restoring default settings RF kill RJ-45-to-DB9 adapter safety precautions 3–4 requirements see also specifications serial port adapter 17–18 specifications system requirements see also safety requirements; specifications top-panel 13–14 LEDs port locations see compliance...
