INSTALLATION INSTRUCTIONS
Voyager Twinspot
96629824 / 96629825
2
Remove Knockouts
IP65 grommet/gland
(not provided)
4
IP65 washers
& screws
(not provided)
6
70367
Issue 1
November 2017
1
230V ac 50/60Hz
3
(7a, 7b)
5
7c)
1.2 Nm
ta: 0°C...+40°C
IP65
Thorn Lighting Limited
Durhamgate, Spennymore
Co Durham, DL16 6HL, UK
www.thornlighting.co.uk
