WT100CR operation manual
1,
Touch remote controller battery install
Use AA size battery x 2
Note:
DO NOT
touch the "Touch Area" while placing the battery
2.
Functions of Touch PAD
a.
move coursor
touch and move touch-pad by finger
b.
simulate mouse left button
a short touch (click)on touch pad
c.
simulate mouse right button
a long touch(no moving approx. 1 second) on touch pad
3.
Auto search RF receiver dongle
press
and
when you see blue LEDs keep ON, it means that the WT100CR is looking
for the RF dongle; when you see blue LEDs blinking quickly, it means that
both remote controller and RF dongle had been successfully connected!
Note : if you replace WT100CR battery, you have to reconnect RF dongle.
simultaneously until LED off then release keys ,
Advertisement
Table of Contents
Related Manuals for Wonde Proud WT100CR
Summary of Contents for Wonde Proud WT100CR
- Page 1 LED off then release keys , when you see blue LEDs keep ON, it means that the WT100CR is looking for the RF dongle; when you see blue LEDs blinking quickly, it means that both remote controller and RF dongle had been successfully connected!
- Page 2 Key operation mouse Left button play/Pause in Windows Media Player fast forward in Windows Media Player fast backward in Windows Media Player increase volume mouse right button Backspace task window switching Press , PC pop all active task iterm, select task, press switch to your task window...
- Page 3 mute decrease volume arrow up arrow right arrow down arrow left ENTER full screen in Windows Media Player RF Receive Dongle install Plugin RF receive dongle to your PC/NoteBook USB port, PC/NoteBook find a new device and install driver automatically. This device complies with Part 15 of the FCC Rules.
