Clyde Alkon 90 Datasheet

Natural gas 90 kw lp gas 90 kw floor standing condensing boilers
Hide thumbs

Advertisement

Quick Links

Download this manual
Natural Gas
LP Gas
Contents
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - info@mytub.co.uk
Clyde Alkon 90
90 kW
Floor standing condensing boilers
90 kW
Fully modulating burner and efficiency of up to 109.1% ncv
Modulating integral pump
Modular arrangement of floor standing boilers that simply bolt together
Cascade of up to 8 boilers (2 x 4) without additional frames or manifold
Aluminium/silicon/magnesium heat exchanger resists corrosion
Page
Counter flow heat exchange maximises heat transfer & thermal efficiency
For internal and external installations
2 & 3
4
5 & 6
7
8 to 12
Engineering Data Sheet 814/1
May 2010

Advertisement

loading
Need help?

Need help?

Do you have a question about the Alkon 90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clyde Alkon 90

Summary of Contents for Clyde Alkon 90

  • Page 1: Table Of Contents

    Clyde Alkon 90 Natural Gas 90 kW LP Gas Floor standing condensing boilers 90 kW Fully modulating burner and efficiency of up to 109.1% ncv Modulating integral pump Modular arrangement of floor standing boilers that simply bolt together Cascade of up to 8 boilers (2 x 4) without additional frames or manifold...

  • Page 2: General Information 2

    Operating principles The Alkon 90 is a floor standing condensing boiler with a counter flow heat exchanger with heat exchange pins that ensure a constant rate of heat transfer through the aluminium body. It has a fully-modulating, down-firing pre-mix gas burner (refer Figs 1 and 2).
  • Page 3 8.0 bar and a maximum working temperature of 90°C (see Technical data). Alkon 90 boilers are suitable for use with Group H second family gases (eg natural gas, G20), and Group P third family gases (eg propane, G31). and Butane/Propane mix (G30).

  • Page 4: Dimensions And Data

    Dimensions and technical data 1300 Plan 129 251 430 Front Right elevation Left elevation Dim e nsions Bo ile r m o d e l / o u tp u t Bo ile r flo w co n n e ctio n D N 80 Bo ile r re tu rn co n n e ctio n D N 80...

  • Page 5: Installation Requirements 5

    2, 4, 7 and 10. Boiler location Water treatment Alkon 90 boilers can be installed external to a building if the optional top weather cover is fitted. The boiler must Alkon 90 boilers have an aluminium/silicon/magnesium be mounted on a sound, smooth and level plinth of non- alloy heat exchanger and care must be exercised to combustible material, capable of supporting its weight.
  • Page 6 Low velocity headers should always be vertical and sized for a maximum water velocity of 0.5 m/s. Alkon 90 low velocity headers are designed to ensure a water velocity of 0.2 m/s or less and for T10 / 20, so will be suitable for most systems.

  • Page 7: Boiler Wiring Diagram

    Boiler wiring diagram Fig 4 Schematic wiring diagram Key to Fig 4 Ignition electrode assembly Ionisation electrode Minimum water pressure switch Modulating pump Flow temperature sensor Return temperature sensor DHW temperature sensor (optional) Limit thermostat Flue gas temperature limit thermostat (optional) Gas valve Modulating fan speed control EDS814/1 page7...
  • Page 8 Mains connection Each Alkon 90 boiler requires a permanent mains supply of 230V 50Hz, protected by a 3 Amp fuse. The electrical supply to the boiler must be installed in accordance with current IEE (BS 7671) Regulations. A separate supply and isolating switch is required for each boiler, with at least 3 mm separation for both the phase and neutral poles.
  • Page 9 Hydraulic system design and control Fig 5 1-boiler frame and pipework Notes; (1) Overall length of the standard frame and pipework kit, which does not include items 3, 4 and 5. (2) This is the overall length including items 3, 4 and 5. These items are a safety device kit including housing, manifold, controls and boiler expansion vessel.
  • Page 10 Hydraulic system design and control Fig 6 2-boiler frame and pipework Notes; (1) Overall length of the standard frame and pipework kit, which does not include items 3, 4 and 5. (2) This is the overall length including items 3, 4 and 5. These items are a safety device kit including housing, manifold, controls and boiler expansion vessel.
  • Page 11 Hydraulic system design and control Fig 7 3-boiler frame and pipework Notes; (1) Overall length of the standard frame and pipework kit, which does not include items 3, 4 and 5. (2) This is the overall length including items 3, 4 and 5. These items are a safety device kit including housing, manifold, controls and boiler expansion vessel.

  • Page 12: Hydraulic Systems 8 To

    All offers and sales are subject to the Company's current terms and conditions of sale, a copy of which is available on request. Units 13 - 14 Charlwoods Rd East Grinstead West Sussex RH19 2HU Clyde Energy Solutions Ltd info@clyde4heat.co.uk clyde4heat.co.uk For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - info@mytub.co.uk...
