快速 IP 呼叫 ZXV10 P802L 支持快速 IP 呼叫。用户可以通过拨打目标 IP 地址的最后几位进 行直接 IP 呼叫。此功能时再没有 SIP 代理的情况下使用 CMSA/CD 模拟 PBX 功 能,只有两台话机在同一 LAN/VPN 中才能实现。推荐使用静态 IP 地址。 使用快速 IP 呼叫前需要先对话机进行设置。在话机内嵌的 WEB 页面中选择设 置 > 高级设置,将参数使用快速 IP 拨打模式的值设置为是。 当用户拨打#xxx(x 是 0-9 之间的整数,xxx≤255)时,呼叫发送至 aaa.bbb.ccc.xxx。其中 aaa.bbb.ccc 是目的 IP 地址所在子网的子网掩码。#x,#xx 格式的呼叫也是允许的。...
多路呼叫:用户选择接听另一线路的呼叫,则当前通话自动置于呼叫保持状 态,通话中的另一方将听到呼叫等待提示音。 静音 按静音键可以使麦克风在静音状态和普通状态间切换。 线路状态指示将显示“LINEx:通话中”或“LINEx:静音”来表示麦克风 是否处于静音状态。 呼叫转移 ZXV10 P802L 支持两种呼叫转移方式:呼叫前转和呼叫后转。 呼叫前转 假设当前用户 A 和 B 正在通话中,A 按下 TRANSFER 键后会听到 拨号提示音,输入 C 的号码并按发送键发送呼叫,则 A 退出当前 通话,通话被无条件的转接到 C。 呼叫后转 假设当前用户 A 和 B 正在通话中,通话使用线路 LINE1。A 按下 LINE2 键并拨打 C 的号码,与 C 建立通话,此时 A 与 B 的通话自...
Page 42
ZXV10 P802L SIP Enterprise Phone User Manual 20111013-V1.0...
Page 43
Connecting Your Phone................. 41 Safety Compliances ................42 Warranty....................42 Product Overview ..................43 Using the ZXV10 P802L................46 Getting Familiar with the LCD ............... 46 Making Phone Calls ................49 Handset, Headset and Speakerphone .......... 49 Dual Lines with SIP Account ............49 Completing Calls................
Page 44
Definitions ..................61 Saving the Configuration Changes............84 Rebooting the Phone Remotely ............84 Software Upgrade & Customization............85 Firmware Upgrade Through TFTP/HTTP ..........85 Key Pad Menu ................85 Web Configuration Interface ............85 No Local TFTP/HTTP Server ............86 INSTRUCTIONS FOR LOCAL TFTP UPGRADE: ......
Base Stand Quick Start Guide Connecting Your Phone The connectors of the ZXV10 P802L are located on the bottom of the device. Table 2: ZXV10 P802L Connectors 10/100Mbps RJ-45 ports for PC (downlink) connection 10/100Mbps RJ-45 port for LAN (uplink) connection Power Jack 5V DC power port;...
Safety Compliances The ZXV10 P802L phone complies with FCC/CE and various safety standards. The ZXV10 P802L power adaptor is compliant with the UL standard. Please use the universal power adaptor provided with the ZXV10 P802L package only. The manufacturer’s warranty does not cover damages to the phone caused by unsupported power adaptors.
ZXV10 P802L LCD Display 128 x 40 pixel Number of Lines Programmable Soft Keys Extension Module Table 4: ZXV10 P802L Key Features in a Glance Features Benefits Open Standards SIP RFC3261, TCP/IP/UDP, RTP, HTTP/HTTPS, Compatibility ARP/RARP, ICMP, DNS (A record, SRV and NAPTR), DHCP (both client and server), PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, SIP over TLS, 802.1x,...
Page 48
Table 5: ZXV10 P802L Hardware Specifications ZXV10 P802L LAN Interface 10/100 Mbps Full/Half Duplex Ethernet port with auto detection Graphic LCD 128 x 40 pixel Display Expansion Module Call Appearance 2 Dual color (green/red) line keys Universal Input: 100-240VAC 50-60 Hz...
Page 49
Support SIP PUBLISH method (RFC 3903), SIP Presence package (RFC 3856, 3863) for use of MFKs, SIP Dialog package (RFC 4235) Support for SIP MESSAGE method (RFC 3428) Graphic LCD display, up to 4 level grayscale Display HOLD, TRANSFER, CONF, LINE 1, LINE 2, MSG, Feature Keys SPEAKERPHONE, HANDSET,...
Using the ZXV10 P802L Getting Familiar with the LCD ZXV10 P802L has a dynamic and customizable screen. The screen displays differently depending on whether the phone is idle or in use (active screen). Table 7: LCD Display Definition...
Page 51
LOGO NAME Displays company logo name. This logo name can be customized via xml screen customization. The maximum size for logo name is 22 characters in English NETWORK Shows the status of network in the middle of the screen. It will STATUS indicate whether the network is down or starting STATUS BAR...
Page 52
INDICATES calls are forwarded. Please refer to call forwarding procedures MUTE Icon: INDICATES call is on MUTE during the call SRTP Icon: INDICATES SRTP is enabled for the call Table 9: ZXV10 P802L KEYPAD BUTTONS Button Descriptions HOLD Place active call on hold TRANSFER...
Making Phone Calls Handset, Headset and Speakerphone The ZXV10 P802L allows you to make phone calls via handset, headset or speakerphone. During the active calls the user can switch between the handset, headset and the speakerphone by pressing the corresponding keys on the phone.
Page 54
• Select and press “Dial” to dial out : Server/PBX has to support Page/Intercom. Also, 5. V NTERCOM ZXV10 P802L and PBX have to be configured correctly. • T ake Handset off hook or press SPEAKER button or press HEADSET button or press an available LINE key to activate speakerphone •...
“.”; the “#” key represents colon “:”. Press OK to dial out. The ZXV10 P802L also supports Quick IP Call mode. This enables the phone to make direct IP-calls, using only the last few digits (last octet) of the target phone’s IP-number.
NOTE: If you have a SIP Server configured, a Direct IP-IP still works. If you are using STUN, the Direct IP-IP call will also use STUN. Configure the “Use Random Port” to “No” when completing Direct IP calls. Answering Phone Calls Receiving Calls 1.
MUTE” to indicate whether the microphone is muted. Call Transfer ZXV10 P802L supports both Blind and Attended transfer. Also, users could make auto-attended transfer when this feature is enabled from web GUI. 1. Blind Transfer: Press “TRANSFER” button, then dial the number and press the # button to complete transfer of active call.
3-Way Conferencing ZXV10 P802L can host conference calls and supports up to 3-way conference calling. 1. Initiate a Conference Call: Establish a connection with two parties Press CONF button Choose the desired line to join the conference by pressing the corresponding LINE button 2.
A blinking red MWI (Message Waiting Indicator) on the top right corner of the ZXV10 P802L indicates a message is waiting. Dial into the voicemail box to retrieve the message. An IVR will prompt the user through the process of message retrieval.
“shared line” buttons associated with the account. Call Features The ZXV10 P802L supports traditional and advanced telephony features including caller ID, caller ID w/name, call forward/transfer/park/hold as well as intercom/paging.
Offhook, dial “*93” and the phone will hang up. Customized LCD Screen & XML ZXV10 P802L IP phone support both simple and advanced XML applications: 1) XML Custom Screen and 2) XML Downloadable Phonebook. For more information on how to create a downloadable XML phonebook, creating a custom idle screen and/or reprogramming the soft-keys on ZXV10 P802L, please visit our website at http://www.zte.com.cn...
Configuration Guide The ZXV10 P802L can be configured in two ways. Firstly, using the Key Pad Configuration Menu on the phone; secondly, through embedded web- configuration menu. Configuration Via Keypad To enter the MENU, press the round button. Navigate the menu by using the arrow keys: up/down and left/right.
Page 63
Preferenc Press Menu button to enter this sub menu including: D o NOT Disturb DND (Do Not Disturb) function could be turned on or off in the “Do Not Disturb” menu. R ing Tone Choose different ring tones in the “Ring Tone” menu. ...
Exit from this menu. Configuration VIA Web Browser The ZXV10 P802L embedded Web server responds to HTTP/HTTPS GET/POST requests. Embedded HTML pages allow a user to configure the IP phone through a Web browser such as Microsoft’s IE, Mozilla Firefox and Google Chrome.
To access the phone’s Web Configuration Menu • C onnect the computer to the same network as the phone • Make sure the phone is turned on and shows its IP address • Start a Web browser on your computer •...
Page 66
Account: To configure the SIP account. Table 13: Device Configuration - Status The device ID, in HEXADECIMAL format. Address IP Address This field shows IP address of ZXV10 P802L. Product This field contains the product model information. Model Part This field contains the product part number.
Page 67
IP Address The ZXV10 P802L operates in three modes: 1. DHCP mode: The ZXV10 P802L acquires its IP address from the first DHCP server it discovers on its LAN. The DHCP option is reserved for NAT router mode. In DHCP mode, all the field values for the Static IP mode are not used (even though they are still saved in the Flash memory).
Page 68
Options available for Key Mode are : 1. Line 2. Shared Line Time Zone This parameter controls the date/time display according to the specified time zone. If “Allow DHCP Option 2 to override Time Zone setting” is checked, the time zone will be overridden by the DHCP server. Self- This parameter allows the users to define their own time zone.
Page 69
and pressing the ‘SwitchSCR’ soft-key once. Set LCD contrast. Range from 0 to 20. Contrast Time LCD time display in 12 hour or 24 hour format. Display Format Disable in- Default is “No”. This field is used to hide the keypad input call DTMF during a call.
Page 70
ZXV10 P802Ls are behind the same NAT. Default is “No”. Keep-alive This parameter specifies how often the ZXV10 P802L sends a interval blank UDP packet to the SIP server in order to keep the “hole” on the NAT open. Default is 20 seconds.
Page 71
Defines the config server path for provisioning; it can be Server Path different from the Firmware server. Firmware Default is blank. If configured, ZXV10 P802L will request the File firmware file with the prefix/postfix and only the firmware with Prefix/Postfi the matching encrypted prefix will be downloaded and flashed into the phone.
Page 72
Automatic This function is used by ITSP. End user should NOT touch Upgrade these parameters. Default is “No”. Choose “Yes” to enable automatic HTTP upgrade and provisioning. In “Check for upgrade every” field, enter the number of minutes to check the HTTP server for firmware upgrade or configuration changes.
Page 73
Password Authenticati Select the authentication method among “No authentication”, on Method “Basic” or Digest. Connection Enter the connection request port. Request Port Phonebook Selects the file download mode for the download server. Users can choose from TFTP/HTTP/No. Download Phonebook The URL/IP address of the phonebook download server. XML Server Path Phonebook...
Page 74
Use custom The phone will use custom filename specified in XML server filename path if set to “Yes”. The default setting is “No”. Idle Screen Specify the idle screen XML server path. XML Server Path Offhook To configure a User ID/extension to dial automatically when the Auto Dial phone is taken offhook.
Page 75
Caller ID must be configured. Select a Distinctive Ring Tone 1 Ring Tone through 3 for a particular Caller ID. The ZXV10 P802L will ONLY use selected ring tones for particular Caller IDs. For all other calls, the ZXV10 P802L will use System Ring Tone. When selected and no Caller ID is configured, the selected ring tone will be used for all incoming calls.
Page 76
and then repeat the pattern. Up to three cadences are supported. Disable Call Default is “No”. If set to “Yes”, the call waiting feature will be Waiting disabled. Disable Call Default is “No”. If set to “Yes”, the call waiting tone will be disabled.
Page 77
Hungarian, Italian, Japanese, Korean, Dutch, Polish, Portuguese, Russian, Slovenian, Simplified Chinese and Traditional Chinese. Note: The “Automatic” setting in language refers to ZTE’s IP2Location client which when connected to Internet would attempt to lookup a database (driven by ZTE) with the IP...
Page 78
address for its geographical location. Language file postfix allows the language file to have different postfixes so the phone can request a particular file. It will append an underscore "_" plus the string in the language file postfix. The default language file name is "gxp.txt". If the field “Language File postfix “has "NL"...
Page 79
Secondary SIP This field allows administrator to configure a backup SIP Server Server. Outbound IP address or Domain name of Outbound Proxy, Media Proxy Gateway, or Session Border Controller. Used for firewall or NAT penetration in different network environment. If the system detects symmetric NAT, STUN will not work.
Page 80
The maximum interval is 65,535 minutes (about 45 days). Reregister This parameter allows user to specify the time frequency Before (in seconds) that ZXV10 P802L sends out a re-registration Expiration request before the Register Expiration. By default is 0 second. Local SIP Port This parameter defines the local SIP port used to listen and transmit.
Page 81
SIP and SDP messages. If selecting Keep-Alive with no specified STUN server, the ZXV10 P802L will periodically (every 20 seconds or so) send a blank UDP packet (with no payload data) to the SIP server to keep the “hole”...
Page 82
Feature Key Default is “No”. This option is to synchronize DND/Call Synchronizatio Forward features with Broadsoft. When set to “Yes”, a SUBSCRIBE will be sent out periodically to the server. Then when DND/Call Forward features (Call Forward No Answer, Unconditional Call Forward and Call Forward on Busy) are configured or changed on the phone and the Broadsoft server side, those features will be synchronized on the phone side and the Broadsoft server side.
Page 83
e) [147] - any digit of 1, 4, or 7 f) <2=011> - replace digit 2 with 011 when dialing g) | - the OR operand • Example 1: {[369]11 | 1617xxxxxxx} Allow 311, 611, and 911 or any 10 digit numbers with leading digits 1617 •...
Page 84
by any length of numbers. Delayed Call Time waited before the call is forward to a number or VM. Forward Wait Default is 20 seconds. Time Enable Call Default is “Yes”. If set to “No”, Call transfer, Call Features Forwarding & Do-Not-Disturb are supported locally provided ITSP support those features.
Page 85
INVITE message will be set to anonymous, essentially blocking the Caller ID from displaying. Anonymous Default is “No”. If set to “Yes”, anonymous call will be Call Rejection rejected. Auto Answer Default is “No”. If set to “Yes”, ZXV10 P802L will...
Page 86
Hangup Default setting is set to “No”. Preferred ZXV10 P802L supports up to 7 different Vocoder types Vocoder including G.711(a/µ) (also known as PCMU/PCMA), G.723.1, G.729A/B, G.726-32, Ilbc, G.722 (wide-band). Configure Vocoders in a preference list that is included with the same preference order in SDP message.
Page 87
(x2.5ms) frames respectively. Please be careful when editing these parameters. Adjusting these parameters will also change the dynamic jitter buffer. The ZXV10 P802L has a patent dynamic jitter buffer handling algorithm. The jitter buffer range is 20 ~ 200 ms.
the “#” key is included as part of the dial string. G723 Rate Encoding rate for G723 codec. By default, 6.3kbps rate is set. G726-32 Select “ITU” or “IETF” for G726-32 packing mode. Packing Mode ilbc Frame Size ilbc packet frame size. Default is 20ms. For Asterisk PBX, 30ms might be required.
“Upgrade Server” needs to be set to a valid URL of a HTTP server. Server name can be in either FQDN or IP address format. Here are examples of some valid URLs. • firmware.mycompany.com:6688/ZTE/1.2.3.5 • 72.172.83.110 There are two ways to set up the Upgrade Server to upgrade firmware: via Key Pad Menu and Web Configuration Interface.
To configure the Upgrade Server via the Web configuration interface, open the web browser. Enter the ZXV10 P802L IP address. Enter the admin password to access the web configuration interface. In the ADVANCED SETTINGS page, enter the Upgrade Server’s IP address or FQDN in the “Firmware Server Path”...
Microsoft IIS web server. NOTE: W hen ZXV10 P802L phone boots up, it will send TFTP or HTTP request to download configuration file “cfg000b82xxxxxx”, where “000b82xxxxxx” is the MAC address of the ZXV10 P802L phone. This file is for provisioning purpose.
For more details on XML provisioning, please refer to http://www.zte.com.cn. Managing Firmware and Configuration File Download When “Automatic Upgrade” is set to “Yes”, a Service Provider can use P193 (Auto Check Interval, in minutes, default and minimum is 60 minutes) to have the devices periodically check for upgrades at pre-scheduled time intervals.
Page 93
3333 Example: if the MAC address is 000b8200e395, it should be key in as “0002228200333395”. NOTE: If there are digits like “22” in the MAC, you need to type “2” then press “->” right arrow key to move the cursor or wait for 4 seconds to continue to key in another “2”.
Page 94
—Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.
