PRYME BLU BT-523 User Manual

QUICK START
1. Connect the PRYME BLU adapter to a compatible two-way radio.
2. Pair the PRYME BLU Adapter with a compatible wireless audio accessory.
3. Connect a wired audio or PTT accessory to the Quick-Disconnect accessory port on the
PRYME BLU Adapter (optional).
4. Test and use.
Connecting the Adapter to Radio
STEP ONE: Connecting to Two-Way Radio
To connect your PRYME BLU Adapter to a two-way radio, follow these steps:
* Always turn off your two-way radio before connecting the PRYME BLU Adapter.
* Plug the PRYME BLU adapter into the speaker-microphone / audio accessory jack of your two-way radio.
* On some models of two-way radio, you may need to tighten a retaining screw to ensure that the
PRYME BLU adapter remains attached to the radio
* Turn on your two-way radio and verify that the radio transmits and receives with the adapter attached.
* Because no wireless audio accessory will yet be paired to the PRYME BLU Adapter, received signals
should be heard over the radio's internal speaker and transmitted signals will be sent using the radio's
internal microphone.
* The Talk button on the PRYME BLU Adapter will not function as a Push-to-Talk button for your two-way
radio until a wireless audio accessory is successfully paired to the adapter, or a wired audio accessory is
plugged into the Quick-Disconnect port.
3
Controls and Connection
Quick Disconnect Accessory Port
Allows the connection of a PRYME QD
series wired audio accessory, such
as a Push-to-Talk, earphone,
or auxiliary microphone.
Radio Connector
This port connects the PRYME BLU
Adapter to a compatible two-way radio.
Pairing With an Audio Accessory
STEP TWO: Pairing with an Audio Accessory
* Turn off the radio that the PRYME BLU Adapter is connected to. Wait at least three seconds.
* Turn the radio on while holding down the Talk button on the PRYME BLU Adapter.
* Continue to hold the Talk button down for approximately three seconds. Release the Talk button
when the status LED begins to flash two times per second.
* The PRYME BLU Adapter is now in audio accessory pairing mode. Activate the pairing mode on
your compatible wireless audio accessory.
* Once the wireless audio accessory and PRYME BLU Adapter are paired with each other, the status
LED on the adapter will show a constant blue light for three seconds.
* If the PRYME BLU Adapter does not detect a compatible wireless accessory within 60 seconds
of being put into pairing mode, the adapter will exit the pairing mode and resume normal operation.
* Once successfully paired, you will be able to operate your two-way radio using your compatible
wireless accessory.
Multi-Function Talk Switch / Status LED
Used to place the PRYME BLU Adapter in pairing mode.
The LED flashes messages that let the user know the
current status of the PRYME BLU Adapter. Once paired
with an audio accessory, this switch is used to activate
the Push-To-Talk function of the two-way radio.
