Air conditioner

Installation manual

PC4SUFMAN
Thank you for purchasing this Samsung air conditioner.
Before operating this unit, please read this manual carefully and retain it for future
reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PC4SUFMAN and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung PC4SUFMAN

  • Page 1: Air Conditioner

    Air conditioner Installation manual PC4SUFMAN Thank you for purchasing this Samsung air conditioner. Before operating this unit, please read this manual carefully and retain it for future reference.
  • Page 2: Installing The Panel

    4 Way Cassette Wind-Free Panel If the Wind-Free function is not visible on the higher- 1 Open the electrical component box cover. level controller after connecting the Wind-Free panel: After untightening the screws, slide the electrical Check if the software of the higher-level controller is component box cover in the direction of the arrow as the latest version.
  • Page 3 5 Fix the bolt to the panel. indoor unit firmly so that the panel not to fall out. Fix them tightly not to make a gap between the panel and the ceiling. the each corner of the panels when pulling them out. there are electrical cables connected to that corner.
  • Page 4 4 Way Cassette Wind-Free Panel 8 Attach and close the front grille. panel. properly into the grooves on panel ( white terminal before connecting the cables. the panel to close ( Blue Grille 9 Check out that the panel is fixed to the indoor unit. Fix screws tightly between the panel and the surface Panel of the ceiling.
  • Page 5 Memo English...
