LOFTNESS GrainLogix GBL12C Owner's Manual And Parts Book

Grain bag loader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GBL12A and GBL12C
Grain Bag Loader
Owner's Manual and Parts Book
(Originating w/Serial Number 69-166)
Model Number:
Serial Number:
Date of Purchase:
N29057 Rev. E
02.26.18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GrainLogix GBL12C and is the answer not in the manual?

Questions and answers

Related Manuals for LOFTNESS GrainLogix GBL12C

Summary of Contents for LOFTNESS GrainLogix GBL12C

  • Page 1 GBL12A and GBL12C Grain Bag Loader Owner’s Manual and Parts Book (Originating w/Serial Number 69-166) Model Number: Serial Number: Date of Purchase: N29057 Rev. E 02.26.18...
  • Page 3 All Loftness products have a one (1) year limited warranty. The XLB10 Grain Bag Loader has a two (2) year limited warranty. If any Loftness product is used as rental equipment, or in a commercial application, the limited warranty period is for only 30 days from the delivery date to the original customers.

  • Page 5: Table Of Contents

    Table of Contents Warranty Table of Contents Introduction Owner Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Warranty Policy .
  • Page 6 Table of Contents Set-up Instructions (Cont’d) Grain Bag Loader Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Procedure .
  • Page 7 Table of Contents Maintenance (Cont’d) Disc Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Removing The Brake Pads And Calipers .
  • Page 8 Table of Contents Parts Identification (Cont’d) Hub, 8 Bolt 8" Diameter (N25138) - GBL12 and GBL12C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122 Brake Battery Wired (N30092) - GBL12 and GBL12C .

  • Page 9: Introduction

    Continuous improvement and advancement of Loftness products may result in changes to your equipment that may not be reflected in this publication . Loftness reserves the right to make product improvements to the machine at any time . Although great care has been taken to ensure the accuracy of this publication, Loftness does not assume any liability for errors or omissions .
  • Page 10 Grain Bag Loader OM...

  • Page 11: Safety Instructions

    Fulfill all warranty obligations so as not to void the warranties . The warranty policy included in this manual IMPORTANT: Highlights information that must be outlines the warranty policy of Loftness . heeded . NOTE: A reminder of other related information that needs to be considered .

  • Page 12: Safety Rules

    Safety Instructions Safety Rules • Operators are responsible to know the location and function of all guards and shields including but not limited to PTO drivelines, gearboxes, chain drives, These are general safety considerations. Additional augers and are responsible to make certain that all precautions may be necessary to operate your guards are in place when operating the machine .

  • Page 13: Maintenance Safety

    Safety Instructions Maintenance Safety PTO Safety • Do not allow inexperienced persons unfamiliar with • Keep all guards and shields in place when operating the machine, or unfamiliar with safe operating and the PTO . Replace any damaged or missing guards maintenance procedures, to operate or maintain the and shields before operating the PTO .

  • Page 14: Safety Decal Locations

    Safety Instructions Safety Decal Locations Check and replace any worn, torn, hard to read or missing safety decals on your machine . GBL12 only. GBL12 only. Part No . N26795 GBL12 only. Part No . N26796 Part No . N26683 Part No .
  • Page 15 Safety Instructions Safety Decal Locations (Cont’d) GBL12 only. Part No . N26681 At front gearbox guard. GBL12 shown. Part No . N22764 WARNING Rotating parts hazard. Can cause serious injuries or death. Do not operate machine without shields attached. PN 4189 Part No .
  • Page 16 Safety Instructions Safety Decal Locations (Cont’d) CAUTION Part No . N68525 Do Not Exceed 20 MPH. This machine uses implement tires and hubs. Transporting this machine at higher speeds is unsafe. N23931 Part No . N23931 WARNING Read and understand operator’s manual before using this machine.
  • Page 17 Safety Instructions Safety Decal Locations (Cont’d) GBL12 only. GBL12 only. WARNING Skin Puncture Pinch point. Hazard. Keep hands Hydraulic Lines. clear. Protect hands and body from pressure fluids. N23507 N23899 Part No . N23507 Part No . N23899 Grain Bag Loader OM...

  • Page 18: Machine Decals And Signs

    Safety Instructions Machine Decals and Signs Part No. N68583 NOTE: All safety related decals are also shown in the Safety Instructions Section along with their location on the machine. See “Safety Decal Locations” starting on page 6. Check and replace any worn, torn, hard to read or missing decals on your machine .
  • Page 19 Safety Instructions Machine Decals and Signs (Cont’d) Part No . N26972 Part No . 4138 Part No . N13517 FEMA Part No . N26975 Part No . N13721 Part No . N26971 Part No . N26977 Part No . N26979 Grain Bag Loader OM...

  • Page 20: Gbl12 Identification

    Safety Instructions GBL12 Identification Crane and Trolley Bag Cradle Electric Hoist Auger Auger Sleeve Electrical Harness Hydraulic Hoses Transport Storage Safety Chain Jack Turnbuckle Grain Bag Pan Rubber Flap Hopper Extensions Top Hopper Swing Auger Control Valve Swing Hopper Lift Transfer Case Long PTO Main Auger...

  • Page 21: Gbl12C Identification

    Safety Instructions GBL12C Identification Crane & Trolley Hopper Extensions Hopper Electric Hoist Bag Cradle Electrical Harness and Hydraulic Hoses Electrical Transport Control Panel Wheels Main Auger Storage Jack Grain Bag Step and Work Transport Traction Tires Platform Safety Chain and Disc Brakes Grain Bag Loader OM...
  • Page 22 Grain Bag Loader OM...

  • Page 23: Set-Up Instructions

    Set-up Instructions Site Preparation Lightly scrape the ground, removing weeds, sticks, stones and stubble from the entire grain bag storage site that could penetrate the grain bag . When removing debris from the site, be careful not to loosen the ground . The grain bag storage site should remain as firm as possible and free from debris to minimize grain bag damage .

  • Page 24: Storing Grain Bags In The Field

    Set-up Instructions Grain Bag Placement (Cont’d) NORTH Storing Grain Bags In The Field When storing grain bags in the field, position the grain bags in a line . This will help prevent animals (rodents and other pests) from using the bags as a shelter from the weather and from natural predators .

  • Page 25: Storing Grain Bags In Depots

    Set-up Instructions Grain Bag Placement (Cont’d) Storing Grain Bags In Depots WARNING: Do Not place grain bags near or under power lines. NORTH 5 ft. (1.5 m) MINIMUM SOUTH 20 - 26 ft. (6.09 - 7.92 m) MINIMUM 18 ft. (5.5 m) MINIMUM When storing grain bags in depots, position the bags in pairs approximately 5 ft .

  • Page 26: Initial Set-Up

    Set-up Instructions Initial Set-up NOTE: Before initial set-up, be sure to also watch the supplied DVD that came with the grain bag loader. It includes detailed instructions that show how to safely and correctly prepare the grain bag loader for operation. The Grain Bag Loader components (base assembly, main auger assembly, hopper and crane) are shipped individually .
  • Page 27 Set-up Instructions Initial Set-up (Cont’d) Main Auger Installation (Cont’d) Move the main auger assembly towards the base assembly . NOTE: It may be necessary to connect the hydraulic hoses to a tractor aide during the main auger installation. This will allow the installers to raise/ lower the main auger while installing into the base assembly.
  • Page 28 Set-up Instructions Initial Set-up (Cont’d) Main Auger Installation (Cont’d) Remove retaining pin (1), rotate the jack (2) to the operation position and re-install retaining pin . Raise/ lower the jack until the main auger assembly is level . Remove the forklift from the hitch . Install the two connector strap assemblies over the tunnel frame (1) and hitch frame (2) (both sides) .

  • Page 29: Swing Tube/Spout Assembly (Gbl12 Only)

    Set-up Instructions Initial Set-up (Cont’d) Fasten the spout to the tube using the four retainer plates (2) using two 3/8" x 1-1/4" bolts (3), lock washers (4), and plastic spacer bushings (5) and one slider bushing (7) . Swing Tube/Spout Assembly (GBL12 only) NOTE: Do not over tighten these bolts.

  • Page 30: Mounting The Swing Auger (Gbl12 Only)

    Set-up Instructions Initial Set-up (Cont’d) Mounting The Swing Auger (GBL12 only) Clean the 21-spline shaft on the gearbox in the boot as well as the u-joint in the spout of the swing auger . Apply anti-seize compound to the splined shaft . Move the swing auger (1) over the gearbox shaft (2) .

  • Page 31: Swing Hopper/Tube Assembly (Gbl12 Only)

    Set-up Instructions Initial Set-up (Cont’d) Swing Hopper/Tube Assembly (GBL12 only) Swing Auger Installation (GBL12 only) (Cont’d) Install a woodruff key (1) and apply a thin coating of anti- seize compound on the swing flight shaft (2) . When the auger is seated properly, the flange (1) on the Move the hopper toward the swing tube and slide the end of the spout should lay flat onto the boot inside u-joint onto the swing flight shaft (2) .

  • Page 32: Transition Cover Installation (Gbl12 Only)

    Set-up Instructions Initial Set-up (Cont’d) Swing Hopper Assembly (GBL12 only) Transition Cover Installation (GBL12 only) Angled Front Corner Upper Holes Bottom Holes Install the hopper wheels (1) on the hopper using a plated NOTE: Clean the surface of the hopper before applying wheel pin (2) (3/4"...

  • Page 33: Swing Hopper Hoist Installation (Gbl12 Only)

    Set-up Instructions Initial Set-up (Cont’d) Swing Hopper Hoist Installation (GBL12 only) Slowly lower the swing hopper hoist until the mounting holes are aligned . Install the bolt (1), flat washer (both sides) and nut . Tighten the two bolts to securely fasten the swing hopper hoist to the main auger frame .

  • Page 34: Main Hopper Assembly

    Using two people, place a side panel (2) into position inside a wide side of the hopper base . NOTE: If any of the hopper components are damaged or missing, contact your Loftness dealer. IMPORTANT: Fastening hardware should be assembled so that all bolt heads are inside the assembled hopper and the nuts secured outside of the hopper.
  • Page 35 Set-up Instructions Initial Set-up (Cont’d) Main Hopper Assembly (Cont’d) Position a front/back panel (1) inside the two side panels and hopper base . Place a 2" x 4" - 37 in . (or larger) brace (1) at center to support the panel while the remaining panels are being added .
  • Page 36 Set-up Instructions Initial Set-up (Cont’d) Main Hopper Assembly (Cont’d) Position the final front/back panel (1) inside the two side panels and hopper base . Move the brace (1) out slightly towards the newly added panel to support and balance the weight of the hopper assembly .
  • Page 37 Set-up Instructions Initial Set-up (Cont’d) Main Hopper Assembly (Cont’d) Place a hopper brace (1) into position . Use the set of holes in the hopper front and back panels to align . Insert three 1/2" x 1-1/4" bolts (2) from inside of the hopper at each end of the brace .
  • Page 38 Set-up Instructions Initial Set-up (Cont’d) Main Hopper Assembly (Cont’d) Place two of the hopper extension side panels (1 and 2) on top of the hopper . Align the holes of the front panels with the holes in the Have the person inside the hopper turn the bolts with top of the hopper .

  • Page 39: Main Hopper Installation

    Set-up Instructions Initial Set-up (Cont’d) Main Hopper Installation Main Hopper Assembly (Cont’d) Install chains (1) at the two lift points (2) on the hopper cross braces . Place one hopper extension side panel (1) outside the Raise the hopper slowly, then move the hopper over the hopper extension front and back panels (2) .

  • Page 40: Beam/Trolley Installation

    Set-up Instructions Initial Set-up (Cont’d) Beam/Trolley Installation Main Hopper Installation (Cont’d) Install chains to the beam/trolley assembly . Slowly raise and move the assembly over the mounting plate . Lower the hopper inside the mounting frame . Install a bolt through the rear of the beam/trolley assembly and mounting plate .

  • Page 41: Connecting The Grain Bag Loader

    Set-up Instructions Connecting the Grain Bag Loader Back the tractor up to the hitch of the grain bag loader. WARNING: Never use a clevis to clevis type Insert pin (1) (1-1/8 in. to 1-1/4 in. pin) and secure with connection to secure the implement to the retaining clip (2).
  • Page 42 Set-up Instructions Connecting the Grain Bag Loader (Cont’d) Install the pressure and the return hydraulic hoses into the tractor’s hydraulic connectors at the rear of the tractor. Retract sleeve (1), slide the PTO driveline (2) onto the tractor PTO shaft until the sleeve slides forward and locks driveline to shaft.

  • Page 43: Installing The Grain Bag

    Set-up Instructions Installing The Grain Bag Procedure Remote Control Identification Raise the hoist (1), lifting the bag cradle (2) off the tunnel (3) . Move the trolley (4) out until the bag cradle clears the tunnel .  HOIST UP - Press button to raise the hoist .
  • Page 44 Set-up Instructions Installing The Grain Bag (Cont’d) Procedure (Cont’d) Raise the cradle and grain bag . Place the grain bag behind the tunnel . Remove shipping bands, then remove the top half of the box (1) . NOTE: Be careful not to damage the grain bag when removing the shipping bands and top half of the box.
  • Page 45 Set-up Instructions Installing The Grain Bag (Cont’d) Procedure (Cont’d) Install the bungy cord and ties over the grain bag . NOTE: For longer life, store the bungy cord out of the sunlight when not in use. Lower the pan and pull the tarp out, guiding the tarp under the grain bag .

  • Page 46: Grain Bag Loader Positioning

    Set-up Instructions Installing The Grain Bag (Cont’d) Grain Bag Loader Positioning Procedure Procedure (Cont’d) NOTE: When loading the grain bags, move the loading equipment and position it facing up the slope. Loading the grain bags up the slope will aid the operator in braking the machine.

  • Page 47: Equipment Positioning (Gbl12 Only)

    Set-up Instructions Equipment Positioning (GBL12 Only) Truck Position TRUCK PATH TRUCK PATH STEP #2 - Move the trailer forward allowing adequate clearance for the hopper (1) to swing under the trailer . STEP #1 - Align the trailer parallel to and approximately 100"...

  • Page 48: Swing Auger/Hopper Position

    Set-up Instructions Equipment Positioning (GBL12 Only) (Cont’d) Swing Auger/Hopper Position TRUCK PATH STEP #3 - Swing the hopper under the trailer and position the swing auger as shown . The center of the swing hopper (1) should be approximately 84" (2) from the swing auger pivot (3) .

  • Page 49: Rear Compartment Bagging Position

    Set-up Instructions Equipment Positioning (GBL12 Only) NOTE: The truck auger will move approximately 11' while the rear trailer compartment is being (Cont’d) emptied. Rear Compartment Bagging Position TRUCK TRUCK AUGER AUGER PATH PATH NOTE: The trailer should not have to move while unloading the rear compartment.

  • Page 50: Front Compartment Bagging Position

    Set-up Instructions Equipment Positioning (GBL12 Only) (Cont’d) Front Compartment Bagging Position TRUCK AUGER PATH TRUCK AUGER PATH TRUCK PATH STEP #7 - Move the front gate (1) of the trailer over the swing hopper . NOTE: The truck auger will move approximately 11' while the front trailer compartment is being STEP #6 - Swing the hopper forward and position the emptied.

  • Page 51: Operating Instructions

    Operating Instructions Getting Started Sealing The Grain Bag During the loading process, the operator of the tractor is S L O required to remain in the operator’s position at all times to start and stop the PTO shaft and to keep the tractor/ grain bag loader moving in a straight line with the grain bag .

  • Page 52: Filling The Grain Bag

    Operating Instructions Getting Started (Cont’d) Adjusting The Bag Pan Height Using the tractor’s hydraulics, raise or lower the machine Filling The Grain Bag so that the bag pan height is 8 -10 in . (20 .3-25 .4 cm) above the ground . •...

  • Page 53: Lowering The Swing Auger (Gbl12 Only)

    Operating Instructions Getting Started (Cont’d) Lowering The Swing Auger (GBL12 only) Disconnect the transport winch cable (1) from the swing hopper support ring (2) . Remove slack in the transport winch cable . Use the electric winch (1) to raise the swing hopper and remove tension from the upper transport chain .
  • Page 54 Operating Instructions Getting Started (Cont’d) Lowering The Swing Auger (GBL12 only) (Cont’d) Place the auger stop (1) in its operation position and secure in place with pin and clip (2) . Install the auxiliary hydraulic hoses to the tractor . Start the tractor engine and engage auxiliary hydraulics .

  • Page 55: Swing Hopper Controls (Gbl12 Only)

    Operating Instructions Getting Started (Cont’d) Swing Hopper Controls (GBL12 only) Up And Down Movement Push up on lever (1) to raise the swing hopper . Push down on the lever to lower the swing hopper . Left And Right Movement Move lever (1) in (A) (towards operator) to move the swing hopper to the left .

  • Page 56: Loading The Grain Bag (Gbl12 Only)

    Operating Instructions Getting Started (Cont’d) Loading The Grain Bag (GBL12 only) Slowly open the rear compartment door . Adjust door opening until the augers can move the grain from the swing hopper to the top (main) hopper without Align “START” decals . over-flowing the swing hopper .

  • Page 57: End Of Bag Loading

    Operating Instructions End of Bag Loading Sealing The Grain Bag NOTE: When the grain bag is full, seal the bag as soon Releasing Brake Pressure as possible to eliminate the chance of excess moisture entering the bag and damaging the grain.

  • Page 58: Switching To Transport Position

    Operating Instructions Switching to Transport Position Procedure GBL12 shown in the transport position . Fully raise the transport axle into the transport position . Install the cylinder stops (1) . Lower the transport axle until cylinder contacts the cylinder stop . For GBL12 Only Fully raise the swing auger/hopper into the transport position with the safety chain (1) installed .

  • Page 59: Maintenance

    Maintenance General Maintenance Fluids And Lubricants CAUTION: Use proper safety procedures See “Maintenance Safety” on page 5 before performing any service or maintenance on the grain bag loader . when handling petroleum products including, but not limited to, the use of rubber gloves and eye protection.

  • Page 60: Lubrication

    Maintenance Lubrication Grease Points Use a SAE or #2 general purpose lithium based grease unless noted otherwise . NOTE: See pages component location and identification. Location: Left side bag pan tarp bearing (1) . Interval: Every 20 hours of operation . Location: Traction wheel axle (1) (both sides) .
  • Page 61 Maintenance Lubrication (Cont’d) Grease Points (Cont’d) Location: Swing u-joint (1) . GBL12 only . Interval: Every 8 hours of operation . Location: Discharge auger bearing (1) . Interval: Every 50 hours of operation . Location: Transition mount (1) and u-joint (2) . GBL12 only .
  • Page 62 Maintenance Lubrication (Cont’d) Grease Points (Cont’d) Location: Swing cylinder rod end (1) . GBL12 only . Interval: Every 50 hours of operation . Location: Flight hanger (1), u-joint (2) and hopper drive shaft mount (3) . GBL12 only . Interval: Every 8 hours of operation .

  • Page 63: Oil Points

    Maintenance Lubrication (Cont’d) Transport Wheel Hub Grease Points (Cont’d) Checking Gear Lube Location: Swing hopper tires (1) . GBL12 only . Interval: Every 50 hours of operation or annually . Remove the plug (1), the fluid level should be approximately 6 .35 mm (1/4") below the bottom of the Oil Points plug hole .

  • Page 64: Gearbox

    Maintenance Gearbox Lower Gearbox (GBL12 only) NOTE: Check gear oil level every 50 hours of operation Checking Gearbox Oil Levels or annually. NOTE: Always check the gearbox oil levels with the truck auger in the transport or working position. Use the following procedure for the main auger helical and upper gearboxes only .

  • Page 65: Upper Gearbox (Gbl12 Only)

    Maintenance Gearbox (Cont’d) Main Auger Helical Gearbox Upper Gearbox (GBL12 only) NOTE: Check gear oil level every 50 hours of operation or annually. 76 mm (3") 38 mm (1 1/2") Remove the plug (1) from the gearbox . The gear oil should be approximately 38 mm (1 1/2") below the bottom of the fill hole .

  • Page 66: Swing Hopper Drive Chain (Gbl12 Only)

    Maintenance Swing Hopper Drive Chain (GBL12 only) Checking Drive Chain Tension (GBL12 only) Loosen the two jam nuts (1) on the adjuster(s) . Remove hopper chain guard . Place a straight edge (1) across the two sprockets and chain . There should be approximately 9 .52 mm (3/8") deflection in the top section (2) of the chain and no sag at the bottom section (3) .

  • Page 67: Disc Brakes

    Maintenance Disc Brakes Removing The Brake Pads And Calipers WARNING: Make sure all brake pressure has been removed before servicing wheels, hubs and brakes. Install a jack or an approved lifting device to the grain bag loader . Remove the two nuts and bolts (1) and remove the calipers from the disc .

  • Page 68: Installing The Calipers And Brake Shoes

    Maintenance Disc Brakes (Cont’d) Installing The Calipers And Brake Shoes Install the brake pads (1) and cotter pin (2) . Tighten the two bolts (3) to the proper torque . See “Torque Specifications” on page 139 . Install three bolts or lug nuts (1) to hold the brake drum (2) on the hub .

  • Page 69: Bleeding The Brake System

    Maintenance Disc Brakes (Cont’d) Bleeding The Brake System Park the Grain Bag Loader on level ground and turn tractor engine off . RH Brake Caliper bleed port(s) (1) shown with the lug tire removed . NOTE: Two people are required when bleeding the brakes.
  • Page 70 Maintenance Disc Brakes (Cont’d) 1 - 1/4” Bleeding The Brake System (Cont’d) MAXIMUM Setting The Brake Pressure Turn steering wheel all the way out until 5/8" jam nut (1) contacts the mechanical stop (2) . Verify that the gap between the 5/8" jam nut (3) and the bracket face does not exceed 1-1/4"...
  • Page 71 Maintenance Disc Brakes (Cont’d) Brake Pressure Gauge Bleeding Procedure NOTE: If the pressure gauge by the brake control wheel Bleeding The Brake System (Cont’d) is not operating correctly, bleed the line to the gauge. MASTER CYLINDER FACE Pressurize the system . NOTE: Remove the gauge mounting bolts before bleeding the line to the gauge.

  • Page 72: Troubleshooting

    Maintenance Troubleshooting PROBLEM POSSIBLE CAUSE SOLUTION PTO driveline vibration. PTO driveline loose or worn. Check driveline connection. Tighten and repair as necessary. PTO driveline u-joints dry. Lubricate the u-joints. Driveshaft bent. Replace. PTO slide shaft is dry. Lubricate the shaft with grease. Reduction box at driveshaft Oil level too high.
  • Page 73 Maintenance Troubleshooting (Cont’d) PROBLEM POSSIBLE CAUSE SOLUTION Disc brakes are hot after Braking wheels are touching the Adjust linkage to clear the ground during towing. ground. transport. Raise transport axle higher. Transport brakes not working. Electrical connections faulty. Check all wiring and connections. Towing vehicle control not working.
  • Page 74 Maintenance Troubleshooting (Cont’d) PROBLEM POSSIBLE CAUSE SOLUTION Bag pan tarp not rolling in. Motor is not working. Replace motor. Motor is not receiving power. Replace wiring. Clean electrical connections. Relay is burned out. Replace relay. Relay not receiving a power signal. Verify signal controller delivering power.
  • Page 75 Maintenance Troubleshooting (Cont’d) PROBLEM POSSIBLE CAUSE SOLUTION Swing auger making noise. Running with pan at top of cylinder Use hydraulics to lower the pan. stroke. Chain connection worn. Inspect/repair/replace. Lower shaft rusted to u-joint. Clean connection, u-joint is designed to slide on the shaft (no set screws).
  • Page 76 Maintenance Grain Bag Loader OM...

  • Page 77: Parts Identification

    Parts Identification PARTS IDENTIFICATION SCHEMATICS Grain Bag Loader OM...

  • Page 78: Base Assembly - Gbl12 And Gbl12C

    Parts Identification Base Assembly - GBL12 and GBL12C For parts breakdown of item 1 (N40131), see page 83. For parts breakdown of item 5 (N33583), see page 80. For parts breakdown of item 6 (N30629), see page 82. QTY. PART # DESCRIPTION N40131 CRANE, GBL 12...

  • Page 79: Base Assembly (Cont'd) - Gbl12 And Gbl12C

    Parts Identification Base Assembly (Cont’d) - GBL12 and GBL12C QTY. PART # DESCRIPTION 4000 BOLT, 1/4" x 1" GRADE 5 N26743 BOLT, 3/8" x 1" SER FLG 4065 WASHER, 3/8" LOCK N16290 LIGHT, RIGHT N16289 LIGHT, LEFT N23656 BRACKET, GBU LIGHT RIGHT N23657 BRACKET, GBU LIGHT LEFT N105230...

  • Page 80: Base Assembly (Cont'd) - Gbl12 And Gbl12C

    Parts Identification Base Assembly (Cont’d) - GBL12 and GBL12C For parts breakdown of item 17 (N27684), see page 76. For parts breakdown of item 18 (N37358), see page 81. Grain Bag Loader OM...
  • Page 81 Parts Identification Base Assembly (Cont’d) - GBL12 and GBL12C QTY. PART # DESCRIPTION 203141 CABLE, GBL HITCH WINCH 25' N29079 FERRULE, 1/4" CABLE DOUBLE N10177 LINK, 3/8" CHAIN CONNECTOR N22914 TURNBUCKLE, HOOK AND EYE 3/8" N23763 NUT, JAM 3/8" LEFT HANDED THREAD 4061 NUT, 3/8"...

  • Page 82: Base Assembly, Bag Pan And Flap (Cont'd) - Gbl12 And Gbl12C

    Parts Identification Base Assembly, Bag Pan and Flap (Cont’d) - GBL12 and GBL12C For parts breakdown of item 1 (N27684), see page 76. Grain Bag Loader OM...
  • Page 83 Parts Identification Base Assembly, Bag Pan and Flap (Cont’d) - GBL12 and GBL12C QTY. PART # DESCRIPTION N27684 PAN, GBL12 WITH TARP 4092 PIN COTTER 5/32" X 2" 4071 WASHER, 3/4" FLAT N23728 PIN, 3/4" X 2-3/4" PLATED 1355 BOLT, CARRIAGE 3/8" X 1-1/2" 4064 WASHER, FLAT 3/8"...

  • Page 84: Bag Pan Assembly (N27684) - Gbl12 And Gbl12C

    Parts Identification Bag Pan Assembly (N27684) - GBL12 and GBL12C 12 13 16 17 18 8 Grain Bag Loader OM...
  • Page 85 Parts Identification Bag Pan Assembly (N27684) - GBL12 and GBL12C QTY. PART # DESCRIPTION N29025 PIPE, GBL12 PAN BAG ROLL-IN N40024 TARP, GBL12 BAG PAN 4156 RIVET, 3/16 X 1/2" N27268 PAN, GBL12 BOTTOM N27656 ROLLER, GBL12 PAN TARP 4005 BOLT, 3/8"...

  • Page 86: Base Assembly (Cont'd) - Gbl12 And Gbl12C

    Parts Identification Base Assembly (Cont’d) - GBL12 and GBL12C 10 9 For parts breakdown of item 14 (N27581), see page 124. Grain Bag Loader OM...
  • Page 87 Parts Identification Base Assembly (Cont’d) - GBL12 and GBL12C QTY. PART # DESCRIPTION 4054 NUT, LOCK 1/2" TOP 4486 WASHER, 1/2" FLAT 4012 BOLT, 1/2" X 1-1/4" GRADE 5 N25105 TOOLBOX, WINCH STORAGE 4978 BOLT, 3/8" X 3-1/4" GRADE 5 4064 WASHER, FLAT 3/8"...

  • Page 88: Bag Lift Cradle (N33583) - Gbl12 And Gbl12C

    Parts Identification Bag Lift Cradle (N33583) - GBL12 and GBL12C QTY. PART # DESCRIPTION N85400 CRADLE, GBL12 ONE PIECE 4336 CLIP, HAIRPIN 1/8" X 2-1/4" N27765 PULLEY, 5/16” X 3-1/2” DIA HIGH STRENGTH 4358 PIN, 3/4" X 2-1/4“ Grain Bag Loader OM...

  • Page 89: Bungy Assembly (N37358) - Gbl12 And Gbl12C

    Parts Identification Bungy Assembly (N37358) - GBL12 and GBL12C QTY. PART # DESCRIPTION N29233 HOOK, 3/8" SNAP N27685 ROPE, GBL12 BUNGY CORD N27336 CORD, GBL12 BUNGY W/HOOKS Grain Bag Loader OM...

  • Page 90: Auger Body Sleeve (N30629) - Gbl12 And Gbl12C

    Parts Identification Auger Body Sleeve (N30629) - GBL12 and GBL12C QTY. PART # DESCRIPTION 4064 WASHER, FLAT 3/8" 4065 WASHER, 3/8" LOCK 4232 BOLT, 3/8" x 1 3/4" GRADE 5 4233 NUT, STANDARD 3/8" 4369 WASHER, 5/16" FLAT 4478 BOLT, 3/8" x 3" GR 5 FULL THRD N30583 RING, GBL12 AUG BODY SLV TOP N30587...

  • Page 91: Crane Assembly (N40131) - Gbl12 And Gbl12C

    Parts Identification Crane Assembly (N40131) - GBL12 and GBL12C For parts breakdown of item 6 (N27680), see page 84. QTY. PART # DESCRIPTION 4528 BOLT, 1/4" x 1 - 1/4" GRADE 5 N25234 CLAMP, LOOP 1/2" x 1 - 3/4" VINYL 4231 WASHER, LOCK 1/4"...

  • Page 92: Beam Winch Trolley Lift Assembly (N27680) - Gbl12 And Gbl12C

    Parts Identification Beam Winch Trolley Lift Assembly (N27680) - GBL12 and GBL12C Grain Bag Loader OM...
  • Page 93 Parts Identification Beam Winch Trolley Lift Assembly (N27680) - GBL12 and GBL12C QTY. PART # DESCRIPTION N16351 BOLT, 3/4" X 6-1/2" FN TH GR 8 4071 WASHER, 3/4" FLAT N27682 BRACKET, GBL12 WINCH TROL LEFT N27695 ROLLER, TROLLEY 2000# 4994 WASHER, 3/4ID X 1-1/4OD X .048 N27766 BUSHING, GBL12 TROLLEY SPACER...

  • Page 94: Gbl12 Front Frame Assembly - Gbl12 Only

    Parts Identification GBL12 Front Frame Assembly - GBL12 only For parts breakdown of item 1 (N30147), see page 118. Item 7 Strap (N27753) For parts breakdown of item 2 (N29023), from Detail A shown secured see pages 87 through 96. into position with hardware.

  • Page 95: Gbl12 Front Frame Hitch Assembly - Gbl12 Only

    Parts Identification GBL12 Front Frame Hitch Assembly - GBL12 only QTY. PART # DESCRIPTION 4014 BOLT, 1/2" X 1-3/4" GRADE 5 4486 WASHER, 1/2" FLAT 4054 NUT, LOCK 1/2" N27666 BRACKET, GBL12 AUG LOCK DOWN N29022 PLATE, GBL12 AUGER BOTTOM SUP N25166 CYLINDER, HYD 4"...

  • Page 96: Gbl12 Front Frame Hitch Assembly (Cont'd) - Gbl12 Only

    Parts Identification GBL12 Front Frame Hitch Assembly (Cont’d) - GBL12 only 7 11 27 26 For parts breakdown of item 5 (N30092), see page 123. For parts breakdown of item 29 (N30133), see page 126. Grain Bag Loader OM...
  • Page 97 Parts Identification GBL12 Front Frame Hitch Assembly (Cont’d) - GBL12 only QTY. PART # DESCRIPTION N50260 CHAIN, SAFETY 21,000 LB W/HDWR 4996 NUT, LOCK 1/4" NYLOCK 3183 WASHER, FLAT 1/4" 4999 BOLT, 1/4" X 1-1/2" GRADE 5 N30092 WIRE, BRAKE BATTERY 4006 BOLT, 3/8"...
  • Page 98 BOLT, 3/8" X 1" SER FLG N39055 CHARGER, CAR MICRO USB N33024 LANYARD, LOFTNESS KEYCHAIN N19600 HOLDER, 01-315A STND . MANUAL 4340 BOLT, 1/4" X 3/4" GRADE 5 N39094 RECEIVER, 3 CONTACT LOFTNESS N16133 NUT, NYLON INSERT #8 Grain Bag Loader OM...
  • Page 99 Parts Identification This page intentionally left blank. Grain Bag Loader OM...

  • Page 100: Front Frame Assembly - Gbl12 Only

    Parts Identification Front Frame Assembly - GBL12 only For parts breakdown of item 1 (N29551), see page 93. For parts breakdown of item 11 (N30156), see page 120. For parts breakdown of item 14 (N30155), see page 120. QTY. PART # DESCRIPTION N29551 AUGER, GBL12 COMP SPLIT...

  • Page 101: Split Auger (N29551) - Gbl12 Only

    Parts Identification Split Auger (N29551) - GBL12 only For parts breakdown of item 16 (N29566), see page 96. QTY. PART # DESCRIPTION 4013 BOLT, 1/2" X 1 - 1/2" GRADE 5 4014 BOLT, 1/2" X 1 - 3/4" GRADE 5 4039 BOLT, CARRIAGE 1/2"...

  • Page 102: Front Boot Assembly - Gbl12 Only

    Parts Identification Front Boot Assembly - GBL12 only Grain Bag Loader OM...
  • Page 103 BOLT, 1/2" x 1 - 1/4" GR 5 N26670 WASHER, LOWER FLIGHT RETAINING N26693 SHAFT, DRIVE GEARBOX B003008 N26677 PLATE, BOOT FACE N26760 PLATE, LOFTNESS SERIAL NO . N26675 DOOR, CLEAN OUT N19307 NUT, WING 3/8" 4065 WASHER, LOCK 3/8" 4064 WASHER, FLAT 3/8"...

  • Page 104: Auger Hanger Mount (N29566) - Gbl12 Only

    Parts Identification Auger Hanger Mount (N29566) - GBL12 only QTY. PART # DESCRIPTION 4170 NUT, LOCK 7/8 TOP N29567 BRACKET GBL12 AUGER HANGER N29579 SHIM, GBL12 AUG BRKT N29580 WASHER, FLAT 7/8" N29581 BOLT, 7/8" X 3" GR 5 N30241 BEARING, 2-15/16"...

  • Page 105: Swing Auger Components (N29114) - Gbl12 Only

    Parts Identification Swing Auger Components (N29114) - GBL12 only For parts breakdown of item 1 (N33220), see page 108. For parts breakdown of item 2 (N29066), see pages 104 through 107. For parts breakdown of item 3 (N29230), see page 98. QTY.

  • Page 106: Swing Auger Components Without Pan (N29230) - Gbl12 Only

    Parts Identification Swing Auger Components without Pan (N29230) - GBL12 only See page 100 for the swing auger component hydraulic diagram and hose routing. For parts breakdown of items 8 (N27942) and 9 (N29041), see page 102. For parts breakdown of item 13 (N27851), see page 101. Grain Bag Loader OM...
  • Page 107 Parts Identification Swing Auger Components without Pan (N29230) - GBL12 only QTY. PART # DESCRIPTION N28436 BOLT, 5/16" X 2-1/4" GR5 4228 WASHER, 5/16" LOCK N28927 WASHER, FLAT 5/16 SAE N37627 VALVE, 2 SECTION M45 HYD CONT N47855 BOLT, 3/8" X 1-1/4" SER FLG N40051 ADAPTER PLATE 4979...

  • Page 108: Gbl12 Hydraulic Diagram - Gbl12 Only

    Parts Identification GBL12 Hydraulic Diagram - GBL12 only QTY. PART # DESCRIPTION 8287 CYLINDER, HYDRAULIC 2" x 6" N20037 ELBOW, 90 DEG - 6MJIC - 8MOR N28837 ELBOW, 45 DEG - 6MJC - 6FJC N27926 HOSE, 3/8" HYD 78” - 6FJC - 6FJC N27928 ELBOW, 45 DEG - 6MJC - 8MOR N27605...

  • Page 109: Swing Auger Drive (N27851) - Gbl12 Only

    Parts Identification Swing Auger Drive (N27851) - GBL12 only For parts breakdown of item 5 (N27532), see below. QTY. PART # DESCRIPTION 4099 PIN, COTTER 1/8" x 1 - 1/2" 8287 CYLINDER, HYDRAULIC 2" x 6" N27520 LINK, GBL AUGER DRIVE LONG N27526 LINK, GBL AUGER DRIVE SHORT N27532...

  • Page 110: Swing Auger - Gbl12 Only

    Parts Identification Swing Auger - GBL12 only 25 24 29, 15 29, 15 Grain Bag Loader OM...
  • Page 111 Parts Identification Swing Auger - GBL12 only QTY. PART # DESCRIPTION N30407 TUBE, GBL12 SWING AUG 14" N30408 AUGER, GBL12 SWING 14" 7189-03 KEY, 5/16" x 1-1/2" N26730 GEARBOX, HD-UPPER, 13" HP MDSA N26731 U - JOINT, 1 - 3/8" x 21 SPLINE 4011 BOLT, 1/2"...

  • Page 112: Swing Hopper Main Assembly - Gbl12 Only

    Parts Identification Swing Hopper Main Assembly - GBL12 only 10 12 32 34 QTY. PART # DESCRIPTION N26734 HOPPER, BD LOADER WELD N27942 TUBE, GBL12 SWING AUGER (W/AUGER) N31081 HANGER, DRIVELINE ASSEMBLY N26733 FLIGHT, 13" HP HOPPER LONG N26695 WHEEL, 10" OD x 3/4" BORE N26736 DRIVESHAFT, HOPPER 13"...
  • Page 113 Parts Identification Swing Hopper Main Assembly - GBL12 only QTY. PART # DESCRIPTION N26698 STRAP, HOLD DOWN N26739 GRATE, HOPPER SAFETY LONG N26699 RETAINER, HOPPER MESH N26741 BOLT, CARRIAGE 5/16" x 1" N26742 NUT, 5/16" FLANGE LOCK N26700 COVER,TRANSITION N26701 PLATE, BAFFLE N31083 MOUNT, TRANSITION ASSEMBLY...

  • Page 114: Swing Hopper Drive - Gbl12 Only

    Parts Identification Swing Hopper Drive - GBL12 only 11, 12, 13 11, 12, 13 Grain Bag Loader OM...
  • Page 115 Parts Identification Swing Hopper Drive - GBL12 only QTY. PART # DESCRIPTION N26709 PLATE, CHAIN TENSION N26744 BOLT, 5/16" x 2" FULL THREAD 4237 NUT, STANDARD 5/16" N26710 BEARING, 1" - 2 BOLT FLANGETTE N26741 BOLT, 5/16" x 1" CARRIAGE N26742 NUT, 5/16"...

  • Page 116: Swing Auger Hopper Lift (N33220) - Gbl12 Only

    Parts Identification Swing Auger Hopper Lift (N33220) - GBL12 only 15 20 Grain Bag Loader OM...
  • Page 117 Parts Identification Swing Auger Hopper Lift (N33220) - GBL12 only QTY. PART # DESCRIPTION 4014 BOLT, 1/2" x 1 3/4" GRADE 5 4029 BOLT, 3/4" x 6" GRADE 5 4052 NUT, LOCK 3/8" 4054 NUT, LOCK 1/2" TOP 4056 NUT, LOCK 3/4" 4064 WASHER, FLAT 3/8"...

  • Page 118: Gbl12C Front Frame Assembly - Gbl12C Only

    Parts Identification GBL12C Front Frame Assembly - GBL12C only For parts breakdown of item 1 (N30147), see page 118. For parts breakdown of item 2 (N30872), see pagess 111 through 115. QTY. PART # DESCRIPTION N30147 HOPPER, GBL12 COMPLETE WITH EXT Reference N30872 HITCH, GBL12C FRONT FRAME...

  • Page 119: Gbl12C Front Frame Hitch Assembly (N30872) - Gbl12C Only

    Parts Identification GBL12C Front Frame Hitch Assembly (N30872) - GBL12C only QTY. PART # DESCRIPTION 4015 BOLT, 1/2" X 2" GRADE 5 4486 WASHER, 1/2" FLAT N27666 BRACKET, GBL12 AUG LOCK DOWN 4054 NUT, LOCK 1/2" TOP N29022 PLATE, GBL12 AUGER BOTTOM SUP N18360 BOLT,1/2-13 X 1-1/4 SER FLG N33379...

  • Page 120: Gbl12C Front Frame Assembly - Gbl12C Only

    Parts Identification GBL12C Front Frame Assembly - GBL12C only For parts breakdown of item 4 (N30092), see page 123. For parts breakdown of item 14 (N30133), see page 126. Grain Bag Loader OM...
  • Page 121 PIN COTTER 5/32" X 2" N39055 CHARGER, CAR MICRO USB N33024 LANYARD, LOFTNESS KEYCHAIN N19600 HOLDER, 01-315A STND .MANUAL 4340 BOLT, 1/4" X 3/4" GRADE 5 N39094 RECEIVER, 3 CONTACT LOFTNESS N16133 NUT, NYLON INSERT #8 Grain Bag Loader OM...

  • Page 122: Gbl12C Front Frame Assembly (Cont'd) - Gbl12C Only

    Parts Identification GBL12C Front Frame Assembly (Cont’d) - GBL12C only 20 19 15 14 For parts breakdown of item 1 (N30156), see page 120. For parts breakdown of item 4 (N30155), see page 120. Grain Bag Loader OM...
  • Page 123 Parts Identification GBL12C Front Frame Assembly (Cont’d) - GBL12C only QTY. PART # DESCRIPTION N30156 AXLE, GBU12 RIGHT WIRED 4436 NUT, 1/2" LOCK FN TD GRADE 8 4330 BOLT, 1/2" X 7" GR 8 N30155 AXLE, GBU12 LEFT WIRED N30863 HOLDER, GBL10 PTO END 4052 NUT, LOCK 3/8"...

  • Page 124: 20" Front Auger - Gbl12C Only

    Parts Identification 20" Front Auger - GBL12C only * Parts breakdown of item 1 (N30866) Grain Bag Loader OM...
  • Page 125 Parts Identification 20" Front Auger - GBL12C only QTY. PART # DESCRIPTION N30866 AUGER, GBL12C COMP N30531 AUGER, GBL12C PUR 18" N16351 BOLT, 3/4" X 6-1/2" FN TH GR 8 4071 WASHER, 3/4" FLAT N16352 NUT, LOCK 3/4" GRADE 8 FINE N30870 BUSHING, GBL12C AUGER SHAFT N30871...

  • Page 126: Hopper With Extension (N30147) - Gbl12 And Gbl12C

    Parts Identification Hopper with Extension (N30147) - GBL12 and GBL12C For parts breakdown of item 7 (N27322), see page 119. QTY. PART # DESCRIPTION N29263 PANEL, GBL12 HOPPER EXT FR/BK1 N29266 PANEL, GBL12 HOPPER FR/BK2 N29265 PANEL, GBL12 HOPPER EXT SCAB N18360 BOLT, 1/2-13 X 1-1/4 SER FLG N29262...

  • Page 127: Hopper Hardware (N27322) - Gbl12 And Gbl12C

    Parts Identification Hopper Hardware (N27322) - GBL12 and GBL12C QTY. PART # DESCRIPTION N18360 BOLT, 1/2-13 X 1-1/4 SER FLG N29075 NUT, LOCK 1/2" SERRATED FLANGE N22909 CORNER, GBL HOPPER TOP N27339 BRACE, GBL12 HOPPER N27335 PANEL, GBL12 HOPPER FRONT/BACK N27338 PANEL, GBL12 HOPPER SIDE N27323...

  • Page 128: Right Transport Axle Wired (N30156) - Gbl12 And Gbl12C

    Parts Identification Right Transport Axle Wired (N30156) - GBL12 and GBL12C QTY. PART # DESCRIPTION N19839 SHROUD, WP CONTACT 2 - WAY N30154 AXLE, STUB 6000 LB HALF RIGHT N30066 SEAL, WP 14 - 16 GA N30067 TERMINAL, WP MALE 14 - 16 GA Left Transport Axle Wired (N30155) - GBL12 and GBL12C QTY.

  • Page 129: Hub Assembly, Traction/Brake Wheel

    Parts Identification Hub Assembly, Traction/Brake Wheel QTY. PART # DESCRIPTION N29957 SPINDLE, AXLE 6000 LB HALF N29958 SEAL, AXLE 6000 LB OIL (1056) N29959 CONE, AXLE 6000 LB INNER BRG (3984) N29960 CUP, AXLE 6000 LB INNER BRG (3920) N29961 DRUM, AXLE 6000 LB BRAKE (9271) N29962 STUD, AXLE 6000 LB WHEEL MNT (7115)

  • Page 130: Hub, 8 Bolt 8" Diameter (N25138) - Gbl12 And Gbl12C

    Parts Identification Hub, 8 Bolt 8" Diameter (N25138) - GBL12 and GBL12C QTY. PART # DESCRIPTION N157998 HUB, 8-BOLT SUBASSEMBLY N158004 CUP, BEARING 8-BOLT HUB 8082-02 CUP, BEARING (LARGE) 6BLT. HUB LM501310 N158000 STUD, HUB 5/8"-18 UNF 2-3/4" N157999 CASTING, HUB 8-BOLT (NO PARTS) N158001 NUT, LUG 5/8-18 UNF GR 5 ZP N158003...

  • Page 131: Brake Battery Wired (N30092) - Gbl12 And Gbl12C

    Parts Identification Brake Battery Wired (N30092) - GBL12 and GBL12C QTY. PART # DESCRIPTION N19840 TOWER, WP CONTACT 2 - WAY N29355 BATTERY, BRAKE AWAY SYSTEM N30066 SEAL, WP 14 - 16 GA N30067 TERMINAL, WP MALE 14 - 16 GA N30068 TERMINAL, WP FEMALE 14 - 16 GA N30069...

  • Page 132: Brake Actuator (N27581) - Gbl12 And Gbl12C

    Parts Identification Brake Actuator (N27581) - GBL12 and GBL12C QTY. PART # DESCRIPTION 4098 PIN, COTTER 1/8" x 1 - 1/2" N27571 ADAPTER, GBL BRAKE PSHR INNER N27578 RING, SNAP 1 - 7/8" ID N27572 BEARING, INSERT 0 .7874 ID DOUBLE ROW N27575 WASHER, GBL BRAKE TUBE PSHR N27577...

  • Page 133: Brake Caliper (N22794) - Gbl12 And Gbl12C

    Parts Identification Brake Caliper (N22794) - GBL12 and GBL12C WILWOOD BRAKE CALIPER SERVICE PARTS DESCRIPTION WILWOOD P/N LOFTNESS P/N " " Cotter Pins 1/8 (Forged Billet Dynalite Caliper) WIL - 180 - 0055 N26517 Set of 10 Caliper Body Seal (Sold Separately)

  • Page 134: Brake Wiring Diagram (N30114) - Gbl12 And Gbl12C

    Parts Identification Brake Wiring Diagram (N30114) - GBL12 and GBL12C NOTE: TO ORDER A COMPLETE BRAKE WIRING KIT, ITEMS 3, 5, 7 & 8 USE PART NUMBER N30133. QTY. PART # DESCRIPTION N30156 AXLE, GBU12 RIGHT WIRED N30155 AXLE, GBU12 LEFT WIRED N30083 WIRE, GBU12 LEFT BRAKE N30086...

  • Page 135: Brake Diagram (N29035) - Gbl12 And Gbl12C

    Parts Identification Brake Diagram (N29035) - GBL12 and GBL12C NOTE: TO ORDER A COMPLETE BRAKE HOSE KIT, ITEMS 2, 3, 4, 5, 6, 8, 9, 10 &11 USE PART NUMBER N29032. QTY. PART # DESCRIPTION N22794 CALIPER, WILWOOD BRAKE N23939 ELBOW, 90 DEG - 4MJIC - 2NPT N25220 HOSE, 1/8"...

  • Page 136: Hydraulic Lift Schematic (N29040) - Gbl12 And Gbl12C

    Parts Identification Hydraulic Lift Schematic (N29040) - GBL12 and GBL12C NOTE: TO ORDER A SEAL KIT FOR ITEM 1 (N25166), USE PART NUMBER N26542. TO ORDER A COMPLETE HOSE KIT, ITEMS 2, 3, 4, 5, 6, 7, 8, 9, USE PART NUMBER N29037.

  • Page 137: Wiring Diagram (N157277) - Gbl12 And Gbl12C

    DESCRIPTION N27660 MOTOR, ELECTRIC 1/2 HP N37300 WINCH, WARN PROVANTAGE 4500 N30833 CABLE, GBL10 6 GA WINCH IMP N39094 RECEIVER, 3 CONTACT LOFTNESS N39055 CHARGER, CAR MICRO USB N157800 HARNESS, GBL12A SWG AUG WINCH N26639 HARNESS, GBL12 MAIN POWER N26638...

  • Page 138: Pto Driveline (N29020) - Gbl12 Only

    Parts Identification PTO Driveline (N29020) - GBL12 only QTY. PART # DESCRIPTION N26772 YOKE, 1 - 3/8" - 21 SPL . ASGE N23479 KIT, WALT PTO CROSS & BEARING N23711 YOKE, WALT INBOARD S4 N23480 PIN, WALT PTO SPRING 10 x 80 N26773 SHAFT, INNER PROFILE S4 N26774...

  • Page 139: Pto Driveline (N29021) - Gbl12 Only

    Parts Identification PTO Driveline (N29021) - GBL12 only QTY. PART # DESCRIPTION N26781 YOKE, 1 - 3/4" - 20 SPL . ASG N23479 KIT, WALT PTO CROSS & BEARING N23711 YOKE, WALT INBOARD S4 N23480 PIN, WALT PTO SPRING 10 x 80 N26773 SHAFT, INNER PROFILE S4 N26774...

  • Page 140: Pto Driveline (N30626) - Gbl12C Only

    Parts Identification PTO Driveline (N30626) - GBL12C only 13 5 15 16 QTY. PART # DESCRIPTION N35476 HALF, 1-3/8" 1000 RPM 35E PTO N35477 HALF, 1-3/4" 1000 RPM 35E PTO 8209-01 KIT, COLLAR AND PAWL N35478 ASM, SAFE SLIDE LOCK YOKE N35479 KIT, 35E SERIES CROSS REPAIR N35480...

  • Page 141: Pto Driveline (N30627) - Gbl12C Only

    Parts Identification PTO Driveline (N30627) - GBL12C only 13 5 15 16 QTY. PART # DESCRIPTION N35487 HALF, 1-3/4" 1000 RPM 35E PTO N35477 HALF, 1-3/4" 1000 RPM 35E PTO 8624-01 KIT, SLIDE LOCK REPAIR 1-3/4" N35488 ASM, SAFE SLIDE LOCK YOKE N35479 KIT, 35E SERIES CROSS REPAIR N35480...
  • Page 142 Grain Bag Loader OM...

  • Page 143: Appendix

    Appendix Specifications - GBL12 DESCRIPTION GRAIN BAG LOADER (GBL12) Operating Capacity 500 Bushels/Min Operating Weight 13,020 LB . Minimum Tractor Horsepower 120 HP Maximum Rear–PTO RPM 1000 RPM Hydraulic Flow 6 GPM Main Discharge Auger 20" Main Auger Drive 1 - 3/4 - 20 Spline Wheels 15L - 19 .5 Suregrip Traction PTO Driveline...

  • Page 144: Dimensions - Gbl12

    Appendix Dimensions - GBL12 Transportation 175" (14' 7") 31" (2' 7") 164 " 141 in. (13' 8") (11' 9") 110" (9' 2") 236" (19' 8") 341" (28' 5") 236" (19' 8") 390" (32' 6") Grain Bag Loader OM...

  • Page 145: Dimensions - Gbl12C

    Appendix Dimensions - GBL12C Transportation 175" (14' 7") 31" (2' 7") 159 in. 138 in. (13' 3") (11' 6") 110" (9' 2") 236" (19' 8") 251" (20' 11") 236" (19' 8") 291" (24' 3") Grain Bag Loader OM...

  • Page 146: Dimensions (Cont'd)

    Appendix Dimensions (Cont’d) DESCRIPTION GBL12 (W/SWING AUGER) Operating Height 153 in . (12' 9") - (388 .6 cm) - Varies Operating Width 340 in . (28' 4") - (863 .6 cm) Operating Length 390 in . (32' 6") - (990 .6 cm) Transport Height 153 in .

  • Page 147: Torque Specifications

    Appendix Torque Specifications Inches Hardware and Lock Nuts Grain Bag Loader OM...

  • Page 148: Metric Hardware And Lock Nuts

    Appendix Torque Specifications (Cont’d) Metric Hardware and Lock Nuts Grain Bag Loader OM...
  • Page 150 Loftness Specialized Equipment, Inc. 650 So. Main Street • PO Box 337 • Hector, MN 55342 Tel: 320.848.6266 • Fax: 320.848.6269 • Toll Free: 1.800.828.7624 Printed in USA © Loftness 2018...

This manual is also suitable for:

Grainlogix gbl12a

Table of Contents
