- Page 1 HOIST ® Power Installation Instructions Hoistatop.com Lange Originals 3651 S. 700 E. Salt Lake City, UT 801-262-7322...
- Page 2 PLEASE READ ALL INSTRUCTION BEFORE INSTALLATION Parts List This list may include optional items, from other Hoist-a-Top® systems, as well as a list of common parts included in all hoists. Parts are listed by part number, description, and quantity. The part number may be referenced in the instructions designated by parenthesis () for your convenience.
- Page 3 We use these products ourselves and like them, we hope you will too. Lange Originals® is not responsible for damage or personal injury due to improper installa- tion, custom installation that doesn’t follow the instructions, or neglect.
- Page 4 Ceiling Mounting Overhead mounting the power unit: To determine a suitable lifting point from the ceiling, back your Jeep in the garage to a suitable parking spot and run a plumb-bob from the center of your hardtop to the ceiling and make a mark with a pencil. Make sure you still have room to open your tailgate.
- Page 5 Determine if your studs run Ceiling mount perpendicular or Parallel with with perpendicular studs your garage door. If your Back wall or garage door studs run perpendicular to Power Unit Drop cable (or the opposite direction as your garage door). Center the two 2x6 ‘s Cribbing between the area you...
- Page 6 Ceiling mount Parallel stud configuration with parallel studs Back wall or garage door Install two cross braced 2x4 cribbed cross 2x4’s laying flat longer brace laying flat on Lag Bolt (4a) than the length of the gap 16 inch centers between studs (typically Lag Bolt (4a) Drop cable...
- Page 7 Sidewall/Back-wall mount: Back your Jeep into your garage and determine a lifting point from the ceiling. Run a plumb-bob from the center of your hardtop to the ceiling and make a mark with a pencil. Draw a straight line to the wall you want your power unit on.
- Page 8 Install two cross braced 2x6’s laying flat longer than the length of the Perpendicular Stud Wall gap between studs centered on the middle mark you drew with your Mounting pencil and plumb bob. The pulleys should be installed 32 inches apart centering the pulley wheels.
- Page 9 HOIST ® Frame Assembly Begin frame assembly by locating the T shaped bar (2) depressing the spring buttons and sliding the front arms (1) into the T shaped bar with the spring button facing up (corresponding with the drilled holes in the T) and moving them to the appropriate holes (see frame assembly fig.
- Page 10 TJ YJ CJ Setting JK 4 Door Setting JK 2 Door Setting JK 2 Door Setting JK 4 Door Setting TJ YJ CJ Setting Fig. 3 front settings on frame for JK 2 door Frame Assembly video www.langeinstructions.com Fig. 4 Underside look at the correct place- ment of the rear arm TJ YJ CJ Setting...
- Page 11 Balancing and attaching the frame TEST YOUR INSTALL WITH WEIGHT AND INSPECT BEFORE CONTINUING! If you have not done so put your safety stop loosely in place before this step. With your frame assembled (see Fig. 1-4) lay it on the floor directly below the cables with the top of the “T” shape of the frame facing your garage door.
- Page 12 facing up flipped directly on the frame and foam on the same side from where they were removed. The bungee cords hook from the grommet straps to any free hole in the lifting blade, holding them in place. Final leveling of the hard top is achieve by loosening the cable clamps and removing some slack from the dipping side.
- Page 13 The documents and instructions in this product are subject to copyright ©2016 all rights reserved. Hoist A Top, Off With Your Top, Lange Originals, are registered trademarks of Lange Originals LLC. Hoist A Top, Hoist A Cart, Hoist A Top Simple, are protected by the following patents 009932209B2 Chrysler, Dodge, Jeep, Ram, Mopar and SRT are registered trademarks of FCA US LLC.
- Page 14 10. Minor cosmetic issues such as paint flaws, mis-shaped foam pieces that do not affect the function of the product as determined by Lange. Lange Originals LLC reserves the right to change this document at any time and is not limited to the terms and conditions described here. For a comprehensive warranty on your specific part number/product please visit us at www.langeoriginals.com...
