Inncom e4 General Description page 2

OPERATION:
In its most basic form, the e4 functions as a high quality
DDC thermostat, automatically adjusting fan speeds and valves to
achieve set temperature. In its EMS mode, the e4 receives
inputs from the PIR motion detector and INNCOM's wireless
door switch. When it determines that the guestroom is
unoccupied, the temperature is allowed to drift up or down
within a programmable setback band in order to save energy.
When the e4 becomes part of a centrally controlled system
connected to INNCOM's CINET, substantial additional energy savings
are achieved by using a broader setback band when the guestroom
is unrented.
In addition, the e4 may use its control assembly to receive
inputs from monitorable points in the room, such as a balcony
door, minibar, or smoke detector.
INSTALLATION:
The e4 is wired as a low voltage wall thermostat with 3 wires.
Total installation time for both the e4 and INNCOM's wireless
door switch is typically less than 45 minutes per room. Adding
the CINET for central control requires additional time.
Leaders in Integrated Guestroom Control Systems...Worldwide!
TEL: (860) 739-4468 · FAX: (860) 739-4460 · EMAIL: sales@inncom.com · WEBSITE: www.INNCOM.com
FEATURES:
• Advanced energy management
• Customer programmable parameters
• Low acquisition and low installation costs
• Precision DDC temperature control for enhanced
guest comfort
• Ideally suited for retrofit as well as new
construction or refurbishment projects
• Expandability to include functions best suited
to each hotel's needs, such as:
• Multi-point lamp control
• Minibar and safe monitoring
• Smoke detector annunciation
• Balcony door monitoring
• Optional central control and monitoring
of all above
• Aesthetically pleasing appearance
SPECIFICATIONS:
Dimensions: 3.5"W x 3.5"H x 0.9"D
(89 mm x 89 mm x 23 mm)
Operating Range:
Power In:
Temperature: ± 1°F
(± 0.5°C 15°C to 30°C)
OPTIONS:
• Mounting Plate
• Construction Dust Cover
41°F to 149°F
(5°C to 65°C)
12 VDC
60°F to 85°F
