3D innovations DeskCycle Ellipse User Manual

Hide thumbs

Table Of Contents

QUESTIONS / PROBLEMS

Support and Contact:

See the support link at DeskCycle.com

Phone (US customers):

877-426-3292

DeskCycle

USER'S MANUAL

www.DeskCycle.com

Visit us at

•

Usage Tips

•

Calorie Calculator

•

Accessories

•

And More

Order# _____________________

Serial# _____________________

The serial number is on the bottom of

the DeskCycle.

™

Ellipse

for:

Table of Contents

Need help?

Do you have a question about the DeskCycle Ellipse and is the answer not in the manual?

Questions and answers

Linda Anderson

February 19, 2025

After using this for two weeks, it's developed a clunking noise when pedaling, which I can't have as I work around other people. Is there an easy fix for this? This was delivered on February 3rd, today is the 19th, and I don't work in the office on Fridays, so it's only been used maybe 8 days.

1 comments:

Mr. Anderson

February 19, 2025

The manual does not provide specific troubleshooting steps for a clunking noise. However, you can try the following:

1. Check the Pedals – Ensure that the pedals are screwed in as tightly as possible. Loose pedals can cause noise and may damage the crank arm threads.
2. Inspect for Loose Bolts – Verify that all bolts, including those on the pedals, are properly tightened using the provided hex wrench.
3. Ensure Proper Usage – Use the DeskCycle only while sitting and on a level surface to prevent unnecessary strain or damage.
4. Avoid Excessive Shock – Do not subject the bike to heavy impact or disassemble it, as this may void the warranty.

If the problem continues, contact DeskCycle support through their website or phone number for assistance.

This answer is automatically generated

Summary of Contents for 3D innovations DeskCycle Ellipse

Page 1 ™ DeskCycle ™ Ellipse USER’S MANUAL www.DeskCycle.com Visit us at for: • Usage Tips • Calorie Calculator • Accessories • And More Order# _____________________ QUESTIONS / PROBLEMS Support and Contact: See the support link at DeskCycle.com Phone (US customers): Serial# _____________________ 877-426-3292 The serial number is on the bottom of the DeskCycle.
Page 2 Precautions And Safety Precautions Failure to observe these warnings could result in physical injury and/or damage to the DeskCycle. • Do not stand on the pedals! Use the DeskCycle only while sitting. Standing on the pedals can damage the bike. •...
Page 3: Table Of Contents
Table Of Contents Assembly - Installing the Foot Panels Installing and Removing the Display Using the Display Display Stand for Your Desk Free Online Calorie Calculator Foot Placement for Motion Type Carrying the Bike Adjusting the Resistance Locking the DeskCycle to Your Desk Optional Accessories Care and Maintenance Support...
Page 4: Assembly - Installing The Foot Panels
Assembly - Installing the Foot Panels Step 1: Orient the Arm • Place the DeskCycle on a flat surface. • Orient the arm so the axle is at a the highest point, as shown in the drawing below. Highest Point Step 2: Install the Right Pedal There is a Right pedal and a Left pedal.
Page 5: Installing And Removing The Display
Assembly - Installing the Foot Panels Contd. Step 3: Install the Screws • Flip the arm over as shown in the drawing. • Install the two bolts and washers into the pedal. • Tighten the bolts with the provided hex wrench. •...
Page 6: Using The Display
Using the Display There are two numbers on the display; one on the top and one on the bottom. See the image below. • The Top Number always displays the total number of revolutions you’ve pedaled the bike since the display was last reset.
Page 7: Display Stand For Your Desk
Display Stand for Your Desk The DeskCycle comes with a display stand for those who use the DeskCycle at their desks. The Display Stand lets you place your display anywhere on your desktop. Connection Instructions: 1. Plug one end of the extension cable into the back of the display.
Page 8: Foot Placement For Motion Type
Foot Placement for Motion Type The DeskCycle has longer pedals than the other desk ellipticals. This lets you choose the type of pedal motion you want. You control the type of pedal motion by where you place your feet on the pedals. Rear Foot Position for Flatter Motion Placing your heels against the rear of pedal makes your pedal motion the flattest.
Page 9: Carrying The Bike
Carrying the Bike Securing the Pedals Pedals The pedals can be secured for travel. Follow the Secured steps below to secure the pedals. 1. Align the notches in the pedals with the bungee grips. 2. Pull each bungee grip out and secure it to the pedal notch as shown in the picture to the right.
Page 10: Adjusting The Resistance
Adjusting the Resistance Adjusting the Pedal Resistance • There are 8 tension settings. • The Tension Indicator arrow points to the current tension setting. • The higher the number, the higher the pedal resistance. Locking the DeskCycle to Your Desk There is a Kensington slot on the front leg of the DeskCycle.
Page 11: Care And Maintenance
Care and Maintenance Care • Do not stand on the pedals! The DeskCycle was not designed to be used while standing. Maintenance The DeskCycle requires no maintenance. Do Not Lubricate The DeskCycle contains sealed bearings that provide many years of maintenance-free use. No lubrication is needed.
