  • Page 1 Manuale d’uso Italiano No.38111 8 Port Splitter/Transmitter No.38110 Transmitter (TX) No.38112 Receiver (RX) No.38109 Extender/Repeater (EX) www.lindy.com Tested to Comply with FCC Standards For Home and Office Use! © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - Secon EDITION (June 2018)
  • Page 2: Connection Diagram

    Connection Diagram DVD or Blu-ray Player 8 Port Cat.6 Splitter/Extender Option 1 Option 2 Option 3 HDMI Cable Cat.6 Cable (40m @ 8 Bit) (15m @ 8 Bit) Cat.6 Transmitter Cat.6 Cable (40m @ 8 Bit) Cat.6 Extender Cat.6 Cable (40m @ 8 Bit) Cat.6 Receiver HDMI Cable (15m @ 8 Bit) Option 4:...
  • Page 3: Package Contents

    English Introduction Thank you for purchasing from the LINDY HDMI Extender series. This HDMI Extender series allows you to distribute multiple displays over long distances for applications such as digital signage, public display and large scale presentations. With support for crystal-clear digital video, including 3D video, these extenders can take your distribution system to the next level.
  • Page 4: Troubleshooting

    User Manual English 6. On the 8 Port Splitter/Transmitter set the other EDID selection switch STD/TV to TV to use the TVs EDID. In this case the EDID will be read from the first display recognised starting at output port 1. (Any DVI EDID may be ignored.) If this causes problems to any of the displays connected or if you want to limit colour depth to 8 Bit switch to the STD setting: 1080p 8/12 Bit and PCM 2CH Audio.
  • Page 5 Handbuch Deutsch Einführung Mit den Geräten der LINDY HDMI Extenderserie können Sie Netzwerk mit etlichen HDMI Displays und einer HDMI Quelle einrichten. Es ist ideal geeignet für Digital Signage, öffentliche Bildschirmanzeigen, Vorführ- und Videopräsentationen und immer wenn kristallklare Bilder oder sogar 3D Inhalte verteilt werden sollen. Dieses System stellt ihr Präsentationssystem auf einen neuen Level.
  • Page 6: Fehlersuche Und -Behebung

    Handbuch Deutsch Sie erreichen wollen (siehe Connection Diagramm Seite 2). Beachten Sie bitte, dass die 12 Bit Einstellung die Cat.6 Kabellänge auf maximal 15m reduzieren kann. 6. Am 8 Port Splitter/Transmitter stellen Sie den anderen EDID Schalter STD/TV auf TV um die tatsächlichen EDID Daten des Displays/TVs zu verwenden.
  • Page 7: Caractéristiques

    38109 Extender EX Livraison  Emetteur/splitter 8 ports N° Art. 38111 ou émetteur (TX) N° Art. 38110 ou récepteur (RX) N° Art. 38112 ou Extender/Répéteur (EX) N° Art. 38109  Alimentation avec 4 adaptateurs EURO, US, UK, AUS/CN  Ce manuel Installation 1.
  • Page 8 Manuel d‘utilisateur Français diagramme à la page 2). Notez bien que le choix 12bits peut réduire la longueur de câble cat.6 jusqu’à 15m. 6. Sur l’émetteur/splitter 8 ports, mettez le switch EDID STD/TV sur la position TV pour transmettre les données EDID de l‘écran. Dans ce cas précis, les données EDID venant du 1er écran connecté, en partant du port de sortie 1, seront lues et utilisées (les données DVI EDID seront ignorées).
  • Page 9: Installazione

    Italiano Introduzione Grazie per aver acquistato un prodotto della serie HDMI Extender LINDY. Questa linea di prodotti consente di assemblare una rete di distribuzione per segnali audio/video utile per applicazioni di Digital Signage, Video pubblici, and presentazioni su larga scala anche con contenuti CrystalClear e 3D.
  • Page 10: Risoluzione Dei Problemi

    Manuale d’uso Italiano 6. Sullo Splitter/Transmitter 8 porte impostate il selettore EDID STD/TV su TV per utilizzare come default l’EDID del primo display trovato connesso a partire dalla porta output 1 (I segnali EDID di monitor DVI possono essere ignorati.) Se questa impostazione crea problemi ad uno qualsiasi dei monitor connessi o se volete limitare la profondità...
  • Page 11 LINDY Herstellergarantie – Hinweis für Kunden in Deutschland LINDY gewährt für dieses Produkt über die gesetzliche Regelung in Deutschland hinaus eine zweijährige Herstellergarantie ab Kaufdatum. Die detaillierten Bedingungen dieser Garantie finden Sie auf der LINDY Website aufgelistet bei den AGBs.
  • Page 12: Recycling Information

    Fare riferimento alle leggi del proprio Stato quando si dispone di un apparecchio elettrico o elettronico. Per ulteriori dettagli fare riferimento alla direttiva WEEE sul riciclaggio del proprio Stato. LINDY No.38109, 38110, 38111,38112 Edition, June 2018 www.lindy.com Tested to Comply with...
