- Page 1 AEROTRAK ® PORTABLE AIRBORNE PARTICLE COUNTER MODEL 9310/9350/9510/9550/9500 QUICK START GUIDE P/N 6004218, REVISION L MARCH 2018...
- Page 2 ® Thank you for purchasing a TSI AeroTrak Portable Labels Airborne Particle Counter (particle counter). This guide Advisory labels and identification labels are attached to will help you quickly begin using your particle counter. the outside of the particle counter housing and to the optics housing on the inside of the instrument.
- Page 3 Description Part/Model Reference Picture probe. ™ 7001901 Lite Secure Item CD for 21 Description Part/Model Reference Picture CFR Part 11 compliant AeroTrak ® 9310-02 data Airborne 9510-02 downloading Particle 9350-02 software Counter (includes 9350-03 manuals) 9550-02 9500-01 Operation 6002279 Included on ™...
- Page 4 2. One battery is provided for the 28.3 and 50 L/min models, but up to two batteries can be used to Pump Exhaust Diffuser extend the run time up to 7 hours of continuous use Battery for the 28.3 model (4.5 hours for the 50 L/min and Access 2 hours for the 100 L/min).
- Page 5 Recipe editor. 5. The Main tab is updated as samples are collected. Zones, Locations, and Recipes 1. AeroTrak data is organized by Zones and Locations within Zones. This is modeled after the data organization used by the supported classification 2.
- Page 6 2. A Recipe consists of the sampling mode, sample timing, alarm thresholds, display preferences and other configuration settings to be used for sampling. Each Zone has one Recipe that is associated with it, and one Recipe can be shared by several Zones. When a Zone is selected from the Main screen for sampling, its associate Recipe is also activated.
- Page 7 9. Timing field details are provided below: Data Screen Labels and Controls Field Description Field Description Start Start Delay indicates how long it will be before #, ft Button used to change between counts and Delay the first sample is taken. concentration displays.
- Page 8 Software ™ 1. The TrakPro Lite Secure Data Transfer utility and user manuals come on a CD that was packaged with your particle counter. 2. To install the communications software and drivers, insert the CD into the computer drive and follow the on-screen instructions.
